Резюме. Mixed ligand complexes, Na[M{(C\(_{6}\)H\(_{5}\) CH\(_{2}\) CH(NH\(_{2}\)) COO)} {NH(CH\({_2}\)COO)\(_{2}\)}.H\(_{2}\)O], where M = Cu(II) and Co(II), formed with phenylalanine and iminodiacetic acid were synthesized and characterized by their elemental analysis, spectral (IR and UV) and magneto chemical studies. In both complexes, phenylalanine was found to act as a bidentate ligand coordinating through the carboxylate oxygen and the nitrogen atom of the amino group. The iminodiacetic acid, however, coordinated through the two carboxylate oxygen atoms and the nitrogen of the NH group, hence acted as a tridentate ligand. The remaining coordination position is satisfied by one water molecule. Thus both complexes have been suggested to show six fold octahedral structures.

Ключови думи: phenylalanine, iminodiacetic acid, \(\operatorname{Cu}\) (II) and \(\operatorname{Co}\) (II) complexes, synthesis, characterization, structure

Introduction

Some transition metal ions play an important role in various biological systems and hence can form simple and mixed ligand complexes with biologically active ligands (Choudhary et al., 2011). Mixed ligand complexes have been found to be biologically active against pathogenic microorganisms (Patil et al., 2011; Thakkar & Thakkar, 2000) and can act as active catalysts in industrially useful reactions (Patil et al., 2012). Amino acids are biologically active ligands and have the ability to form various types of metal complexes. Amino acids involved mixed ligand complexes may give a better understanding about the reactions of various drugs that may undergo in the body (Iakovidis & Hadjiliadis, 1989) and are also significant potential model for enzyme metal ion substrate complex (Choudhary et al., 2011; Thakkar & Thakkar, 2000). Patel & Joshi (1997) have reported the formation and the stability constants of mixed ligand Ni(II), Zn(II) or Cd(II) complexes potentiometrically in aqueous solution involving iminodiacetic acid and phenylalanine. Mixed \(\mathrm{Al}^{3+}\) complex in aqueous solution with \(\beta\)-phenylalanine and iminodiacetic acid has also been identified (Petrosyants et al., 1996). Synthesis, characterization, antibacterial and antimicrobial studies of some transition metal mixed ligand complexes formed with phenylalanine and pyrimidine nucleoside (uridine) (Reddy & Reddy, 2000), 8-ydroxyquinoline (Patil et al., 2011), 1-nitroso-2 naphthol (Fayad et al,, 2012) or 5-flurouracil (Choudhary et al., 2011; Shobana et al., 2012) have been earlier reported. In earlier publications (Kumar, 2007; Kumar & Kiremire, 2007; Kumar, 2008) mixed ligand octahedral complexes of some transition metals formed with iminodiacetic acid and hippuric acid have been studied. Literature is lacking on the studies of mixed ligand transition metal complexes formed with phenylalanine and iminodiacetic acid. Hence this paper describes the synthesis and characterization of mixed ligand Cu(II) and Co(II) complexes of iminodiacetic acid and phenylalanine.

Experimental

Solutions of L-phenylalanine (Aldrich) and iminodiacetic acid (Aldrich) were prepared in one equivalent of sodium hydroxide. Solutions of metal ions, \(\mathrm{CuCl}_{2} \cdot 2 \mathrm{H}_{2} \mathrm{O}\) \((\mathrm{BDH})\) and \(\mathrm{CoCl}_{2}\) (Rochelle Chemicals) were prepared in one equivalent of hydrochloric acid.

Synthesis of Cu(II) complex

Two ligands solutions \((0.1 \mathrm{M})\) were mixed with 0.1 M metal ion solution in \(1: 1: 1\) volume ratio at room temperature. At first phenylalanine solution was mixed with \(\mathrm{CuCl}_{2} .2 \mathrm{H}_{2} \mathrm{O}\) solution followed by iminodiacetic acid solution and the pH of the solution was adjusted to \(\sim 4.24\) by adding sodium hydroxide. On adding phenylalanine solution to metal ion solution, a light blue solution was obtained with pH 0.51. On the addition of iminodiacetic acid to this solution, the pH of the resulting dark blue solution was adjusted to \(\sim 4.24\) by adding sodium hydroxide. The dark blue solution was then concentrated between \(20-25 \mathrm{ml}\) over a steam bath and allowed to crystallize. Dark blue crystalline product was then filtered and washed first with \(50 \%\) water-ethanol mixture followed by acetone and dried in a vacuum desiccator.

