Резюме. A tertiary method of enhanced oil recovery (EOR) based on the watergas alternating injection process (WG) is examined in this article based on the ratio between saturation pressure and reservoir pressure. A hydrodynamic simulation of the WAG process was carried out using TEMPEST MORE software (version 7,1). Many hydrocarbon fields worldwide are currently experiencing declining production rates. However, by utilizing advanced technologies like alternate injection of water and associated petroleum gas, the final oil recovery factor (RF) can be significantly increased. To ensure successful water injection experiments in real fields, it is crucial to consider the ratio of saturation and reservoir pressures during injection. Any negligence in this regard can lead to failure of the experiments aimed at enhancing oil recovery through WAG application. The research examines two variations of reservoir system models with certainty. In the initial model, the saturation pressure is lower than the reservoir pressure, signifying an under-saturated state of the reservoir system containing dissolved gas. Consequently, when accompanying petroleum gas is introduced, it mixes with oil at precise thermobaric conditions. According to the second model, the reservoir is saturated with gas at a saturation pressure equivalent to the formation pressure. A thorough assessment indicates that the success of water alternating gas injection (WAG) is heavily influenced by the initial state of the reservoir. In situations where the reservoir is already saturated with gas, implementing water-gas stimulation may be ineffective as gas breakthroughs may occur rapidly. However, implementing WAG in saturated reservoirs can lead to a 1 – 8% rise in overall oil production, observable within 3 – 4 years, depending on the timing after waterflooding. Simultaneously, in the case of reservoirs with a low saturation pressure, which exhibits an undersaturated reservoir system, the implementation of water alternating gas injection can be seen as a viable approach for enhancing oil recovery. WAG is a proven method that confidently increases oil recovery up to 10% in undersaturated reservoirs compared to conventional waterflooding.

Ключови думи: WAG, Waterflooding; Saturation pressure; Cumulative oil production; EOR

1. Introduction

Over the past few years, the use of water alternating gas injection (WAG) has become more prevalent in global operations as a means of boosting the production of challenging oil reserves (Liao et al. 2022; Afzali, Rezaei & Zendehboudi 2018; Belazreg & Mahmood 2020). This innovative technology is being utilized to enhance oil recovery from these reserves. Implementing water alternating gas injection method in the studied oil and gas region of Western Siberia has the potential to significantly increase the oil recovery factor. Renowned for its vast natural gas reserves, this region boasts numerous fields that possess the necessary geological and physical characteristics for the successful application of this approach (Bhadran et al 2019; Al-Obaidi 2021; Sorokin et al. 2021). The article focuses on the technique of alternating injections of associated petroleum gas and water, which is better suited for the geological, physical, and geographical characteristics of Western Siberia. This method, known as WAG, increases both the coverage coefficient and the displacement coefficient (Al-Shargabi 2022; Smirnov & Al-Obaidi 2008; Verma 2015). The alternate injection of working agents involves injecting gas and water in small alternating slugs, which is typically 5% or less of the initial oil-saturated pore volume.

To successfully displace oil using injected agents, it is crucial to ensure mutual miscibility between the injected gas and the fluid present in the formation. This can be achieved by closely adhering to specific thermobaric conditions and having a deep understanding of the saturation state of the formation system during the WAG process (Wojnicki et al. 2022; Al-Obaidi & Khalaf 2019; Panahov, Abbasov & Jiang 2021). By confidently following these guidelines, effective displacement of oil can be accomplished.

After extensively evaluating relevant literature sources (Ma & James 2022; Liao et al. 2022; Abdullah & Hasan 2021), it has been established that the application of water alternating gas (WAG) injection in oil reservoirs frequently neglects a crucial factor: the saturation pressure to reservoir pressure ratio during stimulation initiatives. Moreover, there is a significant knowledge gap regarding the ideal amount and timeframe for injection of displacement agents, as well as the most suitable stage of development for incorporating WAG.

