Резюме. Baby powder based talc (BP) is modified by keeping in 0.3 M HCl solution at room temperature for 24 hours. The product, acid modified baby powder based talc, is called “modified-BPT”. Modified-BPT is investigated for their usefulness in the stationary phase of Thin-Liquid Chromatography (TLC). The separability of the components of a commercial ink has been tested on modified-BPT layers successfully. These results may be also said for the adaptability or validity on column chromatography.

Ключови думи: analytical chemistry, TLC, baby powder , modi fied baby powder talc, chromatography

Introduction

Chromatography is one of the most important analytical techniques used to separate components of mixtures. In chromatographic separations and teaching chromatography, the thin-layer chromatography (TLC) is often used as a quick, easy and separation method extensively used for organic species but rarely used for inorganic samples. While TLC is not common for inorganic cations, in the literature, some researchers have recently revealed that its utility is also valid for inorganic samples (Ergül, 2004; 2006; 2008; Mohammad et al., 2002; 2004; Mohammad & Jabeen, 2003; Mohammad & Agrawal, 2000; 2002; Mohammad, 1997; Mohammad & Khan, 1995; Ajwal et al., 1988; 1989a; 1989b; Mohammad & Fatima, 1987; Savaşcı & Akçay, 1999; Gürkan & Savaşcı, 2005).There are numerous applications of TLC for the qualitative and quantitative analysis of components of natural and artificial mixtures (Curtright et al., 1999; Baum & Shanks, 1975; Anwar, 1963; Goller, 1963; Rolins, 1963; Frodyma & Frei, 1969).

A number of minerals have previously been used as TLC adsorbents, including talc (Walsch, 1967), activated bentonite (Popov & Stefanov, 1968), kaolinite (Fayez et al., 1967), china clay (Sheen, 1971), activated bleaching earth (Hashimoto et al., 1965), modi fied perlite (Karaka ş & Yüksel, 1998), acid modi fi ed diatomaceous earth (Ergül et al., 2005; Ergül & Savaşcı, 2008). Silica gel and alumina have been used most frequently as adsorbents for the separation to components of the mixtures on TLC applications (Sthal, 1969).

Successful TLC separation depends on the properties of the sample, and also those of the mobile and stationary phases. Finding suitable resolution for a TLC application involves usually by changing the properties of mobile phase only. It does not involve by changing the properties of stationary phase although a possibility sorbent is present to change the properties of stationary phase (Ergül et al., 2005; Ergül & Savaşcı, 2008).

On TLC, adsorbent materials should be inexpensive and easily available. Besides, commercial baby powders are easily available products, and they are mixtures based on talc or corn starch as major components. Some commercial baby powders and their contents were given (Ergül, 2009). Talc as a major component of baby powder is a magnesium silicate mineral with the composition \(\mathrm{Mg}_{3}\left[\mathrm{Si}_{4} \mathrm{O}_{10}\right]\) \((\mathrm{OH})_{2}\) and a layered lattice structure. Its available surface for absorption markedly depends on particle size. Talc has been used as a TLC adsorbent to separate fatty acids, lanatosides, amino acids, the sugars and the flavonoids (Walsch, 1967; Sthal, 1969). In addition, the retention factors and separability of commercial ink components on thin layers prepared by acid modifi ed diatomaceous earth (Ergül et al., 2005), baby powder based talc (Ergül, 2009) and silica gel \(60 \mathrm{GF}_{254}\) (Ergül et al., 2005; Ergül, 2009) were examined and were discussed in the context of the variation of the stationary and mobile phases.

In practice, the modifi cation of the baby powder based talc has not been investigated yet. Therefore, in this study, the baby powder (BP) based talc was modifi ed by refluxing with acid processes. Modified BP (modified BPT) was used as stationary phase. The commercial ink samples were run on activated thin layers of acid modified BPT. The retention factors (\(\mathrm{R}_{\mathrm{F}}\) ) and separabilty of commercial ink components were examined and discussed in the context of the variation of stationary and mobile phase properties and the adaptability or validity on column chromatography. In addition, this layers was compared with already known \(\mathrm{R}_{\mathrm{F}}\), and separability of ink compenents on activated baby powder and \(\mathrm{Si}-60 \mathrm{GF}_{254}\) layers on cited literature.