Synthesis of Co(II) complex

Two ligands solution (0.1M) were mixed with anhydrous Co(II) chloride solution in 1:1:1 volume ratio at room temperature. At first phenylalanine solution was added to the metal ion solution followed by iminodiacetic acid solution and the pH of the solution was adjusted to \(\sim 5.12\) by adding sodium hydroxide solution. On the addition of phenylalanine to the metal ion solution, a pink solution with pH 2.92 was obtained. On the addition of iminodiacetic acid solution to this solution, a clear pink solution was obtained with pH 2.56 which was raised to \(\sim 5.12\) by adding sodium hydroxide. The clear pink solution was then concentrated over a steam bath between 20 to 25 ml and allowed to crystallize. The dark violet crystalline product was then filtered and washed with \(50 \%\) water-ethanol mixture followed by acetone.

The IR spectra of the ligands and metal complexes were recorded on a Perkin Elmer FT-IR 2000 spectrophotometer in \(4000-400 \mathrm{~cm}^{-1}\) range using KBr disc. The magnetic susceptibility of the complexes was measured at room temperature using Johnson Matthey Alfa product magnetic susceptibility balance. Schimadzu UV-vis 2501 model TCC-240A was used to record the electronic spectra of the complexes in \(200-1100 \mathrm{~nm}\) range. The elemental analysis (CHN) was carried out on a Vario EL CHNO/S elemental analyzer.

Results and discussion

Elemental analysis

(1) Sodium(phenylalaninato)(iminodiacetato)(monoaqua)copper(II). Dark blue crystals. Anal. Calcd for \(\mathrm{Na}\left[\mathrm{Cu}\left(\mathrm{C}_{6} \mathrm{H}_{5} \mathrm{CH}_{2} \mathrm{CH}\left(\mathrm{NH}_{2}\right) \mathrm{COO}\right)\left\{\mathrm{NH}\left(\mathrm{CH}_{2} \mathrm{COO}\right)_{2}\right\}\right.\). \(\left.\mathrm{H}_{2} \mathrm{O}\right]\) : \(\mathrm{C}=\) \(39.05 \% ; \mathrm{H}=4.29 \% ; \mathrm{N}=7.00 \%\). Found \(\mathrm{C}=38.61 \% ; \mathrm{H}=3.98 \% ; \mathrm{N}=6.87 \%\).

(2) Sodium(phenylalaninato)(iminodiacetato)(monoaqua)cobalt(II). Pink powder. Anal. Calcd for \(\mathrm{Na}\left[\mathrm{Co}\left(\mathrm{C}_{6} \mathrm{H}_{5} \mathrm{CH}_{2} \mathrm{CH}\left(\mathrm{NH}_{2}\right) \mathrm{COO}\right)\left\{\mathrm{NH}\left(\mathrm{CH}_{2} \mathrm{COO}\right)_{2}\right\} . \mathrm{H}_{2} \mathrm{O}\right]\) : \(\mathrm{C}=39.70 \%\); \(\mathrm{H}=4.36 \% ; \mathrm{N}=7.12 \%\). Found \(\mathrm{C}=39.40 \% ; \mathrm{H}=4.35 \% ; \mathrm{N}=6.84 \%\).

