Резюме. An integrated model for determining the reservoir properties of the rock reservoir during underground storage of a gas-hydrogen mixture is presented. The methodology consists of four main modules: Characterization of the core sample (mineral composition, porosity, and permeability), determination of the parameters of the gas-hydrogen mixture at different % hydrogen and methane contents (5%, 15%, 25%), study of flow properties (porosity and permeability of the core sample at different gas-hydrogen mixture contents), and a module summarizing the results. The results obtained from the study using the developed methodology form the basis for designing the storage indicators for gas-hydrogen mixtures in underground gas storage facilities.

Ключови думи: hydrogen; underground storage; capacitance parameters; flow parameters

Introduction

The main objective of the paper is to investigate and study the effect of hydrogen on the capacity and flow parameters of the rock, as hydrogen has emerged as a promising alternative to address the growing demand for sustainable and renewable energy sources. Underground hydrogen storage (UHS) in depleted gas fields has significant potential for large-scale energy storage and seamless integration of renewable energy sources due to its ability to address the challenges associated with the intermittent nature of renewable energy sources, ensuring a stable and reliable energy supply (Gerov, 2019). Due to the impact of exhaust gases on nature, action is needed to decarbonize the atmosphere. This can be done through the use of hydrogen gas mixtures for domestic and industrial use. In the following publication, the influence of gas- hydrogen mixtures on the hydro-gas-dynamic parameters of reservoir rocks in a gas field and in particular on the near-hole zone where the wellbore-productive horizon contact takes place is investigated.

An integrated model for determining the reservoir properties of the rock reservoir during underground storage of a gas-hydrogen mixture is presented on Figure 1. It consists of four main modules: Characterization of the core sample (mineral composition, porosity, and permeability), determination of the parameters of the gas-hydrogen mixture at different \% hydrogen and methane contents (\(5 \%\), \(15 \%, 25 \%\) ), study of flow properties (porosity and permeability of the core sample at different gas-hydrogen mixture contents), and a module summarizing the results. The porosity of the core sample is determined using two methods: tomography and a helium porosimeter. When using the tomography method, the mineralogical and petrographic composition of the core (extracted from the rock reservoir) is also determined (Lakov et al., 2024).

Based on the presented integrated model, the parameters of the gas-hydrogen mixture are determined, as presented below.

Experimental

Each gas mixture consists of a set of components, and each individual component has its own parameters: molar mass, critical pressure, critical temperature, relative density, etc. The corresponding gas mixture has the same parameters. Table 1 shows an example of a hydrogen gas mixture.

Relative density, also called specific gravity, is a dimensionless quantity defined as the ratio of the density (mass divided by volume) of a substance to the density of a given reference material or sunstance. The term “relative density” (abbreviated r.d. or RD) is preferred in SI, whereas the term “specific gravity” is gradually being abandoned. The relative density of gases is often measured with respect to dry air at a temperature of \(20^{\circ} \mathrm{C}\) and a pressure of 101.325 kPa absolute, which has a density of \(1.205 \mathrm{~kg} \cdot \mathrm{~m}^{-3}\). Relative density with respect to air can be obtained by formula 1.

(1) \[ R D=\tfrac{\rho_{g a s}}{\rho_{a i r}} \]

Where:

\(\boldsymbol{\rho}_{\text {gas }}\) - density of the measured gas \(\left[\mathrm{kg} . \mathrm{m}^{-3}\right]\)

\(\boldsymbol{\rho}_{\text {air }}\) - density of air [ \(\mathrm{kg} . \mathrm{m}^{-3}\) ]

Using formula 2, we calculate the molecular mass of the gas-hydrogen mixture; the data is taken from the gas-hydrogen mixture certificate (Boyadjiev & Georgiev, 2020; Nikolov, 1993).

(2) \[ M_{g m}=\tfrac{\sum_{i=1}^{n} M_{i} \times x_{i}}{100},\left[\mathrm{~kg} . \mathrm{kmol}^{-1}\right] \] Where:

\(\mathrm{M}_{\mathrm{i}}\) - molar mass of component i in the gas-hydrogen mixture \(\left[\mathrm{kg} . \mathrm{kmol}^{-1}\right]\)

\(\mathrm{X}_{\mathrm{i}}\) - percentage content of component i in the gas-hydrogen mixture [mol \%]

Using formula 3, we calculate the critical pressure of the gas-hydrogen mixture; the data is taken from the gas-hydrogen mixture certificate.

(3) \[ P_{\text {crit }}=\tfrac{\sum_{i=1}^{n} P_{\text {criti }} \times x_{i}}{100} \]

Where:

\(\mathrm{P}_{\text {criti }}\) - critical pressure of the i component in the gas-hydrogen mixture [ MPa ]

\(\mathrm{X}_{\mathrm{i}}\) - percentage content of component i in the gas-hydrogen mixture [ \(\mathrm{mol} \%\) ]

Using formula 4, we calculate the critical temperature of the gas-hydrogen mixture; the data is taken from the gas-hydrogen mixture certificate.