Experimental

Chemicals, reagents, materials

Ammonia, n-butanol, acetic acid and ethanol were purchased from Merck (Darmstadt, Germany). Baby powder of Bebeten trademark was used to prepare modified BPT. Red and blue inks of Pelikan 4001 were used as the sample on TLC applications.

\(2 \mathrm{~mol} \mathrm{~L}^{-1}\) ammonia solution was prepared by adding distilled water to 150.4 mL of ammonia (\(\mathrm{d}=0.904 \mathrm{~g} / \mathrm{mL}, 25 \%\) ) on 1.0-L volumetric flask. Butanol-ethanol-2M ammonia (\(3: 1: 1, \mathrm{v} / \mathrm{v}\) ) and butanol-acetic acid-water (\(12: 3: 5, \mathrm{v} / \mathrm{v}\) ) mixtures were used as mobile phases. Modi fied BPT was used as stationary phases. The plates were prepared using a Loughborough-Griffin&George, TLC Unikit (Leicestershire, England). All the chemicals were of analytical grade.

Modifi cation of BP

200 mL of \(0.3 \mathrm{~mol} \mathrm{~L}^{-1} \mathrm{HCl}\) was poured into a beaker and \(\mathrm{BP}(40 \mathrm{~g} \lt 50 \mu \mathrm{~m}\) particle size) was added to it and then was shaken at room temperature for 24 h. After, this suspension was filtered and washed until the filtrate gave a negative reaction for \(\mathrm{Cl}^{-}\). The product was dried at \(110^{\circ} \mathrm{C}\) for 24 h and then sized with a \(50 \mu \mathrm{~m}\) sieve. The product, acid modified baby powder based talc, was named modifi ed-BPT.

Preparation of thin layer plates from modifi ed-BPT

Slurries of modified-BPT in ethanol (\(1: 1.5, \mathrm{w} / \mathrm{v}\) ) were spreaded onto clean glass plates (\(7.5 \times 15 \mathrm{~cm}\) ) with a thickness of \(250 \mu \mathrm{~m}\) using a spreader kit. Non activated plates were obtained by keeping the plates at room temperature for 2 h. They were activated by heating in an oven at \(110^{\circ} \mathrm{C}\) for 1 h. For TLC applications, activated plates were used.

TLC applications

The red and blue ink samples and a mixture of both (\(1: 1, \mathrm{v} / \mathrm{v}\) ) were spotted with micropipettes on the starting line which was 2 cm from the bottom of the activated modified- BPT plates. The original spots on the layers were dried at room temperature for 5 min. A pencil line was marked 8 cm above the starting line of each plate. Two developing chambers measuring 10x50x20 cm were used. Sixty milliliters of butanol-ethanol-2M ammonia (\(3: 1: 1, \mathrm{v} / \mathrm{v}\) ) was poured into one chamber and 60 mL of butanol-acetic acid-water (12:3:5, v/v) into the other. The lids of the chamber were closed and the chambers allowed standing for 25 min to ensure saturation of the air in each chamber with solvent vapors. Then, activated modifi ed BPT plates with their ink samples were carefully immersed in the chambers. The plates, which were taken out of the chambers when the solvent fronts reached 8.0 cm above the starting line of each plate, were dried. The migration distances of the solvent (Zf each plate, were dried. The migration distances of the solvent \(\left(\mathrm{Z}_{\mathrm{f}}\right)\) and of each spot (\(\mathrm{Z}_{\mathrm{x}}\) ) were then measured.

The Measurements of pH

10 % süspensions of BP, modified BPT and \(\mathrm{Si}-60 \mathrm{GF}_{254}\) were individually prepared. The pH values of these süspansions, butanol-ethanol-2 M ammonia \((3: 1: 1\), \(\mathrm{v} / \mathrm{v}\) ) and butanol-acetic acid-water (12:3:5, v/v) mixtures were individually measured using pH meter. From the measurations, when the pH values of acidic and basic mobile phases were respectively 3.00 and \(11.00, \mathrm{pH}\) values of the slurries of Si-\(60 \mathrm{GF}_{254}\), BP and modified-BP as stationary phases were respectively \(7.00,9.00\) and 7.50.

