Резюме. TiO\(_{2}\)-M (M = Cd, Co, Mn) were synthesized by sol-gel method using titanium(IV) isopropoxide (TTIP) and cadmium sulfate octahydrate (CdSO\(_{4}\).8H\(_{2}\)O), manganese(II) sulfate monohydrate (MnSO\(_{4}\).H\(_{2}\)O), cobalt(II) sulfate heptahydrate (CoSO\(_{4}\).7H\(_{2}\)O) as precursors. M-doped TiO\(_{2}\) was performed with molar ratio 1:3; 1:2; 1:1; 2:1; 3:1 (mol Ti / mol M) and photocatalytic processes using visible light with irradiation time for 5, 10, 15, 20, 25 and 30 minutes. This study was carried out to determine the effect of different metal ions, the composition of Ti:M and the exposure time on the photocatalytic degradation of methylene blue dye. The results showed that different metal ions influenced crystal size and affected electronic properties (band gap). Crystal size of TiO\(_{2}\) > TiO\(_{2}\)-Mn > TiO\(_{2}\)-Co > TiO\(_{2}\)-Cd and band gap of TiO\(_{2}\) > TiO\(_{2}\)-Cd > TiO\(_{2}\)-Co > TiO\(_{2}\)-Mn. In addition, differences of Ti:M composition also influenced the photocatalytic activity. The longer of applied time exposure, the higher photocatalytic degradation of methylene blue was achieved. The optimum composition of Ti:M was obtained at Ti:M ratio by 3:1 with degradation values by 92.56% (TiO\(_{2}\)-Cd), 90.44% (TiO\(_{2}\)-Co), and 89.42% (TiO\(_{2}\) -Mn).

Ключови думи: methylene blue; metal doping; photocatalytic degradation; TiO\(_{2}\)-M; visible light

Introduction

Indonesia is one of textile industrial based country producing wastewater. Most of wastewater generated from textile industry contain dyes which difficult to eliminate and to degrade. One of dyes often used in textile industry is methylene blue. Methylene blue, one of cationic dyes with chemical formula \(\mathrm{C}_{16} \mathrm{H}_{18} \mathrm{ClN}_{3} \mathrm{~S}\), is frequently employed in cotton, paper and hair dying process (Alzaydien, 2009). This aromatic hydrocarbon compound has strong adsorption and it was categorized as thiazine dyes. It also has toxic properties causing some effects in health, including skin irritation, cyanosis, and gastrointestinal track irritation (Hamdaoui & Chiha, 2007).

Nowadays, the researchers utilized \(\mathrm{TiO}_{2}\) semiconductor to degrade the dyes through photocatalytic, electrocatalyst, and photoelectrocatalyst degradation methods (Hamadanian et al., 2010; Purnawan et al., 2016; Wahyuningsih et al., 2013). The use of photocatalyst material, however, is limited since it only absorbs \(5 \%\) ultraviolet light from sun with broad band gap: \(3.0-3.2 \mathrm{eV}\) (Ni et al., 2007). Thus, modification is required to improve optical property in visible light range.

Modification of \(\mathrm{TiO}_{2}\) can be performed by adding metals or doping metals like transition metals (Binas et al., 2012; Chen et al., 2005; Deng et al., 2011; Purnawan et al., 2016). The addition of metals into \(\mathrm{TiO}_{2}\) semiconductor with increasing concentration caused lowering band gap energy up to visible light absorption area (Ganesh et al., 2012; Tian et al., 2012).

Dopant ion formed electron trapping which it minimizes recombination process between electron and hole. Not only it resulted new band gap, metal doping also accelerated photocatalytic activities (El-Bahy et al., 2009; Zaleska, 2008). Fig. 1 illustrated the effect of metals doping on electron excitation of \(\mathrm{TiO}_{2}\) photocatalyst.

