https://doi.org/10.53656/ped2023-5s.01

Резюме. Ballast Water Management Convention entered into force on the 8th of September 2017. Nevertheless, six years later, many problems are still waiting for their solution. Despite International Maritime Organization Guidelines, IMO HTW 7/12, Resolution MEPC.173 (58) and others, some details are still open questions that are waiting to receive their answer from the practice. The maritime society still discusses the correct way of collecting samples from ship’s ballast tanks, laboratory accreditation and licensing regulations, ballast water treatment systems maintenance. Another important issue is education and training of the personnel in charge of systems’ operation and repair. Education and training processes are already in the focus of the International Maritime Organization (IMO) but still waiting for Member states’ decision. The idea for such kind of activities appears in some particular educational institutions and training centers but the subject is not in the syllabi. Ballast Water Management Convention and related knowledge and skills are the new challenge for the shipping in all respects. The aim of this article is research regarding implementation of Ballast Water Management Convention in maritime education worldwide and in Bulgarian education and training institutions. The method of information analysis is used in order to compare what the leading maritime institutions propose in respect to Ballast Water Management Convention.

Ключови думи: Ballast Water Management Convention; maritime education and training; distance learning; computer based training; STCW Convention

Introduction

The expansion of trade by sea caused the International Maritime Community to pay attention to a problem that permanently gripped the entire World Ocean. Along with transporting goods, ships transport biological organisms from one climate zone to another. In this way, permanent disruption of the habitat of both native and introduced organisms is caused. A large part of the invasive species adapts to the new living conditions, but causes changes to the host eco-system.

Research on bio invasion in various marine areas has been done for centuries. Such statistics are collected in the administrations and research institutes of the designated shipping regions. Statistics for the Black Sea, for example, report registered invasive species at 217. Almost half of them (102) have permanently established themselves in different parts of the sea. This high proportion of invasive species assumes a serious impact on the biodiversity of the Black Sea, with negative consequences for human activities and economic interests (Kasapoglu et al. 2011; Yankova 2011; Băncilă et al. 2022).

In 2004, at a diplomatic conference in London, initiated by the International Maritime Organization (IMO), the Member States of the Organization, in the presence of representatives of associated countries and non-governmental organizations, adopted the International Convention for the Control and Management of Ship Ballast Water and Sediments (Ballast Water Management Convention, BWMC). The Convention applies to all ships designed or constructed to carry ballast, of over 400 gross tonnage, flying the flag of a State that has ratified the Convention. In addition, ships flying the flag of another country but visiting the ports of a country party to the Convention must also comply with the requirements of the BWMC1, 2. The Convention requires provision of scientific developments and research in the field of ship ballast water control, as well (David and Gollasch 2015).

The scientific research is one part of the ballast convention's effect on the overall maritime transport system. Another indispensable part is maritime education, for the development of which there are also indications from the IMO. The application of the provisions of the BWM Convention raises a number of educational issues. The performance requires common efforts of the entire crew – bridge and engine. The International Maritime Organization has introduced a competency in the Standard of Training, Certification and Watchkeeping Convention – 78/95 (STCW – 78/95) which requires ship officers to have knowledge of maritime environmental protection. Nikola Vaptsarov Naval Academy delivers to the students a new subject in the syllabi of deck and engine students – “Environmental protection awareness". The course is mandatory as per Manila amendments to the STCW Convention. A small part of the program is also dedicated to the problems caused by invasive species carried in ballast water (Belev and Daskalov 2019).

Purely environmental topics in the subject are not enough. The application of the D-1 and D-2 standards raises the following problems, related to the ship’s operation, which need to be solved by education (Phanuwat 2018):

– ensuring stability of the vessel when ballast water exchange operation in different sailing conditions is in progress;

– legislative aspects for ballast water exchange and treatment;

– risk assessment of ballast water changing and treating operation in different sailing conditions;

– taking samples from the ballast tanks and analyzing the water in a specialized laboratory;

– working with various ballast water treatment systems on board.

Application of the D-2 standard requires a ballast water treatment system to be installed on board ships. The different ways of applying the standard allow systems of different types and constructions. Safe and effective work with them requires good technical knowledge and understanding of the principles of the treatment process.