Result

Successful TLC separation depends on the properties of the sample and also those of the mobile and stationary phases. Finding suitable resolution for a TLC application usually involves changing the properties of the mobile phase only. It does not involve changing the properties of the stationary phase.

a: Butanol:acetic acid:water mixture (12:3:5, v:v:v), b: Butanol-ethanol-(2M) ammonia mixture (\(3: 1: 1, \mathrm{v} / \mathrm{v}\) ) Number of repeated runs: 3

In this study, to prepare a new stationary phase, the baby powder based talc was modifi ed by refl uxing with 3M HCl and modifi ed BPT was used as stationary phase for normal-phase TLC applications of commercial red and blue ink samples. Because of the ink components being acidic, basic or neutral, and also soluble in water, basic butanol-ethanol-2M ammonia (\(3: 1: 1, \mathrm{v} / \mathrm{v}\) ) and acidic butanol-acetic acid-water (12:3:5, v/v) mixtures were used as mobile phases. The chromatograms were given in Figs 1- 2 for the activated modified BPT plates. The developed spots of ink compenents could be determined easily with the naked eye. The retention factors \(\left(\mathrm{R}_{\mathrm{F}}\right)\) of the ink components were calculated from \(\mathrm{R}_{\mathrm{F}}=\mathrm{Z}_{\mathrm{x}} / \mathrm{Z}_{\mathrm{f}}\). The same procedure was also applied to the activated BP and the modified-BPT layers. From the chromatograms, the RFrom the chromatograms, the \(R_{F}\) values of ink components were given in Table I.

Separability on TLC and expected resolution on CC

On TLC application, the resolution is relation to separability parameter (\(r\) ) in context of different between \(\mathrm{R}_{\mathrm{F}}\) values of component couple. In addition, the separations by TLC are precursor for the applications on column chromatography. The retention factors and separability of components in the sample using TLC is related to the elution time and separability on column chromatography. In this context, the \(r\) parameter is quantitatively the measurement of expected resolution on column chromatography in this context of the separability of components on thin layer chromatography. It is calculated using Eq. (1) (Duncan, 1962).

(1) \[ \mathrm{r}=\tfrac{\mathrm{a}}{\mathrm{~b}+0.1 \mathrm{a}} \]

In Eq. (1), \(a\) is \(\mathrm{R}_{\mathrm{F}}\) value of the fast moving substance A and \(b\) is \(\mathrm{R}_{\mathrm{F}}\) value of the slow moving substance B on the chromatograms respectively. The separability parameter is dimensionless number, which indicates whether separation on column chromatography is carried out or not. When mobile and stationary phases are same for column and thin layer chromatographic systems, it is said that the separation of two components may be possible when \(r\) is \( \gt 1\) (Duncan, 1962). In this study, \(r\) values of red and blue ink component couples obtained on thin layer chromatographic applications were given in Table 2.

a: Butanol:acetic acid:water mixture (12:3:5, v:v:v), b: Butanol-ethanol-(2M) ammonia mixture (\(3: 1: 1, \mathrm{v} / \mathrm{v}\) ) Number of repeated runs: 3.

Discussion

Evalation of Modifi cation

To prevent interference and the reacting of activated BP layer with acidic mobile phase was modified by refluxing with 3M HCl solution. The reacting and interfering inorganic compounds (such as ZnO, magnesium stearate) were converted to soluble salts and removed from baby powder based talc by refl uxing with acid processes. When pH value of baby powder based talc was 9.0, pH of modifi ed BPT was 7.5. Through the modifi cation process, the pH of the baby powder based talc changed from 9.0 to 7.5. Although the layers of baby powder based talc react with acidic mobile phase, modifie BPT layers do not react with acidic mobile phase. In addition, chromatographic parametres (such as \(\mathrm{R}_{\mathrm{F}}\) and \(r\) ) of both layers were differend from each other. These qualitative and quantitative indicators suggested that some interfering organic and inor ganic compounds had been successfully removed and mofi difaciton was succcesfuly carried out.

