Резюме. The present contribution is focused on the relation preparation – structure – optical properties of hybrid silica powders containing Eu(III) complexes: \(\mathrm{SiO}_{2}\) : \(\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\) and \(\mathrm{SiO}_{2}\) : \(\left[\mathrm{Eu}(\mathrm{phen})_{2}\right]\left(\mathrm{NO}_{3}\right)_{3}\). New methods for surface functionalization of silica microparticles \({ }_{2}\) based on adsorption of 1,10-phenantroline and \(\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\), are proposed in the framework of preparation of red emitting hybrid composites with quantum efficiency \(20-50 \%\). The optical properties of rare earth ions incorporated in silica composites are used to explore the site symmetry (\(\mathrm{D}_{2}\), \(\mathrm{C}_{2 \mathrm{v}}\) or lower) of the \(\mathrm{Eu}^{3+}\) optical centers in the hybrid composites. Quantum yields of the investigated sol-gel micropowders and quantification of their optical spectra are presented. X-Ray diffraction patterns of the investigated hybrid composites are presented. A short overview of sol-gel technology as a method for preparation of functional nanomaterials is presented.

Ключови думи: silica, europium complexes, luminescence, sol-gel

Introduction

Sol-gel materials functionalized with rare earth ions and their complexes display important optical properties like luminescence, coloration and energy transfer and give opportunity for wide technical applications. This paper deals with colloidal preparation strategies of silica gels doped with europium complexes. Such materials have potential application as red emitting materials for photo conversion of light, ultraviolet sensors and in labeling of materials (Brinker & Scherrer, 1990). From materials science point of view sol-gel materials functionalized with rare earth ions are hybrid materials as they contain an organic ligand or complex in an inorganic matrix. The oxide matrix is usually prepared using sol-gel chemistry. To transform an inorganic silica or zirconia matrix into a system with desired optical properties it is necessary to incorporate into the matrix an optical active component using a physico - chemical doping procedure. Here, the optical active components are strong red emitting europium (III) complexes (Bünzli, 2014). As a model of europium complexes in this paper following species are used: (a) \(\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\), containing 4,4,4-trifluoro-1-(naphthalene-2-yl) butan-1,3-dione (Hntac) and pyrazino[2,3-f][1,10-phenathroline-2,3-dicarbonitrile (pphendcn). It is a relatively new luminescent complex, detailed described by Bünzli (2014), Petkova et al. (2011a), Petkova et al. (2011b), Danchova & Gutzov (2014), Danchova et al., 2014 and Danchova & Gutzov (2014). The quantum efficiency of the solid complex is \(10-15 \%\); (b) \(\left[\mathrm{Eu}(\mathrm{phen})_{2}\right]\left(\mathrm{NO}_{3}\right)_{3}\), europium (III) diphenathroline nitrate. It is a well known luminescent complex, detailed described by Mirochnik et al (2002). The quantum efficiency of the solid complex is \(35-40 \%\).

The basic principles of sol-gel chemistry as a tool for preparation of functional nanomaterials are given bellow. Sol-gel technology is a powerful method for preparation of oxide nanomaterials at low temperatures (bellow \(150{ }^{\circ} \mathrm{C}\) ). Most important advantages of sol-gel technology are the use of liquid chemicals, the possibility for preparation of complicated chemical compositions and the use of low temperature of preparation. Sol-gel chemistry, however, displays some disadvantages like individual preparation schemes for solving each problem, long duration times of gelation and lot of physico - chemical measurements necessary for a reproducible preparation. Sol-gel chemistry offers a possibility for the ambient preparation of optical materials like xerogels or layers doped with rare earth ions. In the same way a wide range of useful ceramic materials like \(\mathrm{Al}_{2} \mathrm{O}_{3}, \mathrm{ZrO}_{2}, \mathrm{SnO}_{2}, \mathrm{SiO}_{2}, \mathrm{Al}_{2} \mathrm{O}_{3}\) can be easily prepared.

Gels are solids confining a solvent in a three-dimensional network. The solvent may be enclosed as quasi-liquid in a pore system. At this state, the gels are called hydrogels (water as solvent) or alcogels (alcohol as solvent), etc. If the network has nanodimensions or is index-matched, the gel looks transparent. If the solvent is removed without destruction of the porous network, the resulting body is called a aerogel. The density of aerogels is in the range of \(0.05 \mathrm{~g} / \mathrm{cm}^{3}\). Drying with destruction of the porous network leads to typical xerogel monoliths with a density in the range of \(0.5-1 \mathrm{~g} / \mathrm{cm}\) (Petkova et al., 2011a; Büzli, 2014; Gutzov & Bredol, 2006).