The addition of metals into \(\mathrm{TiO}_{2}\) semiconductor will decrease the particle size of doped semiconductor compared to the origin one. Introducing Cd metal into \(\mathrm{TiO}_{2}\) affected in lowering band gap of \(\mathrm{TiO}_{2} / \mathrm{CdS}\) (Li et al., 2014) and enhanced its photocatalytic activities in visible light (Shi et al., 2012). The decreasing of TiO2012). The decreasing of \(\mathrm{TiO}_{2}\) band gab and enhancing of its photocatalytic activities in visible light was also reported by adding Co (Miao et al., 2014; Yang et al., 2007) and Mn metals (Binas et al., 2012; Deng et al., 2011; Papadimitriou et al., 2011; Wang et al., 2015). The dopant Mn decreased the band gap thus it can be adsorbed the visible light. However, it could defect the \(\mathrm{TiO}_{2}\) crystal and reduce the photocatalytic activities when Mn metal was added in high concentration (Deng et al., 2011).

The \(\mathrm{TiO}_{2}\) doped with \(\mathrm{Mn}(0.1 \%, 1 \%\) and \(5 \%)\) degraded the methylene blue up to \(70 \%\) by irradiating in visible light for 30 minutes (Binas et al., 2012; Papadimitriou et al., 2011). Another researcher, Wang et al. (2015), obtained optimum result by doping \(6 \% \mathrm{Mn}\) to \(\mathrm{TiO}_{2}\). T They also found that by increasing Mn concentration increased the rutile phase which reduce the \(\mathrm{TiO}_{2}\) photocatalytic sensitivity. However, the comparative study of three kind of metals, \(\mathrm{Co}, \mathrm{Cd}\) and Mn, doping \(\mathrm{TiO}_{2}\) is not yet studied. Thus, in this research successfully prepared the \(\mathrm{TiO}_{2}\) doped metals (\(\mathrm{Co}, \mathrm{Cd}\) and Mn) and evaluated their photocatalytic performance on methylene blue degradation.

Experimental

Materials and instrument

All reagents employed in this research were commercially available from E-Merck except mentioned. They were titanium(IV) isopropoxide (TTIP), \(\mathrm{CdSO}_{4} \cdot 8 \mathrm{H}_{2} \mathrm{O}, \mathrm{Mn}\)\(\mathrm{SO}_{4} \cdot 1 \mathrm{H}_{2} \mathrm{O}, \mathrm{CoSO}_{4} \cdot 7 \mathrm{H}_{2} \mathrm{O}\), acetic acid glacial, and ethanol. The methylene blue dye was commercially available from Surakarta, Indonesia. Aquades was purchased from Chemistry Laboratory of Universitas Sebelas Maret. The Instruments used in this study were XRD (X-Ray Diffraction, Bruker), SEM-EDX (Scanning Electron Microscopy – Energy Dispersive X-ray), FTIR (Spektrofotometer Fourier Transform Infrared, Shimadzu 6000) and visible lamp osram ultra vitalux (300W 230V AC).

Synthesis of \(\mathrm{TiO}_{2}\)-M (Cd, Mn, Co)

Titanium (IV) isopropoxide solution was hydrolyzed in acetic acid glacial solution at \(14{ }^{\circ} \mathrm{C}\) with solution ration \(1: 10 \mathrm{v} / \mathrm{v}\). The mixture was stirred continuously until the white and viscous solution achieved. Then, it was heated at \(90^{\circ} \mathrm{C}\) to obtain white gel form. Afterward, each \(\mathrm{CdSO}_{4}, \mathrm{MnSO}_{4}\) or \(\mathrm{CoSO}_{4}\) solutions was added drop wise into \(\mathrm{TiO}_{2}\) gel. The ratio of each metal sulfate toward \(\mathrm{TiO}_{2}\) gel was 1:3, \(1: 2,1: 1,2: 1\) and \(3: 1 \mathrm{~mol} / \mathrm{mol}\). After it was cooled at room temperature, the gel was dried at \(150^{\circ} \mathrm{C}\) for 24 h, then calcined at \(400^{\circ} \mathrm{C}\) at 2 h.

Photocatalytic degradation of methylene blue

Photodegradation of methylene blue was conducted by adding \(0.3 \mathrm{~g} \mathrm{TiO}_{2}-\mathrm{M}\) powder into 30 mL of \(5 \mathrm{mg} . \mathrm{L}^{-1}\) methylene blue solution. Under stirring condition, the mixture was irradiated with visible light in Black Box reactor. The visible light irradiation was carried out at \(5,10,15,20,25\) and 30 minutes. Afterward, the solution was separated using centrifugation at 6000 rpm for around 3 minutes. The solution absorbance was then analyzed using UV-Vis spectrophotometer.