Evalation of Chromatograms

As shown in Figs 1 – 2, on the activated BP and modified BPT layers, the red ink was separated into yellow and pink spots when the solvent front values were \(\geq 2.0 \mathrm{~cm}\) for both acidic and basic mobile phases. The blue ink was separated into two main spots (dark blue and green) on running with the acidic and basic mobile phases when the solvent front was \(\geq 8.0 \mathrm{~cm}\). However, the blue ink components were not separated even when the solvent front was \(\geq 8.0 \mathrm{~cm}\) on running with basic mobile phase on \(\mathrm{Si}-60 \mathrm{GF}_{254}\) layer. In addition, dark blue spot has undergone to tailing, the other spots have not. The reason for tailing lies in the fact that it is related with both load capacity of the stationary phase and the amount of the components in the spots. Although the same amount of sample has been spotted to all of three kind layers, the dark blue spot on activated BP and activated modified BPT layers has been developed with tailing on running with acidic mobile phase, but the one on \(\mathrm{Si}-60 \mathrm{GF}_{254}\) has been developed without tailing. This situation indicates that the load capacity of \(\mathrm{Si}-60 \mathrm{GF}_{254}\) layer for dark blue is higher than those of activated BP and activated modified BPT layers. On the other hand, the area of dark blue spot is larger than those of green for three kinds of layers. This observation reveals that the amount of dark blue component on the sample is higher than those of green.

As shown in Figs 1 – 2, the chromaogram in Fig. 2b obtained with basic mobile phase on the activated BP layer is beige although the bottom section chromatogram in Fig. 1b obtained with acidic mobile phase on the activated BP layer is tight and turns into dirty beige. Those spoilt structures and color changing are qualitative indicators of chemical interaction of the stationary phase with mobile phase. The spoilt structure and color change are results of chemical interaction between the talc, \(\mathrm{Mg}_{3}\left[\mathrm{Si}_{4} \mathrm{O}_{10}\right](\mathrm{OH})_{2}\), on activated BP layer and the \(\mathrm{CH}_{3} \mathrm{COOH}\) in acidic mobile phase. On the other hand, no physical deformation and color change have been observed on the activated \(\mathrm{Si}-60 \mathrm{GF}_{254}\) and modified BPT layers qualitatively . Consequently , it can be said that the modi fi ed BPT and \(\mathrm{Si}-60 \mathrm{GF}_{254}\) layers do not react with acidic and basic mobile phases although the activated BP layer undergoes to chemical decomposition on the application with the acidic mobile phase. However, it is possible to conclude that layers of activated BP layer have been successfully applied to the separation of components of ink samples also.

Effect of mobile phase changing to \(R_{F}\)

In Table I, for modified BPT layers, when the acidic mobile phase was replaced by the basic one, \(\mathrm{R}_{\mathrm{F}}\) value changed from \(0.34 \pm 0.02\) to \(0.73 \pm 0.04\) for the yellow component. \(\mathrm{R}_{\mathrm{F}}\) values for the pink, dark blue and green components did not change significantly although acidic mobile phase was replaced by the basic one. For \(\mathrm{Si}-60-\) \(\mathrm{GF}_{254}\) layers, when the acidic mobile phase was replaced by the basic one, \(\mathrm{R}_{\mathrm{F}}\) values changed significantly from \(0.91 \pm 0.05\) to \(0.71 \pm 0.04\) for the pink component. \(\mathrm{R}_{\mathrm{F}}\) values for the yellow, dark blue and green components did not change although mobile phase changed by basic one. For the activated BP layers, when acidic mobile phase was replaced by basic one, \(\mathrm{R}_{\mathrm{F}}\) values of components of ink samples change. On the basis of the experimental data and their changing patterns, the polarity , acidic and basic properties of the mobile phase was effective in contributing to the chromatographic behavior of all the dye components because of water soluble property.

