Резюме. The contemporary state strategy for education in Bulgaria focuses natural science education on forming and developing individuals with strong understanding of ecology. In the context of educational strategy, the school subject “Chemistry and Еnvironment” is taught from 7^th to 12^th grade. A review of the curriculum in the relevant textbooks indicates an absence of experimental activity related to the global environmental problems. A step in this direction is this paper which presents some of the selected and developed teaching experiments for illustration one of the global environmental problems – the intensi fication of the greenhouse effect on Earth. The qualities of the teaching experiments are examined through an expert assessment and in a representative sample of students in the 9^th grade in experimental education conditions. For the purposes of the survey , two students’ groups are formed – control and experimental. They are chosen at random by two independent samples of students (40 in each group) with similar results incoming testing for ecological culture. The cognitive performances of students are established by outgoing testing for ecological culture. The data show that the developed teaching experiments provide good conditions to enrich students’ ecological culture and they can be used effectively in secondary school chemistry education.

Ключови думи: teaching chemical experiment, greenhouse effect, environmental education, ecological culture

Introduction

The problems related with environment pollution (intensification of the greenhouse effect, damage to the ozone layer, formation of acid rain, smog, etc.) are the focus of experts’ attention from different scientific areas (Bliznakov & Mitov, 2001; Deriabo & Iasvin, 1996; Heinz & Reinhart, 1991). Solving these global problems is possible only if there are significant changes in social evolution towards maintaining harmony between man, society and nature (Anastas et al., 2009; Fabian, 1987; Firor, 1990).

In this connection the formation of ecological culture of the adolescents is one of the main objectives of education. The achievement of this objective is in the base for optimization of the relationships between man and environment, as the ecological culture is a permanent part of the spirituality and the common culture of personality (Salz & Figueroa, 2009; Taylor et al., 2009).

To enrich the students’ ecological culture are used the possibilities of educational content on the natural school subjects and the methodical system of organization forms, methods and means of teaching (Anastas et al., 2009; Angelacheva & Gergova, 2011; 2013; Gergova & Angelacheva, 2008; Pak, 2012). The leading method in studying chemistry is the teaching experiment which allows close supervision and learning of objects from the environment. It can be used for increasing of the students’ ecological preparation by learning the impact of chemical substances on the environment, chemical methods for its protection and recovery, presence of substances in nature, biological importance, toxic effect, etc. (Angelacheva, 2006; 2014a).

There is a great number of authors who describe and suggest good ideas about teaching experiments which illustrate the global environmental problems (see, for example Kiselev, 2004; Nazarenko & Luchinina, 1993; Rakoczi & Ivanyi, 1999 – 2000; Mak, 1997, etc.). The elaborations of these authors deserve special attention because they focuse on the technique of experiments’ demonstration – materials, methods, apparatus, procedures. Some of authors put emphasis not only on technique but also on methodology of conducting the experiment, i.e. objectives of the experiment, place in educational content, analyze, explanation. However, none of authors has studied the effectiveness of the developed chemical experiments in Science education. That is why the task of this work is to find the answer to research question:

What is the influence of teaching experiments connected with the global environmental problems on the cognitive results of students with an emphasis on their ecological culture in science education?

The outlined problem directs to the objectives of this paper: (1) to select and to develop teaching experiments which can be used for illustration one of the global fi (2) to investigate experimentally the appropriateness of the proposed teaching experiments for enrichment the ecological culture of students in secondary school chemistry education.

The expectation of the educational experiments’ approbation is for a positive influence on the process of learning with an emphasis on the system of ecological knowledge, skills and attitudes of the students towards the environment.

Methodology

To reach the objectives the following research methods as analysis of literature, the quantative content analysis of textbooks, expert evaluation, pedagogical experiment, criterion testing are applied. The analysis of empirical results is carried out with statistical methods: Student’s t-test, Mann-Whitney U-test (Arthur et al., 2012; Bizhkov & Kraevski, 2007; Cohen et al., 2011; Nasledov, 2012; Sidorenko, 2007). The calculations are carried out with the computer program SPSS (Manov, 2001; Nasledov, 2005).