Results and discussion

Characterization of crystal structure and size by XRD

The XRD characterization of \(\mathrm{TiO}_{2}-\mathrm{M}\) was conducted to evaluate crystallinity of \(\mathrm{TiO}_{2}-\mathrm{M}\) powder by comparing the samples diffractogram with JCPDS standard. It was carried out on the \(3: 1\left(\mathrm{TiO}_{2}: \mathrm{M}\right)\) ratio of synthesized \(\mathrm{TiO}_{2}-\mathrm{M}\) at 2 2thetha 15–85 \({ }^{\circ}\). Based on the XRD spectra of \(\mathrm{TiO}_{2}-\mathrm{M}(3: 1)\) showed in Fig. 2 can be seen the primary characteristic peak of \(\mathrm{TiO}_{2}\) at \(2 \theta 25.490^{\circ}, 37.792^{\circ}\) and \(48.043^{\circ}\). T This peak was confirmed as anatase phase corresponding to JCPDS number 78-2486. This anatase peak was also observed in \(\mathrm{TiO}_{2}-\mathrm{Cd}, \mathrm{TiO}_{2}-\mathrm{Co}\) and \(\mathrm{TiO}_{2}-\mathrm{Mn}\) diffractograms.

The addition of metals into \(\mathrm{TiO}_{2}\) influenced the product crystal size. All of the \(\mathrm{TiO}_{2}-\mathrm{M}\) crystal size was lower than \(\mathrm{TiO}_{2}\). Comparing to another \(\mathrm{TiO}_{2}-\mathrm{M}\), the \(\mathrm{TiO}_{2}-\) Cd was the synthesized product having lowest crystal size, as shown in Table 1. This phenomena was also discovered by Deng et al. (2011), where after Mn metals was doped into \(\mathrm{TiO}_{2}\), it resulted 7 nm of \(\mathrm{TiO}_{2}-\mathrm{Mn}\) crystal size.

Morphological study of \(\mathrm{TiO}_{2}\)-M

Morphological study of \(\mathrm{TiO}_{2}-\mathrm{Cd}, \mathrm{TiO}_{2}-\mathrm{Mn}\) and \(\mathrm{TiO}_{2}-\mathrm{Co}\) was conducted at each \(\mathrm{TiO}_{2}: \mathrm{M}\) ratio by \(3: 1\). All of the \(\mathrm{TiO}_{2}-\mathrm{M}\) surface morphology was offered in Fig. 3.

All of the measurement were captured at magnificent 5000x. The morphology of \(\mathrm{TiO}_{2}-\mathrm{M}\) was not significantly different observed in this research. This indicated that the addition of metals was not change the morphology of \(\mathrm{TiO}_{2}-\mathrm{M}\). From the SEM image was calculated the particle size distribution using JImage application. The calculation result gave same values, where the particle size of \(\mathrm{TiO}_{2}-\mathrm{M}\) was distributed in range of \(100-200 \mathrm{~nm}\). Fig. 4 revealed the particle size distribution of each \(\mathrm{TiO}_{2}-\mathrm{M}\).

The SEM-EDAX result showed that the doped metal concentration contained in \(\mathrm{TiO}_{2}-\mathrm{M}\) as presented in Table 2 were 8.62, 3.26 and \(7.21 \%\) for \(\mathrm{Cd}, \mathrm{Co}\) and Mn, respectively. It was mean that the Cd was easily doped into \(\mathrm{TiO}_{2}\) than Co or even Mn.

This was caused by the ionic radius of Cd was higher than Co and Mn, however its covalent radius of ionic hydrant was smaller than others, i.e. \(\mathrm{Cd}(144 \pm 9 \mathrm{pm}) \lt \mathrm{Co}\)

\((150 \pm 7 \mathrm{pm}) \lt \mathrm{Mn}(161 \pm 8 \mathrm{pm})\). Due to it has small covalent radius of ionic hydrant, the Cd ion was readily to bind and to attach into \(\mathrm{TiO}_{2}\) semiconductor.

Band gap energy

The band gap energy was conducted via thin layer method. The \(\mathrm{TiO}_{2}\) and \(\mathrm{TiO}_{2}-\mathrm{M}\) samples was transformed to the transparency film at glass substrate then their absorbance were recorded using UV-Vis spectrophotometer. The band gap was calculated using Touc Plot method, a method to determine band gap using extrapolate from E (eV) versus (Ahv) \({ }^{2}\) as shown in Fig. 5. Based on the Touch Plot graph can be evaluated band gap energy of each samples presented in Table 3.

