Резюме. The previously reported 6-amino-4-(4-chlorophenyl)-3-methyl-1,4dihydropyrano [2, 3-c] pyrazole-5-carbonitrile 1 was prepared and utilized as a precursor for novel heterocycles such as Benzoxazinone 4, Pyrazolopyranopyrimidines 8, 9, 12, 13 and 20 tetrazolopyrimidine 15 and triazolopyrimidine 16 with anticipated antimicrobial activity. The structural features of these novel heterocycles were characterized and confirmed by their spectral analysis as well as elemental analyses.

Ключови думи: pyrazolopyranooxazinones; pyranopyrimidines; triazolopyrimidines tetrazolopyrimidines and pyrazolopyranopyrimidinthion

Introduction

In recent years, the pyrazole fused heterocycles such as pyrano[2,3-c] pyrazole derivatives are known to possess diverse biological activities as anticancer (Han et al., 2015),antibacrerial and anti-infalmatoryactivites (Santhosh et al., 2012). The literature survey reveals that numerous condensed pyrazole derivatives have been synthesized and advanced to clinic studies with various biological activities (Duan et al., 2014). Pyrrolo[3,4-c] pyrazol-4(1H)-one derivatives have been reported to exhibitanti BVDV activity (Fargualy et al., 2013). Many substituted pyranopyrazoles are known to possess diverse biological activities as new neuropeptide S receptor antagonists (Batran et al., 2017), antitubercular and antimicrobial (Kamdar et al., 2010), antioxidant (Saundane et al., 2013). The fused pyrimidine derivatives have been constructed and evaluated their antimicrobial activity (Mahmoud et al., 2012; 2013). Bezoxazinones are one of the important ring systems that have drawn the attention for their different biological activities (Gao et al., 2017; Piecyk et al., 2017; Martinand-Lurin et al., 2014).Some pyranotriazolopyrimidine derivatives were synthesized and their antigenotoxic activity were tested in Escherichia coli PQ37 by using the SOS chromotest (Chabcloub, 2007).Based on these findings, it was of interest to synthesis newheterocyclic compounds such as Benzoxazinone 4, Pyrazolopyranopyrimidines 8, 9, 12, 13 and 20 tetrazolopyrimidine 15 and triazolopyrimidine 16 with anticipated antimicrobial activity..

Experimental

All the chemicals that we used in this paper are of high purity and have been purchased from Al-Gomhouria Company - Cairo – Egypt. All melting points were measured on a Gallenkamp electric melting point apparatus and are uncorrected. The infrared spectra were recorded in potassium bromide disks on a PyeUnicam SP-3-300 and Shimdazu FT IR 8101 PC Infrared spectrophotometers. The1HNMR was recorded on a Varian Mercury VX-300 NMR spectrometer. 1HNMR spectra were run at 300 MHz and on a Varian Gemini 200 MHz, Brucker AC-200 MHz using TMS as internal standard in deuterated chloroform (CDC13) or deuterateddimethylsulphoxide (DMSO-d6). Chemical shifts are quoted in δ and were related to that of the solvents. The mass spectra were recorded on a Shimadzu GCMS-QP1OOOEX mass spectrometer at 70 eV. Elemental analyses were carried out at the Microanalytical Center of Cairo University. All the reactions and the purity of the new compounds were followed and cheeked by TLC.

2-((4-(4-chlorophenyl)-5-cyano-3-methyl-1,4-dihydropyrano[2,3-c]pyrazol-6yl)amino)-2-oxoacetylchloride (2)

A mixture of 6-amino-4-(4-chlorophenyl)-3-methyl-1,4-dihydropyrano[2,3c] pyrazole-5-carbonitrile (1) (1.43gm, 0.005 mole) in dry toluene (50 mL) and oxalyl chloride (1 gm, 0.0075 mole) was refluxed on a hot plate for 2 hours, excess toluene and oxalyl chloride was removed under reduced pressure, the formed semisolid was washed three times with dry toluene and evaporated under reduced pressure. The semisolid remains after evaporation was allowed to react directly with the appropriate alcohol or amine in some coming reactions.