In connection with the requirements to the teaching experiment in chemistry (Angelacheva, 2006; Chernobelskaia, 2000; Gendjova, 2008; Pak, 2012) are selected and designed experiments about the greenhouse effect (Angelacheva, 2013; Buchner et al., 1989; Rasool, 1973). For each of the experiments is created a worksheet in which is reflected the methodological consistency in conducting of the experiments (Appendix 2).

The expert assessment of the qualities of proposed educational experiments is carried out by 26 experts (students – future teachers of chemistry). They perform experiments in laboratory conditions – in the course “Methodology and technique of teaching experiment in chemistry”. The experts evaluate the qualities of the experiments on indicators which are necessary for determination of their methodological and technical characteristics (Table 1 in Appendix 1). It is used an evaluation scale: +1 – the experiment responds to the relevant indicator; 0 – the expert could not determine whether the experiment responds to the indicator; –1 – the experiment does not responds to the indicator.

The experiments with score under 10 points and which do not respond to the top ten indicators are with poor quality and may not be used for experimental activities in teaching chemistry. Experiments with 10 or 11 points which respond to the first ten indicators have good quality and can be used for illustration the learning process. Experiments assessed with 12 and 13 points are with very good quality and those with 14 and 15 points – with excellent quality.

From the proposed for evaluation experiments are selected only those that have very good and excellent quality. The other experiments are processed or eliminated (Angelacheva, 2013).

To establish the effectiveness of the developed teaching experiments for enrichment the ecological culture of students while studying the IVA group of the Periodic table (9th grade) is carried out pedagogical experiment.

The experimental training is conducted with two groups of students on the following versions: version 1 (V1) – in this group of students the experiments are carried out as demonstration; version 2 (V2 ) – the students realize the experiments as laboratory. In version V2 the experiments are commented with an emphasis on the sources of air pollution with “greenhouse” gases, the consequences for the environment of enhancing the greenhouse effect, the ways to reduce the amount of “greenhouse” gases in the atmosphere, etc. Placing the focus of these accents in performance of the experiments can enrich the students’ knowledge about the role of chemistry as a science and a school subject for achieving the sustainable development of society and the environment.

At random of the two groups are formed two independent samples of students (40 in each group) with similar academic achievements by solving the preliminary test “IVA group of the Periodic table and protection of the environment” (Angelacheva & Gergova, 2011). To establish the influence of the developed two versions of training on the students’ cognitive results is used outgoing test (Appendix 3). It is constructed according to the selected criteria and indicators: (a) criterion of ecological knowledge with indicators volume and application of knowledge in different cognitive situations (subtest 1 – tasks from 1 to 5); (b) criterion of a developed attitude towards global environmental problems with indicators intensity and awareness of attitude (subtest 2 – tasks from 6 to 10). The bases for selection of the criteria and indicators are: (a) pedagogical researches that establish the existence of a logical link between the level of the students’ environmental culture and the productivity of learning (Angelacheva, 2014b; Gergova & Angelacheva, 2008); (b) bibliographic reference, which allows to identify the main components of the ecological culture – ecological knowledge, skills and attitudes towards the environment (Deriabo & Iasvin, 1996; Pak, 2012; Salz & Figueroa 2009).

Results and discussion

The need to experimental verification of the formulated hypothesis places in the focus of statistical analysis the question: do the distributions of random variables X and Y, which characterize with numerical values the productivity of learning chemistry in both groups, differ?

The statistical hypotheses are: H0: the distributions of random variables X and Y in the groups trained in both variants are not significantly differ; HA: between the distributions of random variables X and Y in the groups trained in both variants there is a significant difference.

The verification of the statistical hypotheses is carried out on the basis of the data for students’marks from outgoing test. The mark is formed as a sum total of certain number of points for each true solved task (Appendix 3). The data from outgoing test (Table 1) shows better results of students who learned under version V2.

The distributions of random variables X and Y that characterize the productivity of learning chemistry can be traced in Table 2 through typical for statistics variables.

Fisher’s F-criterion

At a confidence level of α = 0.01 and sample size n1= n2= 40 the difference between the variances in groups V1 and V2 is not statistically significant. The condition for equal dispersion of the studied groups is satisfied and the Student’s t-test can be applied.