It is known, that sol gel-chemisrty is based on three simple chemical reactions: water hydrolysis of liquid alkoxides followed by condensation. Condensation (better known as gelation), could be performed as a water condensation or alcohol condensation. The results of sol-gel process strongly depend on the reaction conditions: it is possible to obtain micro- or nanopowders, transparent xerogels, transparent thin films or even aerogels by changing reaction conditions.

The europium (III) ion is responsible for the red component of the tricolor luminescent lamps due to a strong emission peak at 615 nm. The optical properties of europium ion are well known, they are explained by the weak crystal field approximation. In addition, the europium ion optical spectra give information about the site symmetry of the europium ion, the so called “spectra structure correlation” (Blasse & Grabmaier, 1994).

The optical transitions of lanthanide ions are weak to produce light and therefore their intensity must be increased. Sensitizer ions or molecules absorb ultraviolet energy and transfer this energy to the europium ion. The europium ion itself goes to an excited state and emits in the red spectral region. In this way the quantum yield can be increased more than ten times. As organic sensitizing ligands many organic molecules like phenathroline or acethylacetone and their derivates are used. Cerium ion is a typical example for inorganic ions with sensitizing properties. More about the energy transfer is given in the monographs (Binker & Scherer, 1990; Büzli, 2014). In the case of an efficient energy transfer the weak sharp Eu(III) peaks in the excitation spectra are replaced by strong, broad features dominated from sensitizers.

In Fig. 1. a typical sol-gel preparation equipment in the laboratory of Functional Optical Materials (FOM) in the Department of Physical Chemistry is shown. The used chemicals are liquids – metal alcoxides, alcohol and water, as well as doping solutions, lanthanide solutions and other solutions. The laboratory is specialized in doping of zirconia and silica gels with lanthanide ions and their complexes. Some details the solgel process are: the preparation of oxides consists two steps, hydrolysis of alcoxides and gelataion of the prepared colloidal nanoparticles. The hydrolysis is acid catalized, the condensation / gelation/ step - basic catalized. Drying conditions are very important to obtain gels with desired properties. Reproducibility is one of the most important problems in sol-gel chemistry due to the complicated physic-chemical nature of the processes in sol-gel technology. Parameters which must be controlled during the solgel process are pH, temperature and chemical composition to obtain materials with a given chemistry, transparency, phase composition and microstructure.

In Fig. 2 some results connected with functionalized inorganic silica gels are presented. Silica gels doped with samarium ions are materials with potential application as ultraviolet filters. Left – low doped with samarium ions silica gels are displayed, they are transparent. Increasing the degree of doping leads to a weak yellow color and makes the gels translucent, because nano- crystals of samarium nitrate are formed during the sol-gel process. Under special conditions and using basic condensation conditions, microspheres instead of transparent gels, could be obtained.

The photos of Dr. GulayAhmed (Fig. 2) are made through doped gels with a thickness of about 2 mm with a different samarium concentration. In summary, transparency of inorganic sol-gel materials depends on doping concentration and/or porous system properties. Also Fig. 2 shows interesting applications of sol-gel chemistry, preparation of uniform silica microspheres, known as “Stöber’s silica”. Under special conditions and using basic condensation conditions, uniform microspheres instead of transparent gels could be obtained (Brinker & Scherrer, 1990).

Zirconia sol-gel chemistry is much more complicated compared to silica chemistry, because of the high reactivity of zirconium alcoxides. In the case of zirconia solgel chemistry the rates of hydrolysis and condensation are high and a fast formation of micropowders, as in the case of chemical precipitation takes place. This is why zirconium alcoxides must be protected with organic ligands as acethylacetone or acetic acid, which form chelate complexes with zirconium.