The addition of metals into \(\mathrm{TiO}_{2}\) triggered the lowering band gap energy as presented in Table 3, the Eg of \(\mathrm{TiO}_{2} \gt \mathrm{TiO}_{2}-\mathrm{Cd} \gt \mathrm{TiO}_{2}-\mathrm{Co} \gt \mathrm{TiO}_{2}-\mathrm{Mn}\). T The band gap energy of \(\mathrm{TiO}_{2}-\mathrm{Mn}\) was lowest to others \(\mathrm{TiO}_{2}-\mathrm{M}\). T This initiated a fast recombination of electron-hole which will inhibit oxidation reaction of methylene blue dye.

FTIR analysis of \(\mathrm{TiO}_{2} \mathrm{M}\)

Analysis of \(\mathrm{TiO}_{2}\)-Cd using FTIR was performed to identify a bonding between \(\mathrm{Ti}-\mathrm{O}\) and Cd as result of Cd addition to \(\mathrm{TiO}_{2}\). In Fig. 6, the synthesized \(\mathrm{TiO}_{2}\) spectra has absorbance bands around \(3405.47 \mathrm{~cm}^{-1}, 1627.99 \mathrm{~cm}^{-1}\) as well as strong and broad band at \(576.74-421.46 \mathrm{~cm}^{-1}\) which they are characteristic band of \(\mathrm{TiO}_{2}\). The wave number at \(3405.47 \mathrm{~cm}^{-1}\) indicated the \(\mathrm{O}-\mathrm{H}\) stretching vibration of water entrapping in \(\mathrm{TiO}_{2}\) structure (Kuvarega et al., 2011). Another characteristic peak of water was also observed around \(1625-1650 \mathrm{~cm}^{-1}\) corresponding to the \(\mathrm{O}-\mathrm{H}\) bending vibration. The vibration of O-Ti-O was also discovered in the IR spectra at around \(609.5-420.5 \mathrm{~cm}^{-1}\) (Wahyuningsih et al., 2013).

The IR spectrum of \(\mathrm{TiO}_{2}-\mathrm{Cd}\) showed the broad absorbance band at around 3400 \(\mathrm{cm}^{-1}\) indicating the O-H stretching vibration (Kuvarega et al., 2011). The water characteristic band was also observed in \(\mathrm{TiO}_{2}\)-Cd IR spectra appearing at \(1600 \mathrm{~cm}^{-1}\) (Li et al., 2011; Wu & Chen, 2004). A new absorbance band also appeared around \(1115-1057 \mathrm{~cm}^{-1}\) indicated the Ti-O-Cd stretching vibration. In addition, the absorbance band around \(540-425 \mathrm{~cm}^{-1}\) corresponding to Ti-O-Cd bending vibration. Both of this peaks were sharpen by decreasing of \(\mathrm{TiO}_{2}: \mathrm{Cd}\) ratio. T This peaks related to the Ti-O-Cd bonding formation as result of Cd insertion in \(\mathrm{TiO}_{2}\).

The two peaks around \(1100 \mathrm{~cm}^{-1}\) and \(980 \mathrm{~cm}^{-1}\) were characteristic peak of TiO-Cd stretching vibration in accordance with what has been done by Ge (2012). Both of that peaks showed different intensity on each \(\mathrm{TiO}_{2}: \mathrm{Cd}\) composition ratio, the more concentration of Cd was added then the peak became sharpen. This also occurred at peak around \(619.18-618.21 \mathrm{~cm}^{-1}\) which corresponding to Cd stretching vibration.

In \(\mathrm{TiO}_{2}-\mathrm{Co}\) IR spectra offered in Fig. 7 revealed a peak at \(1627 \mathrm{~cm}^{-1}\) corresponding to a bending vibration of H-O-H bonding. Peaks around \(600-400 \mathrm{~cm}^{-1}\) was an absorbance band of Ti-O-Ti. It was also exposed a weak and broad band around \(2840 \mathrm{~cm}^{-1}\) becoming strong peak by adding more Co, indicate the OH absorbance band of \(\mathrm{H}_{2} \mathrm{O}\) bonded to \(\mathrm{Co}-\mathrm{O}\). Absorbance band around \(1000-1250 \mathrm{~cm}^{-1}\) was a

characteristic peak of Co evidenced by increasing of its intensity with addition more concentration of Co while weaken by decreasing of Co composition (Ganesh et al., 2012).