Student’s t-test

Through this statistical method are exmined the distributions of random variables in groups V1 and V2 in independent samples with an equal sample size n1 = n2 = 40 and a confidence level of α = 0.01.

The higher empirical values of the criterion temp than its critical value t0.01/78 give а reason to accept the hypothesis HA: for both subtests the mean arithmetic values in groups trained in both versions differ significantly. The results of students who learned under version V2 are better than those of the students who learned under version V1. Consequently the realization of laboratory chemical experiments related to the greenhouse effect in studying the IVA group of the Periodic table (version V2) has a positive influence on the productivity of learning chemistry as measured by the selected criteria and indicators. The established difference between the distributions of random variables X and Y which characterize the productivity of learning activity in the studied groups is confirmed by the Mann-Whitney U-test.

Mann-Whitney U-test

Applying U-test is obtained Uemp > Ucr, i.e. the hypothesis H0 is rejected. The statistical analysis confirms the alternative hypothesis HA: the average arithmetic means of the two groups differ substantially. Statistically significant difference can be explained by the positive influence of the proposed teaching experiments on the students’ cognitive performances that reflect students’ ecological knowledge and skills and attitudes towards the environment.

The quantitative and qualitative analysis of the data shows that students trained in version V2, demonstrate better results than students trained in version V1 on the selected criteria. This confirms the hypothesis about the effectiveness of the developed teaching experiments for increasing the environmental culture of students.

The reliability of the cognitive results of students trained in version V2 is measured through a retest (Table 3).

The results from the outgoing test and the retest show similar values of the statistical parameters. There is no statistically significant difference between the data from the test and the retest which confirms the expectation of lasting effect of the proposed teaching experiments on the cognitive results of the tested students.

Conclusions

On the basis of the quantitative and qualitative analysis of the emirical results it can be claimed that in the context of the designed chemical experiments the hypothesis of the research is confirmed and its objectives are carried out. The organized training in version V2 has positively influence on the productivity of learning which is measured by criteria of the ecological culture.

With this work is added a new accents to the theory and practice of teaching chemistry in the following aspects: (a) there are developed worksheets which placed emphasis on methodology and technique of the proposed chemical experiments related to the greenhouse effect on Earth; (b) there are investigated experimentally the qualities of teaching experiments with a view to the possibilities of their application for enrichment the students’ecological culture in the course of teaching chemistry; (c) for the purposes of empirical research is designed a variant of criterion test that can effectively used for diagnostic of students’ environmental knowledge and attitudes in studying the group IV-A Group of the Periodic table in 9th grade.

It should be noted that the selected and developed versions of teaching experiments for illustration the greenhouse effect do not exhaust the whole range of opportunities to visualize the learning process in chemistry. It is necessary for each specific case to look for the most optimum option that not only develops the cognitive interests of the students but also enriches their ecological culture.

APPENDIX 2 Worksheet for the teaching experiment “Influence of carbon dioxide CO2 on the greenhouse effect on Earth”

Purpose of the experiment: to compare the temperatures of the air and carbon dioxide CO2 upon reaching the dynamic temperature equilibrium of gases with the environment.

Place of the experiment in educational content: in studying the IVgroup of the Periodic table.

Necessary substances and materials: plastic bottle of mineral water (3l), thermometer, lamp with lamp shade and 100 W bulb, sodium bicarbonate NaHCO3 (baking soda), vinegar, flask with a volume of 500 cm3, stopper which is fitted with a glass tube.

Experiment:

Version 1. The top of a dry plastic bottle of mineral water (3l) is cut off. A few centimeters from the bottom of the bottle, in its wall is pierced a thermometer (digital or mercury-in-glass). Over the bottle is placed a lamp with lamp shade and 100 W bulb. The air in the bottle is heated until the thermometer reading become constant, i.e. until the system reaches dynamic temperature equilibrium with the environment. The temperature of the air in the bottle is registered.

Then without shuffling the experimental arrangement the bottle is filled with carbon dioxide CO2. It is obtained as in the flask with a volume of 500 cm3 is placed about 10 g sodium bicarbonate NaHCO3 and 250 cm3 vinegar. The flask is closed with a stopper which is fitted with a glass tube. The end of the glass tube is placed in the plastic bottle. It is waited about 10 min to fill up the bottle with carbon dioxide CO2 (check with a lighted match).