In Fig. 3 three sol-gel approaches for preparation of zirconia sol-gel materials depending on protection conditions of the sol are shown. In the left scheme nanopowders, fast produced without protection are displayed. In the middle scheme a protection with acethylaceton as complex forming ligand is given. The result is a transparent gel with increased ultraviolet absorption. Right an example for production of zirconia gels with protection of acetic acid, the most successful way to produce hybrid materials. The photo of Dr. Nina Danchova (Fig. 3) is made through a zirconia gel to demonstrate the optical transparency of the produced zirconia materials. The high transparency in the case of zirconia is combined with a high refractive index, zirconia is well known as “artificial diamond”. The strong gel coloration in Fig. 3 comes from \(\mathrm{Zr}(\) IV \()\)-acetyl acetone complexes with a high UV – absorption, \(\varepsilon=24001 / \mathrm{mol} \cdot \mathrm{cm}\) at 285 nm (Petkova et al., 2011a; Georgieva et al., 2011).

Experimental

The europium complexes \(\left[\mathrm{Eu}(\mathrm{phen})_{2}\right]\left(\mathrm{NO}_{3}\right)_{3}\) and \(\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\) were synthesized according procedures by Petkova et al. (2011b). Elemental analysis was performed on a Vario III instrument. A SpectraPro 300i spectrophotometer was used for measurement of diffuse reflectance, excitation / luminescence spectra and quantum yield of powdered samples. As standard, the Lumogen T Rot GG from BASF with maximum wavelength of excitation at 350 nm and maximum wavelength of emission at 615 nm was chosen. The Quantum Yield (QY) of the investigated samples was determined using the comparison method. Emission spectra were integrated between 430 and 750 nm and excitation spectra between 235 and 430 nm. The luminescence and reflectance measurements were used to estimate QY of investigated samples (defined as the ratio of the number of photons emitted to the number of photons absorbed). In this study, the presented luminescence spectra are mathematically threated as overlapping Gaussion curves to obtain relative intensities, peak number, peak maxima and half widths of each luminescence peak. The Eu – content in all samples prepared was checked using a ICP Ultima2 Horiba-Jobin Yvon unit.

To prepare silica microparticles with an intense red emission two physico-chemical functionalization techniques are used:

Surface functionalization of silica micro particles with [Eu(ntac) ] \({ }_{3}\) ][pphendcn] (physical functionalization)

The preparation of hybrid silica micro composites includes the following basic steps: (1) Preparation of \(\mathrm{SiO}_{2}\) matrix, using a classical base catalyzed sol-gel process (Danchova & Gutzov, 2013); (2) Homogenization of the solid matrix in mortar to obtain silica micro particles in size 100-300 μm; (3) Impregnation of silica micro particles with solution of \(0.0107 \mathrm{M}\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\) in ethanol (48 h at room temperature).

Preparation of functionalized micro particles starting from \(\mathrm{SiO}_{2}\) :Eu (chemical functionalization

The preparation includes the following basic steps: (1) Synthesis of doped \(\mathrm{SiO}_{2}: \mathrm{Eu}^{3+}\) sol-gel bulk materials with molar ratio \(\mathrm{n}_{\mathrm{Eu}} / \mathrm{n}_{\mathrm{Si}}=0.05\) using the procedure by Danchova & Gutzov (2013); (2) Homogenization of silica gel in mortar to obtain \(\mathrm{SiO}_{2}: \mathrm{Eu}^{3+}\) silica micro particles; (3) Impregnation of doped \(\mathrm{SiO}_{2}\) micro particles with ethanol solution of 1.1M 1,10-phenanthroline (48 h at room temperature with molar ratio \(\mathrm{n}_{\mathrm{Eu}}\) / \(\mathrm{n}_{\text {phen }}=9.4 \cdot 10^{-3}, \mathrm{n}_{\mathrm{Si}} / \mathrm{n}_{\text {phen }}=0.18\); (4) Washing the micropowders with absolute ethanol to remove the excess amount of ligand.