2-(2-((4-(4-chlorophenyl)-5-cyano-3-methyl-1,4-dihydropyrano[2,3-c]pyrazol6-yl)amino)-2-oxoacetamido) benzoic acid(3)

A mixture of 2-((4-(4-chlorophenyl)-5-cyano-3-methyl-1,4-dihydropyrano[2,3-c]pyrazol-6-yl)amino)-2-oxoacetyl chloride (2) (1.9 gm, 0.005 mole) and anthranilic acid (1.4 gm, 0.01 mole) was added to dry pyridine (25 mL) and refluxed for 2 hours, the solvent then removed under reduced pressure, the formed solid collected and crystallized from ethanol / acetic acid (drops), to give (3) , as yellow crystals, M.p.: 288-290ºC, yield 60%. Anal. Calcd. for C23H16N5ClO5 (477.9) C, 57.81; H,3.37; N, 14.66; Cl, 7.42. Found: C, 57.73; H, 3.44; N, 14.59; Cl, 7.33. IR (υ/cm-1): 3379, 3266 and 3119 (NH amide and NH pyrazole), 2217 (C≡N), 1681 and 1632 (C=O). MS m/z (%):478 (70.2%), 432 (50%), 353 (62.9%), 254 (52.4%), 239 (100%), 190 (53.2%) and 147 (76.6%). 1HNMR (DMSO-d 6) δ (ppm): 12.77 (s, 2H, NH amide exchangeable with D2O), 10.59 (s, 1H, NH pyrazole exchangeable with D2O), 8.71 (s, 1H, OH carboxylic exchangeable with D2O) 8.10-7.25 (m, 8H, ArH), 4.80 (s, 1H, benzylic H) and 1.87 (1s, 3H, CH3).

4-(4-chlorophenyl)-3-methyl-7-(4-oxo-4H-benzo[d][1,3]oxazin-2-yl)-1H-pyrazolo[4’,3’:5,6] pyrano[2,3-d][1,3] oxazin-5(4H)-one(4)

A mixture of 2-(2-((4-(4-chlorophenyl)-5-cyano-3-methyl1,4-dihydropyrano[2,3-c]pyrazol-6-yl)amino)-2-oxoacetamido)benzoic acid (3) and acetic anhydride (25 mL) are refluxed for 8 hours, the excess anhydride then removed under reduced pressure, the formed solid collected and crystallized from ethanol / acetic acid (drops), to give (4) , as yellow crystals, M.p.:>300ºC, yield 40%. Anal. Calcd. for C23H13N4ClO5 (460.8) C, 59.95; H,2.84; N, 12.16; Cl, 7.69. Found: C, 60.07; H, 2.77; N, 12.26; Cl, 7.60. IR (υ/cm-1): 3268 (NH pyrazole), 1765 (C=O),1628 (C=N). MS m/z (%):461 (61.2%), 322 (92.2%), 246 (100%), 177 (2.91%), 174 (13.6%) and 136 (7.8%) . 1HNMR (DMSO-d6) δ (ppm): 12.69 (s, 1H, NH pyrazole exchangeable with D2O), 8.25-7.32 (m, 8H, ArH), 5.11 (s, 1H, benzylic H) and 1.90 (s, 3H, CH3).

Methyl 2-((4-(4-chlorophenyl)-5-cyano-3-methyl-1,4-dihydropyrano[2,3-c] pyrazol-6-yl)amino) -2-oxoacetate(5) and Ethyl 2-((4-(4-chlorophenyl)-5-cyano-3-methyl-1,4-dihydropyrano [2,3-c]pyrazol-6-yl) amino)-2-oxoacetate(6)

2-((4-(4-chlorophenyl)-5-cyano-3-methyl-1,4-dihydropyrano[2,3-c]pyrazol-6 yl)amino)-2- oxoacetyl chloride (2) (1.9 gm, 0.005 mole) was added to dry methanol and/or dry ethanol (50 mL) and refluxed for 30 minutes , the solvent then removed under reduced pressure, the formed solid collected and crystallized from ethanol / acetic acid (drops), to give (5) , as yellow crystals, M.p.:>300 ºC, yield 75%. Anal. Calcd. for C 17H13N 4ClO4 (372.8) C, 54.78; H, 3.52; N, 15.03; Cl, 9.51. Found: C, 54.71; H, 3.50; N, 14.92; Cl, 9.45. IR (υ/cm 1(ν/cm-1) at: 3373 and 3207 (NH amide and NH pyrazole), 2217 (C≡N), 1723 and 1649 (C=O)MS m/z (%):M∙+ at m/e 372.8 (not observed), 357 (69.5%), 264 (74.7%), 261 (100%), 218 (63.2%) and 96 (25.3%) 1HNMR (DMSO-d6) δ (ppm): 12.21 (s, 1H, NH pyrazole exchangeable with D 2O), 10.25 (s, 1H, NH amide exchangeable with D2O), 7.43-7.17 (m, 4H, ArH), 5.01 (s, 1H, benzylic H), 1.91 and 1.84 (2s, 6H, 2CH 3 )and (6) , as yellow crystals, M.p.:>300 ºC, yield 70%. Anal. Calcd. for C 18H15N4ClO4 (386.8) C, 55.89; H,3.91; N, 14.49; Cl, 9.17. Found: C, 55.94; H, 3.82; N, 14.40; Cl, 9.24.IR (υ/cm -1): 3196 and 3121 (NH amid and NH pyrazole), 2217 (C≡N), 1725 and 1647 (C=O)MS m/z (%):386.8 (not observed), 372 (56.9% relative abundance), 312 (55.9%), 235 (100%), 189 (69.6%) and 120 (26.5%) 1HNMR (DMSO-d6) δ (ppm): 12.24 (s, 1H, NH pyrazole exchangeable with D2 O), 11.0 (s, 1H, NH amide exchangeable with D2O), 7.46-7.20 (m, 4H, ArH), 4.85 (s, 1H, benzylic H), 1.96 (q, 2H, CH2), 1.85 (s, 3H, CH 3pyrazole) and 1.30 (t, 3H, CH 3 ).