A new absorbance band at \(660 \mathrm{~cm}^{-1}\) was found in \(\mathrm{TiO}_{2}-\mathrm{Mn}\) spectra presented in Fig. 8 indicating the \(\beta-\mathrm{MnO}_{2}\) vibration. Moreover, peaks at \(620 \mathrm{~cm}^{-1}\) and \(530 \mathrm{~cm}^{-1}\) was a characteristic vibration of \(\mathrm{O}-\mathrm{Ti}-\mathrm{O}\) and \(\mathrm{Mn}-\mathrm{O}-\mathrm{Ti}\), respectively. Identification of \(\mathrm{MnO}_{\mathrm{x}}\) was difficult to evaluate due to this peak over lapped with other peaks. This was also observed by other researchers (Kernazhitsky et al., 2010; Othman et al., 2007; Šurca et al, 2006). However, a peak around 1140-997 \(\mathrm{cm}^{-1}\) was predicted as \(\mathrm{Mn}-\mathrm{O}\) characteristic absorbance band since its intensity became sharpen at high ratio of Cd.

Photocatalytic degradation of methylene blue

Qualitative analysis of methylene blue using UV-Vis spectrophotometer was conducted to determine its maximum wavelength (\(\lambda_{\text {maks }}\) ). It was scanned in range of \(800 \mathrm{~nm}-350 \mathrm{~nm}\) with methylene blue concentration by \(5 \mathrm{mg} . \mathrm{L}^{-1}\). It was resulted that the maximum wavelength was obtained at 664 nm. This maximum wavelength was then used to identify the decreasing of methylene blue concentration in aqueous solution after photocatalytic degradation carried out.

This research focused to compare the photocatalytic activity of each \(\mathrm{TiO}_{2}-\mathrm{M}\) using visible light at same time and amount. After photocatalytic degradation, it was observed that the absorbance of methylene blue decreased. Photocatalytic degradation is a reaction process involved catalyst assisted with a photon. Fig. 9 showed the degradation result of each \(\mathrm{TiO}_{2}-\mathrm{Cd}\) composition. All of composition revealed that the longer of contact time, the degradation percentages enhanced. They resulted a degradation closing to \(90 \%\) at 30 minutes. The role on photocatalytic degradation was obtained as follow \(\mathrm{TiO}_{2}-\mathrm{Cd}(3: 1) \gt (2: 1) \gt (1: 3) \gt (1: 2) \gt (1: 1)\). T The same pattern was also discovered for \(\mathrm{TiO}_{2}-\mathrm{Co}\) and \(\mathrm{TiO}_{2}-\mathrm{Mn}\) where the highest degradation percentages was achieved at \(\mathrm{TiO}_{2}: \mathrm{M}\) ratio \(3: 1\) while the lowest was at \(1: 1\). The percentage degradation data of \(\mathrm{TiO}_{2}-\mathrm{Co}\) and \(\mathrm{TiO}_{2}-\mathrm{Mn}\) were presented in Fig. 10 and Fig. 11, respectively.

The addition of high concentration of metals caused on decreasing of photocatalytic activity. High metal concentration has high number of defect structure and created more trapper. It triggered a charge carrier generated from energy induction result on \(\mathrm{TiO}_{2}\) photocatalyst can stuck more than one time thus it slow down the mobility and it could undergo a recombination before reaching photocatalyst surfaces. This phenomena initiating at high composition of dopant resulted low degradation percentage compared to a sample added by low composition of dopant.

Based on the experiment result can be revealed that the optimum composition of all \(\mathrm{TiO}_{2}-\mathrm{M}\) was obtained at ratio 3:1. In addition, \(\mathrm{TiO}_{2}-\mathrm{Cd}\) was the best formulation compared to others \(\mathrm{TiO}_{2}-\mathrm{M}\) with degradation percentages of \(92.83 \%\) followed by \(\mathrm{TiO}_{2}-\mathrm{Co}\) and \(\mathrm{TiO}_{2}-\mathrm{Mn}\) which they had degradation percentages of \(91.64 \%\) and \(89.79 \%\), respectively as seen in Fig. 12.