Experimental results and discussion

In Fig. 4 a typical luminescence spectrum of \(\mathrm{SiO}_{2}:\left[\mathrm{Eu}(\mathrm{phen})_{2}\right]\left(\mathrm{NO}_{3}\right)_{3}\) powders produced from \(\mathrm{SiO}_{2}: 0.05 \mathrm{Eu}^{3+}\) functionalized using adsorption of 1,10-phenanthroline (chemical functionalization) is presented. The relative intensity of the \(\mathrm{Eu}^{3+5} \mathrm{D}_{0} \rightarrow{ }^{7} \mathrm{~F}_{2}\) transition is high, about \(80-82 \%\) from the overall \(\mathrm{Eu}^{3+}\) luminescence intensity between 570 nm and 750 nm. It follows from second derivative luminescence spectra, that the most probable symmetry of \(\mathrm{Eu}^{3+}\) is \(\mathrm{D}_{2}\) (Görller-Walrand & Binnemans, 1998). Surface formation of \(\left[\mathrm{Eu}(\text { phen })_{2}\right]\left(\mathrm{NO}_{3}\right)_{3}\) as a result of the functionalization of \(\mathrm{SiO}_{2}\) : Eu with \(1,10-\) phenanthroline has been confirmed by X-Ray diffraction by comparing data of pure solid complexes and functionalized silica samples. X-Ray diagrams of the investigated samples are presented in Fig. 5, here a pure solid complex \(\left[\mathrm{Eu}(\mathrm{phen})_{2}\right]\left(\mathrm{NO}_{3}\right)_{3}\) and solid \(1,10-\) phenanthroline are used as a reference. In the case of solid \(\left[\mathrm{Eu}(\mathrm{phen})_{2}\right]\left(\mathrm{NO}_{3}\right)_{3}\) and functionalized \(\mathrm{SiO}_{2}:[\mathrm{Eu}(\) phen \()]\left(\mathrm{NO}_{3}\right)_{3}\) we have a very weak \({ }^{5} \mathrm{D}_{0} \rightarrow{ }^{7} \mathrm{~F}_{0}\) transition at 585 nm, visible in second – derivative spectra, which refers that the most probable site symmetry of \(\mathrm{Eu}^{3+}\) here is \(\mathrm{D}_{2}\) and / or \(\mathrm{C}_{2 \mathrm{v}}\) (Danchova et al., 2 2014). The presence of two kind of optical centers in the described hybrid materials is also possible. The exact site symmetry evaluation here needs additional investigations.

In Fig. 6 luminescence spectra of solid \(\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\) and functionalized \(\mathrm{SiO}_{2}:\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\) are presented. The relative intensity of the \(\mathrm{Eu}^{3+}{ }^{5} \mathrm{D}_{0} \rightarrow{ }^{7} \mathrm{~F}_{2}\) transition is about \(83-85 \%\). Differences in the luminescence spectra of solid complex and functionalized sol-gel samples have been detected. The luminescence spectrum of \(\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\) has a relative strong \({ }^{5} \mathrm{D}_{0} \rightarrow{ }^{7} \mathrm{~F}_{0}\) transition and a site symmetry of \(\mathrm{Eu}^{3+} \mathrm{C}_{2 \mathrm{v}}\) or lower (Görller-Walrand & Binnemans, 1998). Spectral differences indicate a change of chemical environment and / or site symmetry of \(\mathrm{Eu}^{3+}\) as a result of the adsorption of \(\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\) on the silica surface. In the terms \(\mathrm{Eu}^{3+}\) site symmetry/spectra correlation, the most probable site symmetry in \(\mathrm{SiO}_{2}:\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right]\) [pphendcn] is \(\mathrm{D}_{2}\) (Bünzli, 2014). The luminescence spectral maximum changes from 612 nm to 618 nm as a result of functionalization most probable due to lowering of crystal field strength on the silica surface.

The luminescence emission of the prepared samples \(\mathrm{SiO}_{2}:\left[\mathrm{Eu}(\mathrm{phen})_{2}\right]\left(\mathrm{NO}_{3}\right)_{3}\) and \(\mathrm{SiO}_{2}:\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\) are very stable for long period of times (more than 1 year). We do not observed additional blue lines coming from surface complex destruction.

Table 1 presents the quantum yields of the investigated samples together with the doping level of the europium activator. In addition, the most probable site symmetry of the europium ion, exctracted from the luminescence spectra, is given. The high quantum yields confirm unambiguously that a ligand→europium charge transfer take place in all of the samples. The relative error of QY using the described procedure is about 0.1, quantum yields of pure complexes are given for comparison. The relative high quantum yields in table 1. allow the potential application of the described hybrid powders as potential UV – sensors and label materials for chemical and biological applications. The quantum yield of europium complexes increases after incorporation in the sol-gel matrix due to a lack of concentration quenching.

It is well known, that using a quantification of \(\mathrm{Eu}^{3+}\) luminescence spectra the site symmetry of the activator ion on molecular level can be obtained in different host matrixes, the so called “spectra-structure correlation”. In this way the site symmetry of europium doped crystals and amorphous materials can be investigated.