IR studies

Iminodiacetic acid shows characteristic \(v(\mathrm{C}=\mathrm{O})\) adsorption band for COOH group at \(1702 \mathrm{~cm}^{-1}\) which does not appear in case of metal complexes. Instead, asymmetric and symmetric stretching \(\mathrm{COO}^{-}\)frequencies are observed. The Cu (II) complex shows \(v_{\text {as }} \mathrm{COO}^{-}\)and \(v_{\mathrm{s}} \mathrm{COO}^{-}\)frequencies at \(1615 \mathrm{~cm}^{-1}\) and \(1382 \mathrm{~cm}^{-1}\) respectively whereas in Co (II) complex these bands are observed at \(1558 \mathrm{~cm}^{-1}\) and \(1404 \mathrm{~cm}^{-1}\) respectively. The \(\nu(\mathrm{CN})\) absorption band in iminodiacetic acid is observed at \(1330 \mathrm{~cm}^{-1}\) which is lowered in metal complexes. The \(v(\mathrm{NH})\) absorption band in iminodiacetic acid appears at 3092 \(\mathrm{cm}^{-1}\). This band appears at \(3247 \mathrm{~cm}^{-1}\) and \(3275 \mathrm{~cm}^{-1}\) in Cu (II) and Co (II) complexes respectively. Therefore, it can be concluded that iminodiacetic acid in both the complexes act as a tridentate ligand coordinating through the carboxylate oxygen atoms and nitrogen of the NH group. Phenylalanine is an amino acid and therefore as a zwitter ion it may be written as \(\left[\mathrm{C}_{6} \mathrm{H}_{5} \mathrm{CH}_{2} \mathrm{CH}\left(\mathrm{N}^{+} \mathrm{H}_{3}\right) \mathrm{COO}^{-}\right]\). Thus it should show characteristic bands (\(\mathrm{N}^{+} \mathrm{H}_{3}\) and \(\mathrm{COO}^{-}\)) of amino acids (Srivastava & Srivastava, 1977). Free amino acids show \(\mathrm{V}\left(\mathrm{N}^{+} \mathrm{H}_{3}\right)\) band in \(3130 \mathrm{~cm}^{-1}-3030 \mathrm{~cm}^{-1}\) region. In the formation of metal complexes, \(\mathrm{N}^{+} \mathrm{H}_{3}\) is deprotonated and coordinates to the metal through the neutral \(\mathrm{NH}_{2}\) group. This should be supported by an increase in \(\mathrm{V}\left(\mathrm{NH}_{2}\right)\) absorption frequency and a characteristic band should appear in \(3500-3300 \mathrm{~cm}^{-1}\) region (Reddy & Reddy, 2000). In the present study, the IR spectra of phenylalanine shows a characteristic band at 3068 \(\mathrm{cm}^{-1}\) attributable to the \(\mathrm{N}^{+} \mathrm{H}_{3}\) and is not present in case of metal complexes indicating the deprotonation of \(\mathrm{N}^{+} \mathrm{H}_{3}\) to \(\mathrm{NH}_{2}\) group (Reddy & Reddy, 2000). Instead new bands at \(3180 \mathrm{~cm}^{-1}\) and \(3275 \mathrm{~cm}^{-1}\) in case of Cu (II) and Co (II) complexes respectively are observed lower than in \(\mathrm{v}\left(\mathrm{NH}_{2}\right)\) group region. Thus it appears that in metal complexes nitrogen of the amino group is involved in the coordination (Reddy & Reddy, 2000). The IR spectra of phenylalanine also shows characteristic \(\nu_{\text {as }} \mathrm{COO}^{-}\)and \(\nu_{\mathrm{s}} \mathrm{COO}^{-}\)bands at \(1623 \mathrm{~cm}^{-1}\) and \(1408 \mathrm{~cm}^{-1}\) respectively. Cu(II) complex shows these bands at 1615 \(\mathrm{cm}^{-1}\) and \(1385 \mathrm{~cm}^{-1}\) respectively. However these bands in Co(II) complex are observed at \(1558 \mathrm{~cm}^{-1}\) and \(1404 \mathrm{~cm}^{-1}\), respectively. The difference (\(\Delta \nu_{\text {as }} \nu_{\mathrm{s}}\) ) of \(230 \mathrm{~cm}^{-1}\) and \(154 \mathrm{~cm}^{-1}\) supports the monodentate coordination of the carboxylate group (Mitic et al., 2009; Devereux et al., 1998). Besides Cu(II) and Co(II) complexes also show additional bands at \(3518 \mathrm{~cm}^{-1}\) and \(3499 \mathrm{~cm}^{-1}\) attributable to water molecules (Nakamoto, 1970). The presence of \(\rho_{\mathrm{r}}\left(\mathrm{H}_{2} \mathrm{O}\right)\) frequency at \(833 \mathrm{~cm}^{-1}\) and \(848 \mathrm{~cm}^{-1}\) in case of \(\mathrm{Cu}(\mathrm{II})\) and Co(II) complexes, respectively, confirms the presence of coordinated water molecules (Nakagawa & Shimanouchi, 1964). The main IR frequencies of ligands and the metal complexes are listed in Table 1.