Effect of Stationary Phase Changing to \(R_{F}\)

In Table I, when the modi fied BPT layer was replaced with the activated BP one, when using acidic mobile phase, the \(\mathrm{R}_{\mathrm{F}}\) value changed significantly from 0.34 \(\pm 0.02\) to \(0.67 \pm 0.03\) for the yellow component only. \(\mathrm{R}_{\mathrm{F}}\) values for the pink, dark blue and green components did not change significantly by both acidic and basic mobile phases although the modifi ed BPT layer was replaced by the activated BP one. On the other hand, when the modifi ed BPT layer was replaced with the activated Si-\(60 \mathrm{GF}_{254}\) one, when using acidic mobile phase, the \(\mathrm{R}_{\mathrm{F}}\) value changed significantly from \(0.09 \pm 0.01\) to \(0.49 \pm 0.03\) for the dark blue component. In addition, when the modified BPT layer was replaced with the activated \(\mathrm{Si}-60 \mathrm{GF}_{254}\) one, when using basic mobile phase, the \(\mathrm{R}_{\mathrm{F}}\) values changed significantly the dark blue, pink and yellow components. \(\mathrm{R}_{\mathrm{F}}\) value for the green component did not change significantly by basic mobile phase although the modified BPT layer was replaced by the activated \(\mathrm{Si}-60 \mathrm{GF}_{254}\) one. The chemical composition, pH and physical properties of the modified BPT, activated BP and Si-\(60 \mathrm{GF}_{254}\) are significantly different from each others. Thus, these data and chromatographic behavior patterns could not be explained easily. As a result, the retention of various molecules on stationary phase is generally explained by considering the interactions between polar \(\mathrm{Si}-\mathrm{OH}\) groups on surface of layer and molecules in sample, e.g., hydrogen bridging, dipole-dipole and Van der Waals. Thus, the change of \(\mathrm{R}_{\mathrm{F}}\) values of ink components on TLC applications on both adsorbents is related to surface activity of the layers.

Separability on TLC and expected resolution on CC

The data for the red and blue ink components obtained by using the acidic and basic mobile phases on the activated \(\mathrm{Si}-60 \mathrm{GF}_{254}\), the activated BP and the modified BPT layers are given Tables II. In Table 2, the r values for pink-yellow couple which belong to red ink on the activated \(\mathrm{Si}-60 \mathrm{GF}_{254}\), the activated BP and the modified BPT layers, when using acidic mobile phase are \(1.932,1.196\) and 2.166, respectively. In Table 2, the r values for pink-yellow couple on the activated Si-60GF254, the r values for pink-yellow couple on the activated \(\mathrm{Si}-60 \mathrm{GF}_{254}\), the activated BP and the activated BPT layers, when using basic mobile phase are \(1.507,1.67\) and 1.032, respectively. Because the r values are \( \gt 1.0\) for pink-yellow couple, these chromatographic systems are effective to separate this couple. As a result, pink and yellow spots belong to red ink are successfully separated on all of chromatographic systems.

In Table 2, the r values for green-dark blue couple which belongs to on the activated Si-60GF \({ }_{254}\), the activated BP and the modified BPT layers, when using acidic mobile phase are \(1.026,4.558\) and 3. 960, respectively. \(r\) values for greendark blue couple which belongs to on the activated \(\mathrm{Si}-60 \mathrm{GF}_{254}\), the activated BP and the modified BPT layers, when using basic mobile phase is \(0.909,5.192\) and 3.529, respectively. Yet these components of blue ink have developed only one spot without separation on activated \(\mathrm{Si}-60 \mathrm{GF}_{254}\) layer. Because r value is \( \gt 1.0\) for green-dark blue-green couple, the activated BP and the activated BPT layers are successful to separate this couple on TLC applications using both kinds of mobile phases. However, \(\mathrm{Si}-60 \mathrm{GF}_{254}\) layer is not successful to separate this couple because of \(\mathrm{r} \lt 1.0(\mathrm{r}=0.909)\) and spot overlapping. Consequently, to separate the components of blue ink, the activated BP and activate BPT layers are more successful than \(\mathrm{Si}-60 \mathrm{GF}_{254}\) layers on TLC applications using both kinds of mobile phases.