The article discusses the entire maritime education and training process, related to BWM Convention. A number of educational institutions were observed and proposed courses were analyzed in order to assess their compliance with IMO proposed amendments to the Seafarers' Training, Certification and Watchkeeping Code related to ballast water management. The methods of information analysis and method of comparative analysis are used to present the current place of Ballast Water Management culture in the behavior of maritime educational institutions. The article presents current and potential gaps in maritime education and training in this respect.

1. IMO education and training strategy related to BWMC

IMO has established a precise procedure for initiating and conducting any training in the maritime industry. It is the usual practice of the organization that innovations in shipping, resulting from decisions of the Organization’s committees and subcommittees, be discussed by the SUB-COMMITTEE ON HUMAN ELEMENT, TRAINING AND WATCHKEEPING (HTW) before they become recommended or mandatory standards of the STCW Convention3.

At the 7th session in 2020, the HTW sub-committee included in its agenda a proposal for an amendment to the Ballast Water Management Convention Code4. The proposal was made by China and the International Chamber of Shipping (ICS), based on a number of documents of the Maritime Environment Protection Committee, adopted at the 72nd and 73rd sessions of the Committee. The document details how the Code to STCW – 78/95 Convention should be amended and the competencies for all seafarers on ships added. In this activity, IMO is also encouraged by the global trade organizations in the maritime industry, called cosponsors. Their proposals are:

1. To develop and supplement the STCW code in Chapter II and III by including competencies, related to BWMC.

2. To create a new model course and to amend the existing model courses, thereby supporting the implementation of BWMC.

At its next session, held on March 18, 2022, the HTW also included Japan's proposal, which is directly related to the one made at the 7th session by China and the ICS5. Thus, the idea of including the BWM Convention in maritime education already acquires precise dimensions and scope. HTW document 7/12 included a template for supplementing Chapters 2 and 3 of the STCW-78 Code to facilitate the IMO Assembly in making a final decision on this matter. The HTW 7/12 document also makes specific proposals to the existing model courses which form the basis of maritime education – Model Course No. 7.01 “Master and chief mate”, Model Course No. 7.02 “Chief engineer officer and second engineer officer”, Model Course No. 7.03 “Officer in charge of a navigational watch”, Model Course No. 7.04 “Officer in charge of an engineering watch”, Model Course No. 7.08 “Electrotechnical officer”, Model Course No. 7.15 “Electro-technical rating”, Model Course No. 7.10 “Ratings as able seafarer deck”, Model Course No. 7.16 “Ratings as able seafarer engine”.

An overview of Model Course No. 7.01 “Master and chief mate”, Model Course No. 7.02 “Chief engineer officer and second engineer officer”, Model Course No. 7.03 “Officer in charge of a navigational watch”, Model Course No. 7.04 “Officer in charge of an engineering watch” indicates that BWMC is present in the minimum educational requirements, but an understanding of ship ballast handling must be comprehensive with a focus on the operation of the ship and ensuring its sustainability. In fact, this issue is of the greatest degree of risk in the handling of ballast during transition and deserves the most serious attention from training institutions. For this reason, the amendment of Model Course No. 7.016 and Model Course No. 7.027 is particularly important because of the focus of the training on the management level of the ship’s crew.

2. Analysis of Current Education and Training relevant to BWMC

Until the entry into force of the BWM Convention, 13 years have passed since its adoption. During this period, especially as the process of its ratification by most of the IMO member states progressed, a number of qualification courses were created at the request of the shipping companies concerned. Lee and Ha have conducted a study on the development of ballast water management training under the STCW-78 convention (Lee and Ha 2016). In it, they have analyzed which training centers have created a training program without emphasizing the content. In the conclusions to the publication, the authors have proposed to supplement Part A of the code to STCW-78 by creating Section Ⅵ/7. However, they did not add substance to their proposal, thus leaving open the question of how to engage STCW-78 with the BWM Convention.

Lee and Ha's research turned out to be unique in its substance and dates back to 2016. Almost all training institutions included in it have either been converted or non-existent, and the courses offered by them have been significantly changed.