The \(\mathrm{Cd}, \mathrm{Co}\) and Mn have different ionic radius inducing the resulted \(\mathrm{TiO}_{2}-\mathrm{M}\). The ionic radiation of \(\mathrm{Cd}^{2+}\) is larger than \(\mathrm{Co}^{2+}\) and \(\mathrm{Mn}^{2+}\). The metals, which have large ionic radius, were doped into \(\mathrm{TiO}_{2}\) reducing the steric hydrant and make them easily to interact with oxygen thus a bonding with \(\mathrm{TiO}_{2}\) semiconductor was effortlessly achieved. The Mn, however, has small ionic radius causing the entrance to \(\mathrm{TiO}_{2}\) difficult to accomplish due to it has high steric hydrant.

The photocatalytic activity was also influenced by oxidation number where the oxidation number of \(\mathrm{Cd} \lt \mathrm{Co} \lt \mathrm{Mn}\). The more of oxidation number of metals affected the number of species also more diverse thus the formed catalyst became irregular. This generated that \(\mathrm{TiO}_{2}-\mathrm{Mn}\) has low degradation percentages than others. Moreover, the band gap energy of \(\mathrm{TiO}_{2}-\mathrm{Cd} \gt \mathrm{TiO}_{2}-\mathrm{Co} \gt \mathrm{TiO}_{2}-\mathrm{Mn}\) also influenced in the photocatalytic activity because of the broad band gab will slow down electron-hole recombination process. All of that metals have reduction potential, where \(\mathrm{Cd} \lt \mathrm{Co} \lt \mathrm{Mn}\). The lower of their reduction potential, the more easily they oxidized and more stable in excitation state thus the number of empty orbital as an electron trap increased and recombination process became longer.

Photocatalyst degradation process was determined by reaction rate constant values (k) to identify the reaction kinetic on methylene blue degradation following first, second and third order reaction using Eqs. (1-3), respectively. From the first, second and third order reaction graphs was pointed the linearity value \(\left(\mathrm{R}^{2}\right)\). The \(\mathrm{R}^{2}\) value closing to 1 showed the occurring order reaction and degradation of methylene blue. The k and R value of TiO\(_{2}\)-M was presented in Table 4.

(1) \[\ln C=-k \cdot t+\ln C o \]

(2) \[ \tfrac{1}{C}=k \cdot t+\tfrac{1}{C o} \]

(3) \[\tfrac{1}{c^{2}}-\tfrac{1}{C o^{2}}=2 k \cdot t \]

Conclusion

Synthesis of \(\mathrm{TiO}_{2}\) and \(\mathrm{TiO}_{2}-\mathrm{M}(\mathrm{M}=\mathrm{Cd}, \mathrm{Co}\) and Mn\()\) have been successfully conducted through sol-gel method. The addition of metals influenced on not only the \(\mathrm{TiO}_{2}\) crystal growth but also the material electronic properties (\(\mathrm{Eg} \mathrm{TiO}_{2}=3,35\) \(\mathrm{eV} ; \mathrm{TiO}_{2}-\mathrm{Cd}=3,15 \mathrm{eV} ; \mathrm{TiO}_{2}-\mathrm{Co}=3 \mathrm{eV}\) dan \(\mathrm{TiO}_{2}-\mathrm{Mn}=2,5 \mathrm{eV}\) ). The more metals ion doped into \(\mathrm{TiO}_{2}\) semiconductor affected on decreasing of photocatalytic activity. It was revealed that the optimum composition of \(\mathrm{TiO}_{2}-\mathrm{M}\) was obtained at \(\mathrm{TiO}_{2}: \mathrm{M}\) ratio by \(3: 1\). The \(\mathrm{TiO}_{2}-\mathrm{Cd}\) optimum photocatalytic degradation value was \(92.56 \%\) followed by \(\mathrm{TiO}_{2}-\mathrm{Co}(90.44 \%)\) and \(\mathrm{TiO}_{2}-\mathrm{Mn}(89.42 \%)\) making it to be the best \(\mathrm{TiO}_{2}-\mathrm{M}\) composition compared to others.