From physical point of view the optical transitions of the \(\mathrm{Eu}^{3+}\) ion are magnetic dipole transitions or electric dipole transition described by the low crystal field approximation and quantified by the Judd – Ofelt theory. The Judd – Ofelt theory allows to calculate the oscillator strengths of the f-f transitions of lanthanide ions. The intensities of electronic transitions of europium ions incorporated in sol-gel matrices are characterized by their experimental oscillator strength (Görller-Walrand & Binnemans, 1998; Schmidt, 2000; Brinker & Scherer, 1990):

(1) \[ f=\tfrac{4.32 \cdot 10^{-9}}{C \cdot d} \int A(\widetilde{v}) d \widetilde{v} \]

where \(A(\widetilde{v})\) is the absorbance, C is the \(\mathrm{Eu}^{3+}\) concentration in \(\mathrm{mol} \cdot \mathrm{dm}^{-3}, \mathrm{~d}\) is the optical pathlength in cm and \(\widetilde{v}\) is he wavenumber in \(\mathrm{cm}^{-1}\). The Judd-Ofelt theory allows for the calculation of oscillator strengths according to:

(2) \[ f=4 \cdot \pi \cdot \varepsilon_{0} \tfrac{8 \cdot \pi^{2} \cdot m_{e} \cdot v_{0}}{3 \cdot h \cdot(2 J+1) e^{2}}\left[\chi_{e d} \cdot S_{e d}+\chi_{m d} \cdot S_{m d}\right] \]

Here, \(\chi_{e d}\) and \(\chi_{m d}\) are weighting the electric-dipole and magnetic-dipole contributions, respectively. According to the Judd and Ofelt theory the transition moment for electric dipole \(\mathrm{f} \rightarrow \mathrm{f}\) transitions can be expresses by

(3) \[ \left.S_{e d}=\tfrac{e^{2}}{4 \cdot \pi \cdot \varepsilon_{0}} \sum_{k=2,4,6} \Omega_{k}\left|\left\langle f^{N} \psi J\right| U^{(k)}\right| f^{N} \psi^{\prime} J^{\prime}\right\rangle\left.\right|^{2} \]

and that of the magnetic dipole f-f transition is given by:

(4) \[ \left.S_{m d}=\tfrac{1}{4 \cdot \pi \cdot \varepsilon_{0}} \tfrac{e^{2}}{4 \cdot m^{2} \cdot c^{2}} \sum_{k=2,4,6} \Omega_{k}\left|\left\langle f^{N} \psi J\right| L+2 S\right| f^{N} \psi^{\prime} J^{\prime}\right\rangle\left.\right|^{2} \]

Here, \(\Omega_{\mathrm{k}}\) aretheso-calledJudd-Ofeltintensityparametersand \(\left.\left|\left\langle f^{N} \psi J\right| U^{(k)}\right| f^{N} \psi^{\prime} J^{\prime}\right\rangle \mid\) and \(\left.\left|\left\langle f^{N} \psi J\right| L+2 S\right| f^{N} \psi^{\prime} J^{\prime}\right\rangle \mid\) the reduced matrix elements connecting initial and final states J and J’, respectively. They are commonly assumed to be independent of the host material and have been calculated by Blasse & Grabmaier (1994) and Görller-Walrand & Binnemans, (1998). Conventionally, the \(\Omega_{\mathrm{k}}(\mathrm{k}=2,4,6)\) are determined from experimental spectra taken at room temperature. Hence, a possible temperature dependence of spectral intensity is not accounted for by the standard \(\Omega_{\mathrm{k}}\) values.

The quantum yield of europium doped gels \(\mathrm{QY}_{\text {sam }}\) in this paper is calculated from integrated absorption and luminescence intensity using the comparison method as follows (Schmidt, 2000):

(5) \[ Q Y_{s a m}=Q Y_{r e f} \cdot \tfrac{I_{s a m} \cdot A_{r e f}}{I_{r e f} \cdot A_{s a m}} \cdot 100 \]

Here, \(\mathrm{QY}_{\text {ref }}\) is the quantum yield of the reference sample; \(\mathrm{I}_{\text {sam }}\) and \(\mathrm{I}_{\text {ref }}\) are the integrated luminescence peaks of the investigated sample and the reference and Aref and \(\mathrm{A}_{\text {ref }}\) and \(\mathrm{A}_{\text {sam }}\) are the integrated absorption peaks of the reference and of the investigated sample.