This study explores the potential of implementing WAG as a tertiary method to enhance oil recovery in Upper Jurassic deposits. These formations show promise for WAG application, supported by limited field trials and published data from hydrodynamic simulations specific to Western Siberia (Bello et al. 2024; Shandrygin & Lutfullin 2008; Berman 2023; Al-Obaidi 2016). Notably, the Nizhnevartovsk and Surgut arches contain Upper Jurassic reservoirs with a significant difference between saturation and formation pressures, indicating predominantly undersaturated gas systems (Liu et al. 2022; Chen et al. 2023).

During the 2006 – 2007 in the Novogodny field, it was discovered that water-gas injection was unsuccessful in the later phases of field development. This was because the reservoir system had undergone significant changes from its original state when the pilot project for water-gas stimulation was implemented. The operational wells had 80 – 90% water cut, while the initial saturation of the reservoir system was evident through the saturation pressure being nearly identical to the reservoir pressure (Al-Obaidi & Chang 2023).

In order to conduct a successful pilot industrial work on WAG, it is crucial to carefully consider specific criteria when choosing an object. One important factor to consider is the level of heterogeneity, as a high degree of heterogeneity can lead to decreased efficiency of water injection due to rapid breakthroughs of displacing agents in highly permeable layers (Adegbite & Al-Shalabi 2022; Xue, Liu & Zhang 2023; Matkivskyi & Burachok 2022). Additionally, reservoir temperature is a key consideration when selecting candidate wells for WAG. When the temperature exceeds 70 °C, the efficiency of oil recovery can greatly improve due to the removal of residual oil components by the injected gas (Rudyk, Spirov & Tyrovolas 2018; Patkin & Al-Obaidi 2001). The prevention of crystalline hydrate formation, particularly in the reservoir, is of utmost importance for WAG. This requires maintaining a higher temperature than the hydrate formation temperature. Additionally, the reservoir system must be undersaturated with hydrocarbon gas, with a saturation pressure that is 25 – 50% lower than the reservoir pressure (Duan et al. 2023; Pourhadi & Fath 2020). This study aims to analyse the impact of saturation pressure to reservoir pressure ratio on the effectiveness of water alternating gas stimulation. The research will focus on the Upper Jurassic reservoirs in Western Siberia and the findings can be adapted for use with sediments from similar environmental conditions.

2. Methodology and materials

To simulate the impact of the reservoir system model on the efficiency of WAG, the Tempest (Khan, Amin & Madden 2013; Hofmann, Al-Obaidi & Khalaf 2022; Vinogradov et al. 2015) software package was used. Within the software, a comprehensive hydrodynamic model was constructed for the Upper Jurassic reservoir, with its lithology being characterized by alternating layers of clays and sandstones. The thickness of the reservoir was 8.5 meters and it was situated at a depth of 2600 meters. By examining the mean weighted values of key parameters from Upper Jurassic formations in the Nizhnevartovsk arch, the predominant geological and physical features of the deposit were determined. These parameters consist of a porosity of 16%, a permeability of 0.025 µm2, a reservoir temperature of 91°C, and an initial reservoir pressure of 26 MPa. Furthermore, the PVT (pressure, volume and temperature) characteristics of both oil and gas were identified, with an initial oil saturation of 63% and an oil density of 843 kg/m3 at surface conditions. After extensive planning, the model was meticulously crafted to incorporate the relative phase permeabilities (Kr) and capillary pressures. These parameters were acquired from generalized relationships observed in over 30 hydrocarbon fields within Upper Jurassic formations (Kontorovich et al. 2024; Novikov et al. 2023). Utilizing an inverted five-point development system with a well spacing of 500 meters, the model boasts a generous size of 100x100x17 cells, guaranteeing its thoroughness and precision.