The bottle with carbon dioxide CO2 is heated with the lamp while the thermometer reading become constant, i.e. until the system reaches second dynamic temperature equilibrium with the environment. The temperature of carbon dioxide CO2 in the bottle is registered.

Observations and reflections on the experiment: When filling the bottle with carbon dioxide CO2 is completed a fast increasing of the temperature is observed. For example in one of the measurements is recorded an air temperature 42.8°C and a temperature of carbon dioxide CO2 – 48.1°C. This is explained by the fact that 90% of the bulb light is in the infrared region and the carbon dioxide CO2 absorbs infrared waves.

The temperature of carbon dioxide CO2 is reserved for about 10 min then is reduced to the air temperature. The reason for this is that carbon dioxide CO2 is gradually leaves the bottle and it is filled with air.

Conclusions: When increasing the concentration of the “greenhouse” gases (carbon dioxide CO2, water vapor H2O, methane CH4, ozone O3, nitrogen oxides, etc.) the atmosphere becomes more permeable for the short (ultraviolet) wavelengths of sunshine and less permeable to the long (infrared) wavelengths of the Earth’s thermal radiation. This leads to intensification of the greenhouse effect and to changes in the modes of heat and water balance of the planet, to adverse changes in the conditions for the existence and development of organisms.

Comments:

– The upper part of the bottle may not be cuts to keep longer the carbon dioxide CO2 in it.

– When filling the bottle with carbon dioxide CO2 must be careful not to fall in it solution or foam. This can happen if in the flask are placed large quantities of baking soda or vinegar.

– When performing the experiment should not be allowed direct sunshine and air flow.

– The active part of the thermometer can be overshadowed to not directly heated by the lamp.

– To obtain carbon dioxide CO2 are suitable and other substances − sodium carbonate Na2CO3 , potassium carbonate K2CO3, calcium carbonate CaCO3 (marble, chalk) which is treated with different acids (hydrochloric acid HCl, sulphuric acid H2SO4, nitric acid, HNO3, tartaric or citric acid).

Version 2. Two plastic bottles of mineral water with a capacity of 3l are filled with air and carbon dioxide CO2. At the bottom of the bottles are pierced thermometers for reporting temperature change of the gases. Above each of the bottles is placed a lamp. The gases are heated to a constant value of the thermometers reading. The temperatures of the air and CO2 is registered and compared.

Version 3. In the real greenhouse effect participate water, soil, living organisms, etc. which absorb solar energy and radiate back some of that energy. The participation of the environmental components in the greenhouse effect can be demonstrated by using colored paper. It should be thin with negligible heat capacity to require some time to heat. The matt black paper is best but on the other hand the green paper resembles the nature. The paper should be large enough so that it covers all the radiation that enters in the bottle.

Two thermometers are placed at the same distance (10 cm) from the lamp. The one thermometer is left open and the other is placed in a tightly closed with a stopper test tube. Through the stopper is thrust a thermometer. Advance in the test tube is placed a thin green paper which clings to the inner walls of the tube and covers the thermometer. The thermometer readings are recorded and compared at appropriate intervals (for example 1 min). At the beginning of the experiment the reading of the thermometer left open is rising fast and the reading of the thermometer in the tube almost did not change. This is explained by the fact that the heating of the glass tube needs more time.

After about 5 min is determined a significant difference in the readings of the thermometers − at the thermometer outdoor is recorded temperature 29.6°C; at the thermometer overshadowed by the green paper in the tube − 37.8°C.

APPENDIX 3 Test “Greenhouse effect”

Task 1. In what line are referred substances that are persistent components of the air? Point it out.

A. CH4, O2, H2; (0 pts)

B. N2, O2, Ar; (1 pt)

C. SO2, N2, O 2; (0 pts)

D. NO, NO2, CO; (0 pts)

E. O2, H2O (water vapor), NH3. (0 pts)

Task 2. In what line are given substances that are variable components of the air and have “greenhouse” properties? Point it out.