Note: Ph and IDA stand for the anion of phenyalalanine and iminodiacetic acid respectively in Tables 1 and 2.

Magnetic measurements and electronic spectra

The observed magnetic moment for Cu(II) complex, sodium(phenylalaninato) (iminodiacetato)(monoaqua) copper complex, \(\mu_{\text {eff }}=1.90 \mathrm{BM}\) suggests a spin free octahedral structure for the complex (Figgis & Lewis, 1960) which is supported by its electronic spectra (Lever, 1986). The band observed at \(14925 \mathrm{~cm}^{-1}\) can be regarded as d-d transition band. The complex also shows a band at \(31879 \mathrm{~cm}^{-1}\) which can be assigned as a charge transfer band from ligand to metal. For the Co(II) complex, sodium (phenylalaninato) (iminodiacetato)(monoaqua) cobalt(II), a spin free octahedral structure is also suggested on the basis of the observed magnetic moment (\(\mu_{\text {eff }}\) ) of 5.11 BM (Figgis & Lewis, 1960) which is supported by its electronic spectra. In this complex the band, observed at 19120 \(\mathrm{cm}^{-1}\) can be regarded as a \(v_{3}\) transition. The position of \(v_{2}\) transition in case of octahedral Co(II) complexes may, however, be ambiguous (Lever, 1986) and is rather difficult to observe with certainty. The \(v_{1}\) transition occurs at lower frequencies and is expected to be observed beyond 1000 nm in the near infra red region. Thus in the present complex, a band observed at \(9302 \mathrm{~cm}^{-1}(1075 \mathrm{~nm})\) can be assigned as \(v_{1}\) transition (Cotton et al., 1999). The band observed at \(34847 \mathrm{~cm}^{-1}\) can be regarded as a charge transfer band for the \(\operatorname{Co}\) (II) complex. The observed magnetic measurements and the electronic spectra data are given in Table 2.

Conclusion

Thus data obtained above suggest spin free octahedral structures for both the complexes. In both the complexes iminodiacetic acid acts as a tridentate ligand. However, phenylalanine acts as a bidentate ligand and the sixth coordination position is satisfied by one water molecule.

Acknowledgement. Authors are grateful to the University of Botswana for the financial support to the project.

NOTES

1. Dr. G. Kumar is a Distinguished Member of the Club of Friends of Chemistry: Bulgarian Journal of Science Education (Ed.)

REFERENCES

Choudhary, A., Sharma, R. & Nagar, M. (2011). Synthesis, characterization and antimicrobial activity of mixed ligand complexes of Co(II) and Cu(II) with N, O/S donor ligands and amino acids. Int. Res. J. Pharmacy & Pharmacology, 1(6), 172-187.

Cotton, F.A., Wilkinson, G., Murillo, C.A. & Bochmann, M. (1999). Advanced inorganic chemistry. New York: Wiley.

Devereux, M., Jackmann, M., McCann, M. & Casey. M. (1998). Preparation and catalase-type activity of manganese(II) amino acid complexes. Polyhedron, 17, 153-158.

Fayad, N.K., Al-Noor, T.H. & Ghanim, F.H. (2012). Synthesis, characterization and antibacterial activity of mixed ligand complexes of some metals with 1-nitroso-2-naphthol and l-phenylalanine. Chemistry & Material Res. , 2(5), 18-29.

Figgis, B.N. & Lewis, J. (1960). The magnetochemistry of complex compounds (pp. 400454). In: Lewis, J. & Wilkins, R.G. (Eds.) Modern coordination chemistry. New York: Wiley.