(4) \[ T_{c r i t}=\tfrac{\sum_{i=1}^{n} T_{c r i t i} \times x_{i}}{100} \]

Where:

\(\mathrm{T}_{\text {criti }}\) - critical temperature of the i component in the gas-hydrogen mixture [K]

\(\mathrm{X}_{\mathrm{i}}\) - percentage content of component i in the gas-hydrogen mixture [ \(\mathrm{mol} \%\) ]

Formula 5 is used to calculate the density of the gas-hydrogen mixture under standard conditions (Temperature \(=293.15 \mathrm{~K}\); Pressure \(=0.1013 \mathrm{MPa}\) ).

(5) \[ \rho_{g m s t}=\tfrac{\left(\tfrac{\sum_{i=1}^{n} M_{i} \times x_{i}}{100}\right)}{24.04} \]

Formula 6 is used to calculate the relative density of the gas-hydrogen mixture.

(6) \[ \bar{\rho}=\tfrac{\rho_{g m s t}}{1.2045} \]

Where:

\(\rho_{\text {gmst }}\)-density of the gas-hydrogen mixture at standard conditions \(\left[\mathrm{kg} . \mathrm{m}^{-3}\right]\)

1.2045 - density of air at standard conditions [ \(\mathrm{kg} . \mathrm{m}^{-3}\) ]

Formula 7 is used to calculate the derived pressure of the gas-hydrogen mixture.

(7) \[ P_{d e r}=\tfrac{P}{P_{c r i t}} \]

Where:

\(P\)– Pressure in the reservoir [MPa]

\(\mathrm{P}_{\text {crit }}\)– Critical pressure of the gas-hydrogen mixture [MPa]

Formula 8 is used to calculate the derived pressure of the gas-hydrogen mixture.

(8) \[ T_{d e r}=\tfrac{T}{T_{c r i t}} \]

Where:

T – Temperature in the reservoir [K]

\(\mathrm{T}_{\text {crit }}\)– Critical temperature of the gas-hydrogen mixture [K]

Once we have found the derived pressure of a gas-hydrogen mixture with 5, 15, \(25 \% \mathrm{H}_{2}\) content and, accordingly, the derived temperature of the same gas-hydrogen mixture, but we have chosen only two temperatures \(-288.15 \mathrm{~K}, 293.15 \mathrm{~K}\), we can find the supercompressibility coefficient of the gas-hydrogen mixture at different pressures and two temperatures. The data is shown in Table 9,10,11 and is depicted in Graph 1, 2, 3. For this purpose, we have used the nomogram of “Standing and Katz” shown on Figure 2.

From the data in Tables 9, 10, and 11 and Graphs 1, 2, and 3, we can see the dependence of the supercompressibility coefficient and the pressure.

At pressures and temperatures within the following ranges: \(\mathrm{P}=0.1 \mathrm{MPa} \div 70.3 \mathrm{MPa}\); \(\mathrm{T}=278 \mathrm{~K} \div 511 \mathrm{~K}\), the Lee-Gonzalez-Eakin relationship describes the change in viscosity of the gas-hydrogen mixture with sufficient accuracy. Formula 9 is used to calculate the viscosity of the gas-hydrogen mixture (Gerov, 2019).

(9) \(\mu_{g}=A \times e^{B \times \rho_{g}^{C}}\)

Parameters \(\mathrm{A}, \mathrm{B}, \mathrm{C}\), and \(\rho_{\mathrm{g}}\) are determined by the following dependencies (10

(10) \[ \begin{aligned} & \mathrm{A}=\tfrac{\left(9,4+0,02 \times M_{g m}\right) \times(1,8 \times T)^{1,5}}{\left(209+19 \times M_{g m}+1,8 \times T\right) \times 10^{4}} \\ \end{aligned} \]

(11) \(\begin{aligned} & B=3,5+\tfrac{547,77}{T}+0,01 \times M_{g m} \\ \end{aligned}\)

(12) \(\begin{aligned} & C=2,4-0,2 \times B \\ \end{aligned}\)

(13) \(\begin{aligned} & \rho_{g}=\tfrac{0,1202 \times P \times M_{g m}}{Z \times T} \end{aligned}\)

Where:

\(\mu_{\mathrm{g}}-\) viscosity of the gas-hydrogen mixture [mPa.s]

\(\mathrm{M}_{\mathrm{gm}}\)-molar mass of the gas mixture [ \(\mathrm{kg} . \mathrm{kmol}^{-1}\) ]

Z – supercompressibility coefficient

P – the pressure at which the viscosity of the gas-hydrogen mixture is calculated [MPa]

T – the temperature at which the viscosity of the gas-hydrogen mixture is calculated [K]