The model was evaluated in two versions. The initial situation involves a saturation pressure of 12 MPa, which is lower than the reservoir pressure, indicating an undersaturated reservoir with gas dissolved in the oil. In this case, the addition of associated petroleum gas would result in the gas dissolving in the oil under specific thermobaric conditions (Pavlova et al. 2022; Al-Obaidi & Khalaf 2023). The second scenario assumes the reservoir is completely saturated with gas at a saturation pressure equal to the formation pressure of 26 MPa.

3. Results and discussions

During the initial phase, a homogenous model was utilized to compute various possibilities involving varying proportions of displacement agents injected, in terms of both time and quantity (Table 1).

The cumulative production of a low saturation pressure reservoir is twice as high as that of a saturated gas reservoir. For further analysis of the WAG, the optimal option was selected with the following parameters: the ratio of injectivity limitations: water – 400 m 3/day, gas – 100 thousand m 3/day, and the ratio of water and gas injection time – 90/30 days. The calculation period was 10 years.

Since a stochastic reservoir model was subsequently considered, permeability values varied from 10 to 60 md, with the average permeability for the object being 25.5 md. The initial oil saturation and porosity were determined for each layer, while the initial gas oil ratio (GOR) was set at143 m3/m3.

Given that the majority of Western Siberia's fields are currently in the 3rd stage of development (Mukhina et al. 2021; Dorhjie et al. 2023; Malozyomov et al. 2023), it is imperative to implement innovative techniques to boost oil recovery. One effective method is the incorporation of new methods that enhance the displacement of oil. The utilization of WAG (Water Alternating Gas) has proven to be highly effective in this regard, as it combines the advantageous qualities of both gas and water. To accurately assess the results, a supplementary evaluation of waterflooding was conducted when modelling the WAG process as a tertiary enhanced oil recovery (EOR).

A variety of choices were evaluated. Initially, the deposit functioned naturally for 1 – 2 years, allowing for the utilization of elastic forces and the inclusion of stagnant zones in development. Additionally, the duration of waterflooding implementation before water injection ranged from 1 to 5 years. Through the use of multivariate modelling, the following outcomes were achieved (Table 2).

In the third and fourth years after waterflooding, the introduction of water alternating gas injection resulted in a marginal rise of 0.6 (0.19 thousand tons) and 4% (2.07 thousand tons) in the accumulated oil production for a gas-saturated reservoir that had undergone a period of depletion beforehand (see Fig. 1). Once the formation is operated in a natural mode, it is then subjected to waterflooding. This results in the restoration of reservoir pressure in the second year, causing a significant rise in fluid extraction. This can be attributed to the wider coverage of the formation due to development, as evidenced by a non-linear correlation in the accumulated oil production graphs (Osatemple et al. 2021; Al-Obaidi, Wang & Hofmann 2022).

The reservoir system reaches its maximum capacity of dissolved gas, resulting in incomplete dissolution of any additional gas injected. This causes the removal of the fluid due to the i n c r e a s e d g a s - t o - o i l ratio (Fig. 2).

Simultaneously, implementation of WAG in the 5th year after waterflooding results in a significant 8% increase (equivalent to 3.41 1000 tons) in oil production compared to the traditional waterflooding method. The impact of utilizing WAG takes approximately 3 – 4 years to manifest.

Figure 3 illustrates how water-gas stimulation can serve as a tertiary technique for enhancing oil production in formations containing a low saturation pressure, which is a common feature of Upper Jurassic deposits.

As the natural mode of reservoir operation increases, the total production of oil also increases (Jia et al. 2023; Liu et al. 2024). This increase is observed before the implementation of waterflooding. Additionally, on the graph, the shift from natural operation to the use of a reservoir pressure maintenance system can be seen as a bend with subsequent stabilization of the lines. This is due to a sharp withdrawal of oil when the development involves reservoir zones that have been affected by water flooding (Yongle et al. 2019; Tang et al. 2023). Based on the modelling results, it was noted that the best performance was achieved when using WAG in the second year after waterflooding; the maximum increase in fluid production in this case was 8.2% (4.8 thousand tons). With a further increase in the waterflooding time before WAG, the positive effect of WAG decreases. Thus, with water-gas impact on the formation in the 3rd year after waterflooding (from the 5th year of operation), the increase in accumulated production is already 7.3%.