Iakovidis, A & Hadjiliadis, N. (1989). Interaction of cis-Pt(NH3) . Interaction of cis-\(\mathrm{Pt}\left(\mathrm{NH}_{3}\right)_{2} \mathrm{Cl}_{2}\) with amino acids. The crystal structures of cis-\(\left[\mathrm{Pt}\left(\mathrm{NH}_{3}\right)_{2}\right.\) (gly) \(]\left(\mathrm{NO}_{3}\right)\), cis-\(\left[\mathrm{Pt}\left(\mathrm{NH}_{3}\right)_{2}\right.\) (ala) \(]\left(\mathrm{NO}_{3}\right)\), cis-\(\left[\mathrm{Pt}\left(\mathrm{NH}_{3}\right)_{2}\right.\) (val) \(]\) \(\left(\mathrm{NO}_{3}\right)\).,Inorg. Chim. Acta, 164, 221-229.

Kumar, G. (2007). Synthesis and characterization of mixed ligand cobalt (II) complexes of iminodiacetic acid and hippuric acid. Res. J. Chem. Environ., 11(3), 87-89.

Kumar, G. (2008). Synthesis and characterization of mixed ligand nickel (II) complexes of iminodiacetic acid and hippuric acid. Asian J. Chem., 20, 1143-1147.

Kumar, G. & Kiremire, E.M.R. (2007). Synthesis, coordination and structure of mixed ligand copper (II) complexes of iminodiacetic acid and hippuric acid. Chemistry, 16, 386-393.

Lever, A.B.P. (1986). Inorganic electronic spectroscopy. Amsterdam: Elsevier.

Mitic, D., Milenkovic, M., Milosavljevic, S., Godevac, D., Miodragovic, Z., Andelkovic, K. & Miodragovic, D. (2009). Synthesis, characterization and antimicrobial activity of Co(II), Zn(II) and Cd(II) complexes with N-benzoyloxycarbonyl-S-phenylalanine. European J. Medicinal Chemistry, 44, 1537-1544.

Nakagawa, I. & Shimanouchi, T. (1964). Infra-red absorption spectra of aquo complexes and nature of coordination bonds. Spectrochimica Acta, 20, 429-439.

Nakamoto, K. (1970). Infra-red spectra of inorganic and coordination compounds. New York: Wiley.

Patel, A.K. & Joshi, J.D. (1997). Potentiometric studies on mixed ligand complexes in aqueous solution: M(II) with neutral or charged primary ligand and amino acid systems. J. Indian. Chem. Soc. , 74, 222 – 224.

Patil, A.R., Donde, K.J., Raut,, S.S., Patil, V.R. & Lokhande, R.C. (2012). Synthesis, characterization and biological activities of mixed ligand Co(II) complexes of Schiff base 2-amino4-nitrophenol-n-Salicylidene with some amino acids. J. Chem. Pharm. Res., 4, 1413-1425.

Patil, S.S., Thakur, G.A. & Shaikh, M.M. (2011). Synthesis, characterization, and antibacterial studies of mixed ligand dioxouranium complexes with 8-hydroxyquinoline and some amino acids. ISRN Pharmaceutics, 2011, art. ID 168539.

Petrosyants, S.P., Malyarik, M.A. & Buslaev, Y.A. (1996). Fluoro aminocarboxylato aluminium complexes. Russ. J. Inorg. Chem., 41, 1742-1748.

Reddy, P.R. & Reddy, A.M. (2000). Synthesis and characterization of mixed ligand complexes of bio- metals with pyridine nucleoside (uridine) and amino acids. Indian Acad. Sci. (Chem. Sci ) , 112, 593-600.

Shobana, S. Dharmaraja, J., Kamatchi, P. & Selvaraj, S. (2012). Mixed ligand complexes of \(\mathrm{Cu}(\mathrm{II}) / \mathrm{Ni}(\mathrm{II}) / \mathrm{Zn}(\mathrm{II})\) ions with 5-flurouracil(5-FU) in the presence of some amino acid moieties: structural and antimicrobial studies. J. Chemical & Pharmaceutical Res. , 4, 4995-5004.

Srivastava, J.P.N. & Srivastava, M.N. (1977). Magnetic and spectral studies on some transition metal complexes of DL-\(\alpha\) aminobutyric acid. Acta Chim. Acad. Sci. Hung., 94, 201-207.

Thakkar, N.V. & Thakkar, J.R. (2000). Synthesis and characterization of chiral mixed ligand Co(II) complexes of isonitrosopropophenane and amino acids. Synthesis & Reactivity in Inorganic and Metal-Organic Chemistry, 30, 1871-1887.