To solve the research task, an extended search was conducted in the global network INTERNET for training of any kind related to the implementation of the BWM Convention. The results are divided into two categories – training for initial maritime education and qualification training activity. The keywords Ballast Water Management Convention, Maritime Education and Training, Distance learning, Computer based training, STCW Convention, IMO Model course were used in the search. 22 websites were shown with training information related to the BWM Convention and the application of its rules. In addition to the information from websites, curricula for the Bachelor and Master degree at the Maritime Faculty of the University of Split and curricula for the same degree and specialty at the University of Tallinn were examined.

Of all the internet sources and the above mentioned curricula, only one showed that training for BWM Convention implementation was taking place as part of an academic program at a maritime university – the website of the Faculty of Marine and Fisheries Sciences at the University of Ghana8. The course offers students an in-depth introduction to the requirements of the BWM Convention, as well as the specific application in the safe operation of the ship and the reduction of risk in ballast operations. The course is a subject in the Master's program only for students who are training to work on merchant ships.

17 websites contain information about a qualification course, related to the implementation of the BWM Convention. The names of the training institutions and basic information about the training they offer are shown in Table 1.

Almost all training centers offer online computer-based training (CBT) or e-learning, which use the same facilities. Only one institution uses classical education – classroom training under instructor’s supervision.

Another interesting point is course duration. Suppliers offer different duration and formally it doesn’t depend on the type of training – e-learning or training at school. It mostly depends on the course content. The survey states that training institutions’ syllabi are also different and in this respect their training is categorized as basic, advance and professional.

The content of basic training and education category consists of the following topics in table 29,10:

It is obvious that the basic course is designed to inform trainees about the current status of the regulations and some practical solutions regarding BWM Convention. Usually, the duration of such category courses is between 50 minutes and 4 hours. The course ends with certification of the participant. The certificate is issued by the specific training center and approval by Maritime authority or classification society is optional.

Advanced training and education cover more topics and the syllabus is designed to deliver to trainees some practical skills. The participants upgrade their knowledge if they have preliminary training on BWMC. The content of advance courses is shown in table 311,12:

The duration, proposed by training institutions for advanced courses, is between one and three days. The majority of centers deliver e-learning or CBT online education. Tradition says that practical skills are acquired when students have faceto-face contact with their instructors. That is why it is highly recommended that such kind of education and training to be delivered in the classroom.

The courses end with certificate issued by the educational institution.

Professional courses are more or less similar to education. Such a course is delivered by Lloyd’s Maritime Academy and its duration is twelve weeks. The syllabus consists of six modules and covers BWM Convention requirements and rules, implementation and responsibility of Ballast Water Management, Ballast Water Treatment and technologies used, technique for taking samplings and monitoring and ballast water risk assessment. Almost the same is the content of the syllabus of the Department of Marine and Fisheries Science, which is an education syllabus for Bachelor’s degree.

Conclusions and summary

The research conducted shows that there is a worldwide interest in seafarer’s training, related to the implementation of the BWM Convention. The entry into force of the Convention was a long-awaited act and it caused significant changes in the cargo ship’s equipment. In addition, the Safety Management System, related to International Safety Management Code (ISM Code), was supplemented with new procedures for the operation and maintenance of the ship's ballast handling system.

The past six-year period shows that further training of ship's crews on the rules of the Convention is required, as well as a number of technical issues relating to the operation of equipment and the risk assessment of the entire process of ballast operations. Until now, the IMO has always faced the problems of maritime education and qualification and regulated the process with adequate measures and requirements. The proposals of some member states and co-sponsors are a good indicator that the maritime community is concerned about the implementation of the BWM Convention. The next steps should be towards supplementing the STCW-78 convention and creating a model course. In this way, the process will be improved and the training of marine personnel will be standardized.

NOTES

1. INTERNATIONAL MARITIME ORGANIZATION. Global treaty to halt invasive aquatic species to enter into force, https://www.imo.org/en/ MediaCentre/PressBriefings/Pages/21-BWM-EIF.aspx [Viewed 2023.02.15].