4-(4-chlorophenyl)-5-hydroxy-3-methyl-4,8-dihydropyra-zolo[4’,3’:5,6] pyrano[2,3-d] pyrimidin-7(1H)-one (8) and 4-(4-chlorophenyl)-5-hydroxy-3-methyl-4,8- dihydropyrazolo[4’,3’:5,6]pyrano[2,3-d]pyrimidine-7(1H)-thione (9)

A mixture of 6-amino-4-(4-chlorophenyl)-3-methyl-1,4-dihydropyrano[2,3c] pyrazole-5-carboxamide (7) (1.5 gm, 0.005 mole) , urea (0.3gm, 0.005 mole) and / or thiourea (0.4 gm, 0.005 mole) in dry toluene (50 mL)was refluxed on a hot plate for 24 hours. The excess solvent was removed under vacuum; the solid remained was crystallized from ethanol / acetic acid (drops) to give (8) as yellow crystals, M.p.:>300 ºC, yield 70%. Anal. Calcd. for C15H11N4ClO3 (330.7) C, 54.47; H,3.35; N, 16.94; Cl, 10.72. Found: C,54.53; H,3.42; N, 16.87; Cl, 10.79. IR (υ/cm-1): 3308, 3157 (OH & NH), 1729 (C=O), 1655 (C=N) MS m/z (%):331 (1.14%), 246 (2.83) 221 (30.6%) and 111 (1.03%). 1HNMR (DMSO-d6) δ (ppm): 12.15 (s, 1H, NH pyrazole exchangeable with D2O), 7.63-7.18 (m, 4H, ArH), 6.94 (s, 2H, 2OH exchangeable with D2O), 4.63 (s, 1H, benzylic H), 1.79 (s, 3H, CH3). and (9) as yellow crystals, M.p: 224-226 ºC, yield 70%. Anal. Calcd. C15H11N4SClO2 (346.8) C, 51.95; H,3.20; N, 16.16; Cl, 10.22; S,9.25 Found: C,51.87; H, 3.29; N, 16.10; Cl, 10. 30; S,9.17. IR (υ/cm-1): 3340 and 3166 (OH and NH), 1089 (C=S). MS m/z (%):345 (1.26% relative abundance), 268 (34.9) 236 (9.75%), 143 (5.03%). 1HNMR (DMSO-d6) δ (ppm): 11.0 (s, 1H, NH pyrazole exchangeable with D2O), 7.38-7.05 (m, 4H, ArH), 6.92 (s, 2H, SH, OH exchangeable with D2O), 5.06 (s, 1H, benzylic H) and 1.90 (s, 3H, CH3 ).

4-(4-chlorophenyl)-3-methyl-1,4-dihydropyrazolo[4’,3’:5,6]pyrano[2,3-d]pyrimidin-5-ol (10)

A mixture of 4-(4-chlorophenyl)-3-methyl-4,6-dihydropyrazolo[4’,3’:5,6] pyrano[2,3-d] pyramidin5(1H)-one (7) (1.5 gm, 0.005 mole) and formamide (20mL) was refluxed with stirring on a hot plate with magnetic stirrer at 120oC for 2 hours. The reaction mixture was poured after cooling into water and crushed ice; the solid formed was filtered off, washed with cold water and crystallized from dilute ethanol to give (10) as white crystals, M.p.: 236-238 ºC, yield 84%. The structure of 10 has been confirmed by comparison with the previously prepared from the reaction of 7 with formic acid (El-Ziaty et al., 2014).