A. H2O (water vapor), CO2, CH4; (1 pt)

B. H2O (water vapor), NO, O2; (0 pts)

C. O3, CH4, N2; (0 pts)

D. SO2, CO, O2; (0 pts)

E. CH4, H2O (water vapor), N2. (0 pts)

Task 3. Natural sources of carbon dioxide CO2 in the environment are:

A. volcanic activity; (1.5 pts)

B. photosynthesis; (0 pts)

C. dissolution of carbon dioxide CO2 in surface waters; (0 pts)

D. decay of organic substances; (1.5 pts)

E. respiration of organisms. (1.5 pts)

Circle the letters of the correct answers.

Task 4. Which of the following reasons for increasing the concentration of carbon dioxide CO2 in the atmosphere are the result of human activity. Circle the letters of the correct answers.

A. felling of forests, especially tropical; (1.5 pts)

B. road transport; (1.5 pts)

C. hot mineral springs; (0 pts)

D. precipitation of carbonates; (0 pts)

E. combustion of fossil fuels. (1.5 pts)

Task 5. Which of the following statements are a reason for intensification the greenhouse effect on Earth? Circle the letters of the correct answers.

A. Entry into the atmosphere of methane CH4, halogen derivatives of hydrocarbons, nitrogen oxides, which absorb infrared radiation from 50 to 100 times more powerful than carbon dioxide CO2. (1.5 pts)

B. Use of carbon dioxide CO2 for production of aerated drinks. (0 pts)

C. Increasing concentration of carbon dioxide CO2 into the atmosphere which absorbs in the infrared region. (1.5 pts)

D. Increasing the concentration of water vapour and ozone O3 in the atmosphere which absorb in the ultraviolet and infrared region. (1.5 pts)

E. Formation of acid rains and their impact on the natural resources of carbonates. (1.5 pts)

Task 6. What do you think is the importance of the natural greenhouse effect. Circle the letters of the correct answers.

A. maintains the ecological balance; (1.5 pts)

B. leads to drying of the marshes accompanied by intensive oxidation of peat; (0 pts)

C. creates an average annual temperature on Earth’s surface about 17°C; (1.5 pts)

D. improves the combustion in the internal combustion engines; (0 pts)

E. provides the progress of carbon, nitrogen, oxygen and water cycles in nature. (1.5 pts)

Task 7. What do you think might be the consequences on the environment from intensification of the greenhouse effect? Circle the letter of the correct answer.

A. change the Earth’s climate; (0 pts)

B. increasing the level of seas and oceans; (0 pts)

C. change of the conditions for existence and development of the living organisms on Earth; (0 pts)

D. defrosting of the territories of Siberia and Northern Canada, which will lead to the release of new quantities of carbon dioxide CO2 and methane CH4 included in soil at low temperatures; (0 pts)

E. all of the above. (1 pt)

Task 8. Which of the following actions would you recommend as an effective measure to reduce the amount of greenhouse gases in the atmosphere? Circle the letters of the correct answers.

A. Organization of large-scale afforestation campaigns. (1.5 pts)

B. Increasing the efficiency of machines which use fossil fuels. (1.5 pts)

C. Development and implementation of solar and other renewable energy sources. (1.5 pts)

D. Usage of coal, oil, natural gas as energy sources. (0 pts)

E. Development of technologies waste carbon dioxide CO2 absorbtion or connection with appropriate substances. (1.5 pts)

Task 9. What do you think would happen if the carbon dioxide CO2 leaves the Earth’s atmosphere? Circle the letters of the correct answers.

A. Life on Earth will disappear. (1.5 pts)

B. The synthesis of organic substances by plants will hamper. (1.5 pts)

C. The amount of acid rain will increase. (0 pts)

D. The forest fires will facilitate. (0 pts)

E. There will be no change. (0 pts)

Task 10. To what extent you are agree with the following statements? In table 1 point only one answer on each line out.

REFERENCES

Anastas, P.T, Levy, I.J. & Parent, K.E. (2009). Green chemistry education: changing the course of chemistry. Washington: American Chemical Society.

Angelacheva, А. (2006). Methods and technique of experiment in chemistry teaching: part I. Plovdiv: Plovdiv University Press [In Bulgarian].