The utilization of WAG technology after waterflooding enhances the displacement coefficient. This results in the involvement of poorly permeable sections of the reservoir in the development process, by replacing oil with gas in their pore spaces. Additionally, the use of WAG technology facilitates a more uniform production of oil-saturated zones, as compared to the use of only waterflooding. This can be observed in the oil saturation cubes depicted in Figure 4.

This particular method, illustrated in Figure 4a, allows for a larger area of the reservoir to be covered. It achieves this by either penetrating the poorly permeable zones and substituting gas with oil in their pores, or dissolving the gas in the oil (particularly in viscous oil). The outcome of this application is an improved oil recovery process, resulting in higher recovery factors when utilizing WAG.

During the initial phase of reservoir development in its natural state, the pressure within the reservoir decreases to 16 MPa (as shown in Fig. 5). Later on, when waterflooding is implemented, the reservoir undergoes a recovery process. However, when gas is injected, there is a sudden spike in reservoir pressure due to the expansion of the gas-oil mixture. This highlights the significant impact of the pressure regime and the dissolved gas regime. Thus, the effectiveness of water-gas stimulation is significantly influenced by the initial state of the reservoir system.

4. Conclusions

Water-gas stimulation may not be effective in gas-saturated reservoirs due to the rapid occurrence of gas breakthroughs. However, the effects of implementing WAG can be observed within 3-4 years and may lead to a 1-8% rise in overall oil production, contingent upon the timing of its implementation following waterflooding. The highest recorded increase of 8% was achieved by introducing WAG in the fifth year of development.

In general, cumulative production indicators with WAG are comparable to waterflooding. However, WAG may not be the best option due to the high development costs associated with the necessary technological equipment (Afzali, Rezaei & Zendehboudi 2018; Chang, Al-Obaidi & Patkin 2021).

At the same time, for reservoirs with low saturation pressure, which includes most Upper Jurassic formations, WAG is an effective method for increasing oil recovery. The WAG method is a highly effective technique that combines the advantageous properties of gas and water. While gas dissolves in the oil and increases the displacement coefficient, water boosts the sweep efficiency. As a result, the WAG method ensures a significant increase in the oil recovery coefficient compared to pure waterflooding. In this case, WAG injection can be used after waterflooding, but the waterflooding period should not be too long.

It is possible to increase oil recovery by up to 10% in Upper Jurassic reservoirs by using WAG (Water Alternating Gas) compared to conventional waterflooding. To maximize the potential of WAG as a tertiary method of enhancing oil recovery, it is recommended to operate the reservoir naturally for a long time, followed by waterflooding and the use of WAG in the second year after waterflooding. This approach has been proven to be highly effective in increasing oil recovery.

REFERENCES

ABDULLAH, N. & HASAN, N., 2021. The implementation of Water Alternating (WAG) injection to obtain optimum recovery in Cornea Field, Australia. Journal of Petroleum Exploration and Production, vol. 11, pp. 1475 – 1485. https://doi.org/10.1007/s13202-021-01103-7.

ADEGBITE, J.O. & AL-SHALABI, E. W., 2022. Effect of heterogeneity on engineered water injection in carbonates using five-spot sector model: A numerical study. Petroleum, vol. 8, no. 3, pp. 375 – 390. https://doi.org/10.1016/j.petlm.2021.04.001.

AFZALI, S. REZAEI, N. & ZENDEHBOUDI, S., 2018. A comprehensive review on Enhanced Oil Recovery by Water Alternating Gas (WAG) injection. Fuel, vol. 227, pp. 218 – 246. https://doi.org/10.1016/j. fuel.2018.04.015.