5-chloro-4-(4-chlorophenyl)-3-methyl-1,4-dihydropyrazolo[4’,3’:5,6] pyrano[2,3-d]pyrimidine (11)

A mixture of well-dried 4-(4-chlorophenyl)-3-methyl-4,6-dihydropyrazolon [4’,3’:5,6] pyrano[2,3-d]pyrimidin-5(1H)-one (10) (1.6 gm, 0.005 mole) and phosphorous oxychloride (20 mL) was refluxed on boiling water bath for 2 hours, after completion the excess phosphorous oxychloride was almost evaporated under reduced pressure, the remained mixture was dded gradually with vigorous stirring to crushed ice, the solid formed was filtered off immediately and washed with cold water, then crystallized from ethanol to give (11) as yellow crystals, M.p: 261264 ºC, yield 40%. Anal. Calcd. C15H10N4Cl2O (333.2) C,54.07; H,3.03; N, 16.82; Cl, 21.28. Found: C,53.95; H,3.10 N, 16.89; Cl, 21.20. IR (υ/cm-1): 3303 (NH), 1650 (C=N) MS m/z (%):332 (7.9%), 293 (7.9%), 261 (8.29%), 166 (1.46%), 165 (0.77%). 1HNMR (DMSO-d6) δ (ppm): 11.0 (s, 1H, NH pyrazole exchangeable with D2O), 7.15-7.06 (m, 5H, 4ArH and pyrimidine H), 4.26 (s, 1H, benzylic H), 1.98 (s, 3H, CH3).

4-(4-chlorophenyl)-5-hydrazinyl-3-methyl-1,4-dihydropyrazolo[4’,3’:5,6] pyrano[2,3-d] pyramidne (12)

A mixture 5-chloro-4-(4-chlorophenyl)-3-methyl-1,4-dihydropyrazolo[4’,3’:5,6]pyrano [2,3-d] pyrimidine (11) (1.7gm, 0.005 mole) in ethanol (50 mL) and hydrazine hydrate (0.3 gm, 0.006 mole) was refluxed on hot plate for 4 hours. After reaction completion the excess ethanol was removed under vacuum to dryness. The solid remained was dissolved in minimum amount of ethanol, then poured into crushed ice, the solid formed was filtered off, washed with cold water and crystallized from ethanol to give (12) as white crystals, M.p.: 222-224 ºC, yield 60%. Anal. Calcd. C15H13N6ClO (328.8) C,54.80; H,3.99; N, 25.56; Cl, 10.78. Found: C,54.71; H,4.07 N, 25.48; Cl, 10.75. IR (υ/cm-1): 3411 and 3257 (NH & NH2), 1666 (NH2 bending). MS m/z (%):329 (13.6%), 206 (1.1) 188 (4.3%), 174 (2.7%) and 126 (13.1%). 1HNMR (DMSO-d6) δ (ppm): 10.2 (s, 1H, NH pyrazole exchangeable with D2O), 7.23-7.21 (m, 4H, ArH), 7.20 (m, 2H, NHNH2 exchangeable with D2O), 7.03 (s, 1H, pyrimidine -H), 6.85 (s, 1H, NHNH2 exchangeable with D2O), 4.27 (s, 1H, benzylic H), 2.11 (s, 3H, CH3).

4-(4-chlorophenyl)-5-ethoxy-3-methyl-1,4-dihydropyra zolo[4’,3’:5,6]pyrano [2,3-d] pyrimidine (13)

A mixture of 5-chloro-4-(4-chlorophenyl)-3-methyl-1,4-dihydropyrazolo[4’,3’:5,6]pyrano [2,3-d]pyrimidine (11) (1.7gm, 0.005 mole) and sodium ethoxide solution (0.5 gm sodium metal dissolved in 30 mL of dry ethanol) was refluxed for 4 hours, the mixture then cooled and neutralized with dilute acetic acid then poured to crushed ice, the formed solid is filtered off and washed with cold water, crystallized from ethanol to give (13) as white crystals, M.p: 239-241 ºC, yield 50%. Anal. Calcd. C17H 15N4ClO2 (342.8) C, 59.57; H,4.41; N, 16.34; Cl, 10.34. Found: C,59.66; H,4.50;N,16.30; Cl, 10.26. IR (υ/cm-1): 3306 (NH),1628 (C=N). MS m/z (%):343 (0.13%), 221 (100%) 222 (15.2%), 206 (0.3%), 140 (3.1%), 139 (3.0%) and 124 (1.0%). 1HNMR (DMSO-d6) δ (ppm): 11.8 (s, 1H, NH pyrazole exchangeable with D2O), 7.3-7.22 (m, 4H, ArH), 7.06 (s, 1H, pyrimidine -H), 4.39 (m, 3H, -CH2CH3 and benzylic H), 2.05 (m, 3H, -CH2CH3), 1.09 (m, 3H, CH3 pyrazole).