If the \(\mathrm{Eu}^{3+}\) ion occupies sites with an inversion symmetry, the magnetic dipole transition \({ }^{5} \mathrm{D}_{0} \rightarrow{ }^{7} \mathrm{~F}_{1}\) at 5 590 nm is relatively strong. If the \(\mathrm{Eu}^{3+}\) occupies sites without an inversion symmetry, the electric dipole transition \({ }^{5} \mathrm{D}_{0} \rightarrow{ }^{7} \mathrm{~F}_{2}\) at 615 nm is very strong. In addition, the peak number in the region of each Stark multiplet increases when a europium ion occupies sites with a low symmetry. There are quantitative approaches to obtain the site symmetry group from peak numbers in the region of each Stark multiplet, which has been used to determine the most probable site symmetry of \(\mathrm{Eu}^{3+}\) ion, presented in Table 1.

Conclusions

In this paper surface functionalization of sol-gel \(\mathrm{SiO}_{2}\) microparticles with \(\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\) and \(\left[\mathrm{Eu}(\mathrm{phen})_{2}\right]\left(\mathrm{NO}_{3}\right)_{3}\) complexes is described.

Two colloidal methods of surface functionalization, chemical and physical functionalization for preparation of hybrid optical materials are discussed. All the functionalized samples show a pure, stable in time \(\mathrm{Eu}-\) luminescence with quantum yield \(10-40 \%\) due to energy transfer from organic ligands. Surface functionalization is accompanied with a site-symmetry change of \(\mathrm{Eu}^{3+}\) ions followed using luminescence spectroscopy.

REFERENCES

Blasse G. & Grabmaier B.C. (1994). Luminescent materials. New York: Springer.

Bredol, M., Gutzov, S. & Jüstel, T. (2003). Highly efficient energy transfer from Gerelated decects to Tb3+ ions in sol-gel derived glasses. J Non-Cryst Solids, 321, 225-230.

Brinker, C.J. & Scherrer, G.W. (1990). The physics and chemistry of sol-gel processing. New York: Academic Press.

Bünzli, J-C.G. (2014). On the design of highly luminescent lanthanide complexes. Coordination Chem. Rev. , 293-294, 19-47.

Danchova, N. & Gutzov, S. (2013). Time evolution of samarium doped silica sol-gel materials followed by optical spectroscopy. J Sol-Gel Sci Technol, 66, 248-252.

Danchova, N. & Gutzov, S. (2014). Functionalization of Sol-Gel zirconia composites with Europium complexes. Z. Naturforschung, 69b, 224-230.

Danchova, N., Gutzov, S., Matras-Postolek, K., Bredol, M., Lesev, N., Kaloyanova, S. & Deligeorgiev, T. (2014). Preparation and optical properties of silica sol-gel microparticles functionalized with \(\left[\mathrm{Eu}(\mathrm{ntac})_{3}\right][\mathrm{pphendcn}]\) and \(\left[\mathrm{Eu}(\mathrm{phen})_{2}\right]\left(\mathrm{NO}_{3}\right)_{3}\) complexes. J. Inclusion Phenomena &Macrocyclic Chem. , 78, 381-386.

Georgieva, I., Danchova, N., Gutzov, S. & Trendafilova, N. (2011) DFT modeling, UVVis and IR spectroscopic study of acetylacetne-modidied zirconia sol-gel materials. J Mol. Model, 18, 2409-2422.

Görller-Walrand, C. & Binnemans, K. (1998). Spectral intensities of \(f-f\) transitions: handbook of the physics and chemistry of rare earths. Amsterdam: Elsevier.

Gutzov, S. & Bredol, M. (2006) . Preparation and luminescent of terbium and cerium doped silica xerogels, J. Mater. Sci Lett., 41, 1835-1837.

Mirochnik, A.G. , Buktevskii, B.V., Zhikhareva, P.A. & Karasev, W.E. (2002). Crystal structure and fluorescence properties of p-nitrobenzoyl-methane and its complex with boron difluoride. Russian Chem. Bull., 51, 1715-1719.

Petkova, N., Dlugocz, S. & Gutzov S. (2011a). Preparation and optical properties of transparent zirconia sol-gel materials. J. Non Cryst. Solids, 357, 1547-1551.

Petkova, N., Gutzov, S., Lesev, N., Kaloyanova, S., Stoyanov, S. & Deligeorgiev, T. (2011b). Preparation and optical properties of silica gels doped with new Eu(III) complex. Optical Materials, 33, 1715-1720.

Schmidt, W. (2000). Optische Spektroskopie. Weinheim: Wiley-VCH.