Angelacheva, A. & Gergova E. (2011). Environmental education in teaching chemistry. Plovdiv: Plovdiv University Press [In Bulgarian].

Angelacheva, A. (2013). Teaching experiments which illustrate the greenhouse effect. Scientific researches of the Union of scientists – Plovdiv, Series B, Technique and technology, 16, 112 – 116 [In Bulgarian].

Angelacheva, A. & Gergova, E. (2013). Didactical tools for developing an environmental culture of pupils in chemistry in the secondary school. Chemistry, 22, 532 – 543 [In Bulgarian].

Angelacheva, A. (2014a). Chemistry – observations and experiments. Plovdiv: Plovdiv University Press [In Bulgarian].

Angelacheva, A. (2014b). Diagnostics of the environmental culture of pupils: a case study – teaching of the VI-A group of the periodic table in 8th grade. Chemistry, 23, 192 – 207 [In Bulgarian].

Arthur, J., Waring, M., Coe, R. & Hedges, L.V. (2012). Research methods and methodologies in education. London: SAGE.

Bizhkov, G. & Kraevski, V. (2007). Methodology and methods of pedagogical researches. Sofia: Sofia University Press [In Bulgarian].

Bliznakov, G. & Mitov, I. (2001). Introduction into chemical problems of the environment and into ecological legislation, standartization and monitoring. Sofia: Prof. Marin Drinov Academic Publishing House [In Bulgarian].

Büchner, K.H., Moretto, H.H.. & Woditsch, P. (1989). Industrielle anorganische Chemie. Weinheim: VCH.

Chernobelskaia, G.M. (2000). Methodology of chemistry teaching. Moscow: VLADOS [In Russian].

Cohen, L., Manion, L. & Morrison, K. (2011). Research methods in education. New York: Routledge.

Deriabo, S.D. & Iasvin, V.A. (1996). Ecological pedagogy and psychology. Rostov: Fenics Publishing House [In Russian].

Fabian, P. (1987). Atmosphäre und Umwelt. Berlin: Springer.

Firor, J. (1990). The chandging atmosphere. New Haven: Yale University Press.

Gendjova, A. (2008). A study of quality of home chemistry activity tools. Chemistry, 17, 98 – 108 [In Bulgarian].

Gergova, E. & Angelacheva, A. (2008). Design of a technology towards the environmental education through teaching and learning chemistry. Chemistry, 17, 16 – 24 [In Bulgarian].

Heinz, A. & Reinhart, G. (1991). Chemie und Umwelt. Wiesbaden: Friedr. Vieweg & Sohn.

Kiselev, S. (2004). Demonstration of the greenhouse effect. Physics in School, No, 8, 48 – 50.

Mak, S.-y. (1997). The Greenhouse-еffect еxperiment. The Physics Teacher, 35, 504 – 508.

Manov, A. (2001). Statistics with SPSS. Sofia: Trakia-M Publishing House [In Bulgarian].

Nasledov, А.D. (2005). SPSS: computer data analysis in psychology and social sciences. St. Petersburg: Piter [In Russian].

Nasledov, А.D. (2012). Mathematical methods for psychological researches: analysis and interpretation of data. St. Petersburg: Rech [In Russian].

Nazarenko, V.M. & Luchinina, N.V. (1993). School chemical experiment in the ecological education. Chemistry in School, No. 6, 47 – 53 [In Russian].

Pak, M.S. (2012). Theory and methods of chemistry. St. Petersburg: Trio [In Russian].

Rakoczi, F. & Ivanyi, Z. (1999-2000). Water vapour and greenhouse effect. Geofizika, 16 – 17, 65 – 72.

Rasool, S. (1973). Chemistry of the lower atmosphere. New York: Plenium Press.

Salz, S. & Figueroa, D. (2009). Prepare for PISA: natural sciences. Sofia: Prosveta [In Bulgarian].

Sidorenko, E.V. (2007). Methods for mathematical processing in psychology. St. Petersburg: Rech [In Russian].

Taylor, N., Littledyke, M., Eames, C. & Coll, R.K. (2009). Environmental education in context: an international perspective on the development of environmental education. Rotterdam: Sense.