AFZALI, S., REZAEI, N. & ZENDEHBOUDI, S., 2018. A comprehensive review on Enhanced Oil Recovery by Water Alternating Gas (WAG) injection. Fuel, vol. 227, pp. 218 – 246. https://doi.org/10.1016/j. fuel.2018.04.015.

ALEXANDER, G., SUDAD, A.O. & VIKTOR, S., 2023. Numerical Simulation of Water Alternating Gas Injections (WAG) into Hydrocarbon Reservoirs: Factors Influencing Oil Recovery. J Geol Geophys., no. 12, p. 1147.

AL-OBAIDI, S.H. & CHANG, W., 2023. Evaluation of the Quantitative Criteria of Triassic Carbonate Rocks Reservoirs. J Geology & Geophysics, vol. 12, p. 1067.

AL-OBAIDI, S.H. & KHALAF, F.H., 2019. Development of traditional water flooding to increase oil recovery. Int J Sci Technol Res., vol. 8, no. 1, pp. 177 – 181.

AL-OBAIDI, S.H. & KHALAF, F.H., 2023. A New approach for enhancing oil and gas recovery of the hydrocarbon fields with low permeability reservoirs. Pet Petro Chem Eng J., vol. 7, no. 2. DOI: 10.23880/ppej16000343.

AL-OBAIDI, S.H., 2021. Analysis of hydrodynamic methods for enhancing oil recovery. J Petrol Eng Technol., vol. 6, pp. 20 – 26.

AL-OBAIDI, S.H., WANG, J. C. & HOFMANN, M., 2022. Modelling the development of oil rim using water and gas injection. Nat Sci Adv Technol Edu., vol. 31, no. 3, pp. 279 – 292.

AL-OBAIDI, S.H., 2016. High oil recovery using traditional waterflooding under compliance of the planned development mode. J Petrol Eng Technol., vol. 6, no. 2, pp. 48 – 53.

AL-SHARGABI, M., 2022. Carbon Dioxide Applications for Enhanced Oil Recovery Assisted by Nanoparticles: Recent Developments. ACS Omega, vol. 7, no. 12, pp. 9984 – 9994. DOI: 10.1021/acsomega.1c07123.

BELAZREG, L. & MAHMOOD, S.M., 2020. Water alternating gas incremental recovery factor prediction and WAG pilot lessons learned. J Petrol Explor Prod Technol, vol. 10, pp. 249 – 269. https://doi. org/10.1007/s13202-019-0694-x.

BELLO, A. et al., 2024. Numerical study of the mechanisms of nanoassisted foam flooding in porous media as an alternative to gas flooding. Heliyon, vol. 10, no. 5, p. e26689. https://doi.org/10.1016/j. heliyon.2024.e26689.

BERMAN, L., 2023. Some Possibilities of Increasing the Completeness of Oil and Gas Recovery. Qeios. https://doi.org/10.32388/GCFNG0.

BHADRAN, V. et al., 2019. Experimental Study of Oil Recovery by Water Alternating Gas (WAG) process in Microporous media. J. Phys. Conf. Ser., vol. 1276, p. 012023. DOI: 10.1088/1742-6596/1276/1/012023.

CHANG, W.J., AL-OBAIDI, S.H. & PATKIN, A.A., 2021. The use of oil soluble polymers to enhance oil recovery in hard to recover hydrocarbons reserves. Int Res J Mod Eng Technol Sci., vol. 3, no. 1, pp. 982 – 987.

CHEN, Y. et al., 2023. Sequence Stratigraphy of the Jurassic Strata and Occurrences of Potential Sandstone Reservoirs in the ST Gas Field, Northern West Siberia Basin. Applied Sciences, vol. 13, no. 22, p. 12096. https://doi.org/10.3390/app132212096.