11-(4-chlorophenyl)-5,10-dimethyl-8,11-dihydropyrazolo[4’,3’:5,6] pyrano[3,2-e]tetrazolo[1,5-c]pyrimidine (15)

(0.68gm, 0.002 mole) of 4-(4-chlorophenyl)-5-hydrazino-3,7-dimethyl-1,4-dihydropy- razolo[4’,3’:5,6]pyrano[2,3-d] pyrimidine (14) was dissolved in 10 mL concentrated hydrochloric acid and 5 mL acetic acid at 0 oC, the mixture was stirred in ice bath and 10 mL of 5% sodium nitrite was added gradually on 30 minutes interval. After addition completion the mixture was stirred further for another 1 hour at room temperature, and then the mixture was diluted with water and crushed ice. The solid formed was filtered off, washed with cold water and crystallized from dilute ethanol to give (15) as yellow crystals, M.p.: 240-243ºC, yield 65%. Anal. Calcd. C 16H12N7ClO (353.8) C, 54.32; H,3.42; N, 27.72; Cl, 10.02. Found: C,54.40; H,3.33 N, 27.61; Cl, 10.16. IR (υ/cm-1): 3202 (NH) and 1638 (C=N). MS m/z (%):354 (4.2%), 275 (6%), 235 (15.8%), 83 (100%), 110 (14%), 245 (12.4%), 136 (19.6%), 111 (27%), 298 (9%), 256 (23.4%) and 190 (9.4%). 1HNMR (DMSO-d6) δ (ppm): 10.21 (s, 1H, NH pyrazole exchangeable with D2O), 7.43-7.38 (m, 4H, ArH), 4.61 (s, 1H, benzylic H), 2.0 (s, 6H, 2CH3) .

11-(4-chlorophenyl)-5,10-dimethyl-3-phenyl-8,11 dihydropyrazolo[4’,3’:5,6] pyrano[3,2-e][1,2,4]triazolo[4,3-c] pyrimidine (16)

A mixture of 4-(4-chlorophenyl)-5-hydrazino-3,7-dimethyl-1,4-dihydropyrazolo [4’,3’:5,6]pyrano[2,3-d] pyrimidine (14) (0.68gm, 0.002 mole) and benzoyl chloride (0.28 gm, 0.002 mole) in toluene (10 mL) was refluxed on hot plate for 24 hours. After reaction completion the excess toluene was removed under vacuum to dryness. The solid remained was dissolved in minimum amount of ethanol, then poured into water with crushed ice, the solid formed was filtered off, washed with cold water and crystallized from dilute ethanol to give (16) as yellow crystals, M.p.: 179-182ºC, yield 50%. Anal. Calcd. C23 H17N6ClO (428.9)C, 64.41; H,4.00; N, 19.60; Cl, 8.27. Found: C,64.30; H,3.95 N, 19.71; Cl, 8.35. IR (υ/cm -1): 3427 (NH) and 1220(C=N). MS m/z (%):430 (8.7%), 318 (42.9%), 113 (100%), 338 (46.8%), 324 (30.8%), 285 (33.3%), 176 (74%), 304 (13.9%), 238 (47.8%), 203 (28.4%) and 226 (39.7%). 1HNMR (DMSO-d6) δ (ppm): 11.68 (s, 1H, NH pyrazole exchangeable with D2O), 7.93-7.26 (m, 9H, ArH), 4.20 (s, 1H, benzylic H), 2.04 & 2.0 (2s, 6H, 2CH3).

1-acetyl-4-(4-chlorophenyl)-3,7-dimethyl-4,6-dihydro pyrazolo[4’,3’:5,6] pyrano[2,3-d]pyrimidin-5(1H)-one (18)

A mixture of 1-acetyl-4-(4-chlorophenyl)-3,7-dimethyl-1,4-dihydro-5H-pyrazolo[4’,3’:5,6] pyrano[2,3-d][1,3]oxazin-5-one (17) (1.85gm, 0.005 mole) in formamide (20 mL) was refluxed on a hot plate at 120 oC for 2 hours, then the reaction mixture is poured into crushed ice, the solid formed then filtered, dried and crystallized from ethanol to give (18) , as yellow crystals, M.p.:>300 ºC, yield 45%. Anal. Calcd. C 18H15N4 ClO3 (370.8) C, 58.31; H,4.08; N, 15.11; Cl, 9.56. Found: C,58.40; H,3.93 N, 15.03; Cl, 9.16. IR (υ/cm-1): 3406, 3202 (OH and NH) and 1657 (C=O) 1608 (C=N). MS m/z (%): m/e 371 (69.8%), 243 (100%), 328 (13.9%) and 264 (44.2%). 1HNMR (DMSO-d6) δ (ppm): 9.13 (s, 1H, NH pyrimidine exchangeable with D 2O), 7.30-7.18 (m, 4H, ArH), 4.98 (s, 1H, benzylic H), 2.85, 2.27 and 1.91 (3s, 9H, 3CH3) .