2. INTERNATIONAL MARITIME ORGANIZATION, International Conference on Ballast Water Management for Ships, International Convention for the Control and Management of Ships' Ballast Water and Sediments, (2004). Final Act, 16 February 2004. IMO, London.

3. INTERNATIONAL MARITIME ORGANIZATION. International Convention on Standards of Training, Certification and Watchkeeping for Seafarers, 1978. IMO, London, 2017.

4. IMO SUB-COMMITTEE ON HUMAN ELEMENT, TRAINING AND WATCHKEEPING. Development of Training Provisions for Seafarers Related to the BWM Convention. 7th session, Agenda item 12, 28 February 2020.

5. IMO SUB-COMMITTEE ON HUMAN ELEMENT, TRAINING AND WATCHKEEPING. Report to the Maritime Safety Committee. 8th session, Agenda item 16, 18 March 2022.

6. IMO SUB-COMMITTEE ON HUMAN ELEMENT, TRAINING AND WATCHKEEPING. Model Course 7.01 – Officer in Charge of a Navigational Watch. 2014 Edition. IMO, London.

7. IMO SUB-COMMITTEE ON HUMAN ELEMENT, TRAINING AND WATCHKEEPING. Model Course 7.02 – Chief engineer officer and second engineer officer. 2014 Edition. IMO, London.

8. UNIVERSITY OF GHANA, DEPARTMENT OF MARINE AND FISHERIES SCIENCES. MASC 636 Ballast Water Management. https://www.ug.edu.gh/ marine-fisheries/courses/masc-636-ballast-water-management, [Viewed 202303-23].

9. BALLAST WATER MANAGEMENT – Marine training course. https://www. rina.org/en/ballast-water-management-course, [Viewed 2023-03-23].

10. BALLAST WATER MANAGEMENT AWARENESS. https://www.seably. com/courses/ballast-water-management-awareness, [Viewed 2023-03-23].

11. BALLAST WATER MANAGEMENT (BWM). https://marinerskills.com/ ballast-water-management.php, [Viewed 2023-03-23].

12. BALLAST WATER MANAGEMENT (BWM). https://maritime.solent.ac.uk/ courses/stcw-safety-and-security/ballast-water-management, [Viewed 2023-03-23].

REFERENCES

BĂNCILĂ, RI.; SKOLKA, M.; IVANOVA, P.; SURUGIU, V.; STEFANOVA, K.; TODOROVA, V.; ZENETOS, A., 2022. Alien species of the Romanian and Bulgarian Black Sea coast: state of knowledge, uncertainties, and needs for future research. Aquatic Invasions, vol. 17, no. 3, pp. 353 – 373. Available from: https://doi.org/10. 3391/ ai.2022.17.3.02.

BELEV, B.; DASKALOV, S., 2019. Computer technologies in shipping and a new tendency in ship’s officers’ education and training. In: IOP Conf. Ser.: Mater. Sci. Eng. 618 012034. Available from: https://doi. org/10.1088/1757-899X/618/1/012034.

DAVID, M.; GOLLASCH, S., 2015. Overall Conclusions on the Ballast Water Issue and Its Management Options. Global Maritime Transport and Ballast Water Management. Invading Nature - Springer Series in Invasion Ecology, INNA, vol. 8, pp. 293 – 301.

KASAPOGLU, N.; DUZGUNES, E.; ERDOGANSAĞLAM, N.; SAĞLAM, H., 2011. Alien Species and Their Impacts in the Black Sea. In: Conference Proceedings. 5th International Conference Aquaculture and Fishery, 5, Belgrade (Serbia), 1 – 3 Jun 2011, pp. 256 – 260. ISBN 978-86-7834-119-9.

LEE, Y.-C.; HA, W.-J., 2016. A study on the development of ballast water management-related familiarization training pursuant to the STCW convention. Journal of the Korean Society of Marine Engineering, vol. 41, no. 2, pp. 163 – 170. ISSN 2234-7925.

PHANUWAT, P., 2018. The impact of Ballast Water Management Convention on seafarers work practices. Dissertation. Malmo, Sweden: World Maritime University Dissertations.

YANKOVA, M., 2011. Black Sea Non-Native Fish List. Black Sea Commission Publication.