Result and discussion

Using the developed integrated model for determining the parameters of the reservoir rock when storing gas-hydrogen mixtures containing 5 to \(25 \%\) hydrogen with sufficient accuracy for practical purposes, it is possible to determine the parameters of the gas-hydrogen mixture that determine the flow properties of the reservoir rock. The developed integrated model determines the change in the coefficient of supercompressibility, density, and viscosity at hydrogen concentrations ranging from 5 to \(25 \%\) in a temperature range of 288.15 K to 293.15K and at pressures ranging from 0.1 MPa to 15 MPa. According to the calculations, the density of the gas-hydrogen mixture varies from 0.0306 to \(0.0418 \mathrm{~kg} . \mathrm{m}^{-3}\). It has been established that at \(25 \%\) hydrogen, the coefficient of supercompressibility Z for the gas-hydrogen mixture is described by a different numerical model at a temperature of 288.15 K and 293.15 K in the pressure range from 0.1 to 15 MPa. The viscosity of the gas-hydrogen mixture with \(5-25 \%\) hydrogen varies from 0.01126 to 0.01212 mPa.s.

Conclusions

In order to correctly determine the prospects and possibilities for storing gas-hydrogen mixtures in underground gas storage facilities and to analyze the processes occurring in the formation-bottomhole zone of the well, it is necessary to accurately determine the parameters of the gas-hydrogen mixture. This requires that the main processes occurring in the well-productive horizon system during the storage of gas-hydrogen mixtures be studied and analyzed for each specific site using the developed integrated model. The main processes occurring in the wellbore-productive horizon system depend on the amount of hydrogen in natural gas, which requires accurate determination of the parameters of the gas-hydrogen mixture. Correctly determining the processes occurring in the productive horizon is extremely important for determining whether to complete the well with a horizontal or vertical section (Georgiev, 2023). The data obtained on the parameters of the gashydrogen mixture are extremely important for analyzing the influence of hydrogen on the capacity and flow parameters of the rock formation forming the productive horizon, at the bottomhole zone of the well, the influence of hydrogen during extraction and production on the production tubing column (PTC), and determining the optimal technological regime for injection and production of the gas-hydrogen mixture. The specified parameters of the gas-hydrogen mixture can be used in the design of hybrid heating systems (Karadjov, 2022).

Depending on the place of establishment, gas-hydrogen mixture storage facilities are divided into: underground gas storage in aquifers; underground gas reservoirs in depleted gas fields (Cavanagh et al., 2022), taking into account physical, chemical and energy aspects of underground hydrogen storage (Carden & Paterson, 1979).

Author Contribution

Veselin Mitkov conceived of the presented idea, designed the integrated model, adapted the theory and performed the calculations, and analyzed results, wrote the manuscript.

Acknowledgement

This research is supported by the Bulgarian Ministry of Education and Science under the National Program “Young Scientists and Postdoctoral Students – 2” (Stage II 2024 – 2025).

NOTES

1. First Prize in the \(2^{\text {nd }}\)“Natural Sciences and Innovation in Education” Research Paper Competition, dedicated to the \(140^{\text {th }}\) Anniversary of the Birth of Prof. Dimitar Balarew

REFERENCES

Gerov, L. (2019). Natural Gas Production and Storage. UMG “St. Ivan Rilski”. [In Bulgarian]

Lakov, L., Marinova, K., Dimitrova, R., Yovchev, D., Georgieva, M., Gacheva, M., & Toncheva, K. (2024). Mineralogical-petrographic and Tomographic Study of a Pilot Series of “Yellow” Paving Stones. International Journal of Modern Engineering Research, 14(6), 17 – 24.

Nikolov, G. (1993). Transport and Storage of Oil and Gas. UMG ”St. Ivan Rilski”. [In Bulgarian]

Boyadjiev, M. & Georgiev, L. (2020). Running of Gas Infrastructure. UMG ”St. Ivan Rilski”. [In Bulgarian]

Georgiev, L. (2023). Integrated Model for the Determination Development of Gas Field with Horizontal Wells. BMGK Comers. [In Bulgarian]

Karadjov, M. (2022). Design, Construction, Maintenance and Service of Domestic Hybrid Systems Using Natural Gas. Mining and Geology, (9), 42 – 46. [In Bulgarian].

Cavanagh, A. J., Yousefi, S. H., Wilkinson, M & Groenenberg, R. M. (2022). Hydrogen Storage Potential of Existing European Gas Storage Sites in Depleted Gas Fields and Aquifers. H2020 HyUSPRe Project Report. https://www.hyuspre.eu/wp-content/uploads/2022/06/HyUSPRe_ D1.3_Hydrogen-storage-potential-of-existing-European-gas-storagesites_2022.06.29.pdf

Carden, P. O. & Paterson, L. (1979). Physical, Chemical and Energy Aspects of Underground Hydrogen Storage. International Journal of Hydrogen Energy, 4(6), 559 – 569.