N-(1-acetyl-4-(4-chlorophenyl)-5-(hydrazinecarbonyl)-3-methyl-1,4-dihydropyrano[2,3-c]pyrazol-6-yl)acetamide(19)

A mixture of 1-acetyl-4-(4-chlorophenyl)-3,7-dimethyl-1,4-dihydro-5H-pyrazolo[4’,3’:5,6] pyrano[2,3-d][1,3]oxazin-5-one (17) (1.85gm, 0.005 mole) in ethanol (50 mL) and hydrazine hydrate (0.3gm, 0.006 mole) was refluxed on a hot plate for 2 hours, the solid formed on hot is filtered, dried and crystallized from ethanol / acetic acid (drops) to give (19) , as yellow crystals, M.p.:>300 ºC, yield 60%. Anal. Calcd. C18H18N5ClO4 (403.8) C, 53.54; H,4.49; N, 17.34; Cl, 8.87. Found: C,53.30; H,4.83 N, 17.21; Cl, 8.78. IR (υ/cm-1): 3425 and 3273 (NH2), 3199 (NH amide), 1663 and 1610 (C=O) MS m/z (%):404 (69% relative abundance), 264 (76.3%), 153 (100%) and 143 (72.6%) 1HNMR (DMSO-d6) δ (ppm): 9.4 and 9.13 (2s, 2H, 2NH amide exchangeable with D2O), 7.33 (s, 2H, NH2 exchangeable with D2O), 7.31-7.17 (m, 4H, ArH), 4.98 (s, 1H, benzylic H), 2.27, 1.96 and 1.91 (3s, 9H, 3CH3).

Results and discussion

In our continuous interest in the synthesis and evaluation the biological and pharmaceutical activities of heterocyclic compounds (El-Ziaty et al., 2012; 2014; 2016; 2017; Shiba et al., 2008; Abou-Elmagd et al., 2015; Mahmout et al., 2013b; El-Shahawi et al., 2016; El-Shahawi & El-Ziaty, 2017).The previously reported 6-amino-4-(4-chlorophenyl)-3-methyl-1,4-dihydro-pyrano[2,3-c] pyrazole-5-carbonitrile 1 (El-Zitay et al., 2014) was prepared and utilized as building block for novel heterocycles such as benzoxazinone derivative 4 which constructed by acetylation followed by dehydration and cyclization of the amide derivative 3. The structure feature of the benzoxazinone derivative 4 was elucidated from its elemental and spectral analysis such as its I.R spectrum showed no signal corresponding to the cyano group and showed a sharp signal at 1765 cm-1 for the lactonic carbonyl group. The mass spectrum also elucidates the structure of 4, it exhibited the molecular ion peak at 461(61%). The amide derivative 3 was prepared in situ from the reaction of the 2-oxoacetyl chloride derivative 2 with anthranilic acid in dry pyridine as a solvent. It is worth to be mentioned that, the 2-oxoacetyl chloride derivative 2 was prepared by treatment of the enaminonitrile1 with oxalyl chloride and we could not separate it. The structure of 2 was confirmed chemically by esterification with anhydrous alcohol afforded the esters 5, 6, (Scheme 1). The structure of 5,6 were confirmed from the spectral analysis. The I.R. spectrum showed signals at 1723 cm-1and 1725cm-1for the ester carbonyl group. also their 1HNMR showed the signals at 1.96 ppm (q, 2H, CH 2) and 1.30 (t, 3H, CH 3) corresponding to the ethyl group in compound 6.

Partial hydrolysis of the enaminonitile 1 by conc. Sulfuric acid afforded the well-known amid derivative 7, (Ziaty et al., 2014) which allowed reacting with urea and thiourea to give the pyrazolopyranopyrimidinone 8 and pyrazolopyranopyrimidinthion 9, respectivelly.

The amid derivative 7 was allowed to react with formamide to give the reported pyrazolopyranopyrimidine10 which structure was elucidated authentically with the previously prepared from the reaction of 1 with formic acid (El-Shahawi& El-Ziaty, 2017). Chlorination of 10 with a mixture of phosphorous oxychloride and phosphorus pentachloride afforded the chloropyrimidine derivative 11, which utilized as a precursor to the hydrazinopyrimidine12 and the ethoxypyrimidine 13 by reaction with hydrazinhydrate and/or sodethoxide respectivlly.