DORHJIE, D. B. et al., 2023. Tight and Shale Oil Exploration: A Review of the Global Experience and a Case of West Siberia. Energies, vol. 16, no. 18, p. 6475. https://doi.org/10.3390/en16186475.

DUAN, X. et al., 2023. Prediction of Gas Hydrate Formation in the Wellbore. Energies, vol. 16, no. 14, p. 5579. https://doi.org/10.3390/en16145579.

HOFMANN, M. AL-OBAIDI, S. H. & KHALAF, F. H. 2022. Modeling and monitoring the development of an oil field under conditions of mass hydraulic fracturing. Trend Sci., vol. 19, no. 8, p. 3436.

JIA, D. et al., 2023. Collaboration between Oil Development and Water/ Power Consumption in High-Water-Cut Oilfields. Sustainability, vol. 15, no. 14, p. 11405. https://doi.org/10.3390/su151411405.

KHAN, C., AMIN, R. & MADDEN, G., 2013. Carbon dioxide injection for enhanced gas recovery and storage (reservoir simulation). Egyptian Journal of Petroleum, vol. 22, pp. 225 – 240. DOI: 10.1016/j. ejpe.2013.06.002.

KONTOROVICH, V.A. et al., 2024. Geological Structure and Prospects of Hydrocarbon Potential of Paleozoic Deposits in Southeastern Regions of West Siberia. Russian Geology and Geophysics, vol. 65, pp. 60 – 84. DOI: 10.2113/RGG20234657.

LIAO, H. et al., 2022. Field Application and Experimental Investigation of Interfacial Characteristics of Surfactant and CO2 Alternative Injection. ACS Omega, vol. 7, no. 38, pp. 34222 – 34229. DOI: 10.1021/ acsomega.2c03605.

LIU, B., YAO, C., LIU, Y. et al., 2024. Quantitative evaluation of wateralternative-natural gas flooding in enhancing oil recovery of fractured tight cores by NMR. J Petrol Explor Prod Technol, vol. 14, pp. 221 – 237. https://doi.org/10.1007/s13202-023-01693-4.

LIU, K. et al., 2022. Reservoir characteristics and controlling factors of physical properties of Jurassic Toutunhe Formation in the eastern segment of the southern margin of Junggar Basin [J]. Petroleum Geology & Experiment, no. 4, pp. 579 – 592.

MA, S., & JAMES, L. A., 2022. Literature Review of Hybrid Low Salinity Water-Alternating-Gas Injection and Investigation on Hysteresis Effect. Energies, vol. 15, no. 21, p. 7891. https://doi.org/10.3390/en15217891.

MALOZYOMOV, B. V. et al., 2023. Overview of Methods for Enhanced Oil Recovery from Conventional and Unconventional Reservoirs. Energies, vol. 16, no. 13, p. 4907. https://doi.org/10.3390/en16134907.

MATKIVSKYI, S. & BURACHOK, O., 2022. Impact of Reservoir Heterogeneity on the Control of Water Encroachment into GasCondensate Reservoirs during CO2 Injection. Management Systems in Production Engineering, vol. 30, no. 1, pp. 62 – 68. https://doi. org/10.2478/mspe-2022-0008.

MUKHINA, E. et al., 2021. Enhanced Oil Recovery Method Selection for Shale Oil Based on Numerical Simulations. ACS Omega, vol. 6, no. 37, pp. 23731 – 23741. DOI: 10.1021/acsomega.1c01779.

NOVIKOV, D.A. et al., 2023. Geochemistry and origin of natural gas in the arctic area of West Siberia. Environ Earth Sci, vol. 82, p. 261. https://doi. org/10.1007/s12665-023-10973-5.

OSATEMPLE, M. I. et al., 2021. Assessment and Optimization of Waterflooding Performance in a Hydrocarbon Reservoir. Paper presented at the SPE Nigeria Annual International Conference and Exhibition, Lagos, Nigeria, August. https://doi.org/10.2118/207114-MS.

PANAHOV, G.M., ABBASOV, E.M. & JIANG, R., 2021. The novel technology for reservoir stimulation: in situ generation of carbon dioxide for the residual oil recovery. J Petrol Explor Prod Technol, vol. 11, pp. 2009 – 2026. https://doi.org/10.1007/s13202-021-01121-5.

PATKIN, A, AL-OBAIDI S., 2001. Influence of temperature and pressure of incoming oil-containing liquid from field wells on the gas separation process. J Petrol Eng Emerg Technol., vol. 3, no. 4, pp. 20 – 24.

PAVLOVA, P. L. et al., 2022. Supercritical Fluid Application in the Oil and Gas Industry: A Comprehensive Review. Sustainability, vol. 14, no. 2, p. 698. https://doi.org/10.3390/su14020698.

POURHADI, S. & FATH, A.H., 2020. Performance of the injection of different gases for enhanced oil recovery in a compositionally grading oil reservoir. J Petrol Explor Prod Technol, vol. 10, pp. 641 – 661. https:// doi.org/10.1007/s13202-019-0723-9.

RUDYK, S., SPIROV, P. & TYROVOLAS, A., 2018. Effect of temperature on crude oil extraction by SC-CO2 at 40 – 70 °C and 40 – 60 MPa, Journal of CO2 Utilization, vol. 24, pp. 471 – 478. https://doi.org/10.1016/j. jcou.2018.02.009.

SHANDRYGIN, A. N. & LUTFULLIN, A., 2008. Main Tendencies of the Sweep Efficiency Improvement Evolution in Russia. Paper presented at the SPE Russian Oil and Gas Technical Conference and Exhibition, Moscow, Russia. https://doi.org/10.2118/117410-MS.

SMIRNOV, V. & AL-OBAIDI, S., 2008. Innovative methods of enhanced oil recovery. Oil Gas Res., vol. 1, no. 1, p. e101. DOI: 10.4172/24720518.1000e10.

SOROKIN, A. et al., 2021. Feasibility of Gas Injection Efficiency for LowPermeability Sandstone Reservoir in Western Siberia: Experiments and Numerical Simulation. Energies, vol. 14, no. 22, p. 7718. https://doi. org/10.3390/en14227718.

TANG, B. et al., 2023. Study on Residual Oil Distribution Law during the Depletion Production and Water Flooding Stages in the Fault-Karst Carbonate Reservoirs. Processes, vol. 11, no. 7, p. 2147. https://doi. org/10.3390/pr11072147.

VERMA, M.K., 2015. Fundamentals of carbon dioxide-enhanced oil recovery (CO2-EOR)—A supporting document of the assessment methodology for hydrocarbon recovery using CO2-EOR associated with carbon sequestration. U.S. Geological Survey Open-File Report. http:// dx.doi.org/10.3133/ofr20151071.

VINOGRADOV, P. V. et al., 2015. Adaptive Approach to Integrated Modeling of Development and Exploitation of Group of Gas-Condensate Fields with a Single Production Gathering and Processing System. Paper presented at the SPE Russian Petroleum Technology Conference, Moscow, Russia, October. https://doi.org/10.2118/176583-MS.

WOJNICKI, M. et al. 2022. An Experimental Investigation of WAG Injection in a Carbonate Reservoir and Prediction of the Recovery Factor Using Genetic Programming. Energies, vol. 15, no. 6, p. 2127. https:// doi.org/10.3390/en15062127.

XUE, L. LIU, P. & ZHANG, Y., 2023. Status and Prospect of Improved Oil Recovery Technology of High Water Cut Reservoirs. Water, vol. 15, no. 7, p. 1342. https://doi.org/10.3390/w15071342.

YONGLE, H. et al., 2019. Technologies and practice of CO2 flooding and sequestration in China Petroleum. Exploration and Development, vol. 46, no. 4, pp. 753 – 766.