Aiming to construct novel triazolo and tetrazolopyrimidine derivatives 15 and 16, the enaminonitile derivative 1 was allowed to react with triethylorthacetate followed by hydrazinolysis to give the well-known hydrazinopyrimidine derivative 14 24 (El-Ziaty et al., 2017), [Scheme 2.] Treatment of 14 with nitrous acid afforded the tetrazolopyrimidine derivative 15 which structure was confirmed from the spectral analysis, the I.R spectrum showed no signal for the amino group also1HNMR lacks to the acidic protons of NH2.the mass spectrum also confirms the structure of 15, it exhibited the molecular ion peak at 354 (402%). Benzoylation of 14 by benzoyl chloride afforded the triazolopyrimidine derivative 16which structure was elucidated from the 1HNMR spectra which showed extra 5H arom. at 7.93-7.26 ppm. and the mass spectrum showed the molecular ion peak M+. at 430(8.9%).

Acetylation of the enaminonitle derivative 1 by acetic anhydride afforded the reported pyrazolopyranooxazinone derivative 17 (El-Ziaty et al., 2014). Reaction of the benzoxazinone derivative 17 with formamide gave the corresponding pyrazolopyranopyrimidine derivative 18. The structure feature of 18, was confirmed from the spectral analysis, the I.R. spectrum showed no signal characteristic of the lactonic carbonyl group and shoed the new signal at 1657cm-1 of the cyclic amide carbonyl group. Also the 1 HNMR spectrum showed a strong peak at 9.13ppm for the NH of the pyrimidine moiety. hydrazinolysis of 17 yielded the hydrazide derivative 19 instead of the aminopyrazolopyranopyrimidine19, Scheme 3 the structure of 20 was elucidated from the spectral and elemental analysis.

Conclusion

In conclusion, we have presented novel heterocycles with anticipated biological and pharmaceutical activates from readily available simple raw materials.

REFERENCES

Abou-Elmagd, W.S.I., El-Ziaty, A.K. &Abdalha, A.A. (2015). Ring transformation and antimicrobial activity of indolyl-substituted 2(3H)-furanones, HeterocyclicComm., 21, 179 – 185.

Batran, R.Z., Dawood, D.H., El-Seginy, S.A., Maher, T.J., Gugnani, K.S. &Rondón-Ortiz, A.N. (2017). Coumarinylpyranopyrimidines as new neuropeptide S receptor; design, synthesis, homology and molecular docking. Bioorg. Chem. 75, 274 – 290.

Chabcloub, F., Messaâd, M., Mansour, H.B., Chekir-Ghedira, L. & Salem, M. (2007). Synthesis and antigenotoxic activity of some naphtho[2,1b]pyrano[3,2-e][1,2,4]triazolo[1,5-c]pyrimidine derivativesEur. J. Med. Chem. , 42, 715 – 718

Duan, J.-T., Sang, Y.-L., Makawana, J.A., Teraiya, S.B., Yao, Y.-F., Tang, D.-J., Tao, X.-X. & Zhu, H.-Y. Discovery and molecular modeling of novel 1-indolyl acetate – 5-Nitroimidazole targeting tubulin polymerization as antiproliferative agents. Eur. J. Med. Chem.,85, 311 – 340.

El-Shahawi, M.M. & El-Ziaty, A.K. (2017). Enaminonitriles as building block in heterocyclic synthesis: synthesis of novel 4H-furo[2,3-d][1,3] oxazin-4-one and furo[2,3-d]pyrimidin-4(3H)-one derivatives as antimicrobial agents. J. Chem., 2017, art. no. 5610707.

El-Shahawi, M.M., El-Ziaty, A.K., Morsy, J.M. & Aly, A.F. (2016). Synthesis and insecticidal efficacy of novel bisquinazolinonederivatives. J. Heterocyclic Chem.,53, 1443 – 1448.

El-Ziaty, A’K. &Shiba, S.A. (2007). Antibacterial activities of new (E) 2-cyano-3-(3`,4`-dimethoxyphenyl) -2-propenoylamide derivatives. Synth. Comm.,37, 4034 – 4057.

El-Ziaty, A.K., Abdalh, A., Hamed, A., Shiba, S. &Abdullha, A. (2012). Synthesis of novel 2-propenoyl amides, esters, heterocyclic compounds and their screening as antifungal and antibacterial agents. Eur. J. Chem.,3, 65 – 70.

El-Ziaty A.K., Mostafa, O.E.A., EL-Bordany, E.A., Nabil, M. & Madkour, H.M.F. (2014). Access to new pyranopyrazoles and related heterocycles. Int. J.Sci. & Eng. Res., 5, 727 – 735.

El-Ziaty, A.K., Bassioni, G., Hassan, A.M.A., Derbala, H.A. & Abdel-Aziz, M.M. (2016). A synthetic approach to pyrazolopyranopyrimidinone and pyrazolopyranooxazi- nones as antimicrobial agents. J. Chem., 2016, art.no. 5286462.

El-Ziaty, A.K., Abou-Elmagd, W.S.I., Ramadan, S.K. & Hashem, A.I. (2017). Synthesis and biological screening of some chromonylsubstituted heterocycles derived from 2(3H)-furanone derivative Synth. Comm., 47, 471 – 480.

Fargualy,A.M.,Habib, N.S.,Ismail, K.A., Hassan, A.M.M. & Sang, M.T.M.(2013).Synthesis, biological evaluation and molecular docking studies of some pyrimidine derivatives. Eur. J. Med. Chem., 66, 276 – 295.

Gao, B., Chen, K., Bi, X. &Wang, J. (2017).Intramolecular functionalization of C(sp3) H bonds adjacent to an amide nitrogen atom: metal-free synthesis of 2-hydroxy-benzoxazinone derivatives Tetrahedron,73, 7005 – 7010.

Han, C., Guo, Y.-C., Wang, D.-D., Dai, X.-J., Wu, F.-J., Liu, H.-F., Dai, G.F. & Tao, J.-C. (2015). Novel pyrazole fused heterocyclic ligands: synthesis, characterization, DNA binding/cleavage activity and anti-BVDV activity. Chinese Chem. Lett., 26, 534 – 538.

Kamdar, N.R., Haveliwala, D.D., Mistry, P.T. & Patel, S.K. (2010). Design, synthesis and in vitro evaluation of antitubercular and antimicrobial activity of some novel pyranopyrimidinesEur. J. Med. Chem.,45, 5056 – 5063.

Mahmoud, R.M., El-Ziaty, A.K. &Hussein,A.M. (2012).Utility of S-benzylthiuronium chloride in the synthesis of heterocyclic systems. World Appl. Sci. J., 17, 101 – 108.

Mahmoud, R.M., El-Ziaty, A.K. &Hussein, A.M. (2013a). Synthesis and spectral characterization of novel thiazolopyridine and pyrimidine derivatives. Synth. Comm.43, 961 – 978.

Mahmoud, M.R., El-Ziaty, A.K., Abu El-Azm, F.S.M. & Ismail, M. (2013b). Utility of cyano-N-(2-oxo-1,2-dihydroindol-3-ylidene)acetohydrazide in the synthesis of novel heterocycles. J. Chem. Res.,37, 63 – 124.

Mahmoud, R.M., Shiba, S.A., El-Ziaty, A.K., Abou Al-Azm,F.S.M. & Ismail, M.F. (2014).Synthesis and reactions of novel 2,5-disubistituted 1,3,4-thiadiazoles. Synth. Comm.,44, 1094 – 1102.

Martinand-Lurin, E., El Kaïm, L. &Grimaud, L. (2014). Benzoxazinone synthesis via Passerini–Smiles couplingsTetrahedron Lett. , 55, 5144 – 5146.

Piecyk., K., Krynska, P., Kaluzna, J. &Jankowska-Anyszka, M. (2017). Synthesis of the first double-functionalized dinucleotide mRNA cap analogue for its specific labelingTetrahedron Lett.,58, 3037 – 3040.

Santhosh, R.M., Siliveri, S., Alla, M., Bommena, V.R., Bommineni, M.R. & Balasubramanian, S. (2012). Eco-friendly synthesis and biological evaluation of substituted pyrano[2,3-c] pyrazoles. Bioorg. Med. Chem. Lett., 15, 5277 – 5278.

Saundane, A.R., Vijaykumar, K. &Vaijinath, A.V. (2013). Synthesis of novel 2-amino-4-(5′-substituted 2′-phenyl-1H-indol-3′-yl)-6-aryl-4Hpyran-3-carbonitrile derivatives as antimicrobial and antioxidant agents. Bioorg. & Med. Chem. Lett., 23, 1978 – 1984.

Shiba, S.A., El-Ziaty, A K., El-Aasar, N K. & AL-Saman, H.A. (2008). Uses of piperonal in the synthesis of novel 2-propenoyl amides, esters, heterocyclic systems and study of their antibacterial activities. J. Chem. Res., 9, 500 – 506.