As seen in Table 2, \(r\) parameters of pink-yellow, pink-green, pink-dark blue, greendark blue, green-yellow and yellow-dark blue ink component couples were bigger than 1.000 on all of chromatographic systems using the activated modifi ed-BPT layers. Therefore, it can be said that all of ink component couples were successfully separated on all of thin layer chromatographic systems using the modifi ed BPT layers because of \(r \gt 1.000\). In addition, the best analytical separ > 1.000. In addition, the best analytical separations of pink-yellow and green-yellow ink component couples on all of the chromatographic applications were obtained when using acidic mobile phase butanol:acetic acid:water mixture (12:3:5, \(\mathrm{v}: \mathrm{v}: \mathrm{v})\) as mobile phase on the activated modified BPT layer.

As seen in T able 2, \(r\) parameters of pink-yellow , pink-green, pink-dark blue ink compenent couples were bigger than 1.000 on all chromatographic systems.

Therefore, it can be said that these complex couples were successfully separated on all TLC systems because of \(r \gt 1.000\). In addition, the best analytical separ > 1.000. In addition, the best analytical separation of pink-green ink compenent couple was obtained when using butanol:acetic acid:water mixture \((12: 3: 5, \mathrm{v}: \mathrm{v}: \mathrm{v})\) as mobile phase on the activated \(\mathrm{Si}-60 \mathrm{GF}_{254}\) layer. The best analytical separations of pink-dark blue, green-dark blue and yellowdark blue ink compenent couples were obtained when using butanol-ethanol-(2M) ammonia mixture (\(3: 1: 1, \mathrm{v} / \mathrm{v}\) ) as mobile phase on the activated BP layer.

As seen in Table 2, \(r\) parameters of green-dark blue, green-yellow and yellowdark blue were smaller than 1.00 on some chromatographic systems. On these chromatographic systems, the mobile phase was butanol-ethanol-(2M) ammonia mixture (\(3: 1: 1, \mathrm{v} / \mathrm{v}\) ) for green-dark blue and yellow-dark blue ink component couples when the stationary phase was activated \(\mathrm{Si}-60 \mathrm{GF}_{254}\) phase. In addition, \(r\) value for green-yellow ink component couple was smaller than 1.0 when using butanol:acetic acid:water mixture (12:3:5, v:v:v) as mobile phase on activated BP layer. As a result, although these chromatographic systems were not successfully separated ink component couples cited, other chromatographic systems were successfully separated ink component couples. The mutual separation for all of ink components was obtained when using butanol:acetic acid:water mixture (12:3:5, \(\mathrm{v}: \mathrm{v}: \mathrm{v}\) ) as mobile phase on activated \(\mathrm{Si}-60 \mathrm{GF}_{254}\) and modified BPT layers. In addition, the mutual separation for all of ink components was obtained when using butanol-ethanol-(2 M ) ammonia mixture (\(3: 1: 1, \mathrm{v} / \mathrm{v}\) ) as mobile phase on activated BP and modified BPT layers. As a result, the best mutual separations are carried out on these chromatographic systems cited. It can be said that this result is also valid for column chromatography in context of \(r\) parameters of ink component couples.

Conclusions

This work was carried out to modifie baby powder based talc and to investigate the useful for TLC and the adaptability or validity on column chromatography of modified BPT. In light of these studies, conclusions are as follows: (a) the baby powder based talc was succesfully modified to the modified BPT by refl uxing with 3 M HCl. Being different of the pH values and chromatographic properties of BP and modified BPT are quantitative indicators of modification; (b) the modifi ed BPT and \(\mathrm{Si}-60 \mathrm{GF}_{254}\) layers do not react with acidic and basic mobile phases although the activated BP layer undergoes to chemical decomposition on the application with the acidic mobile phase; (c)pink and yellow spots belong to red ink are successfully separated on all of chromatographic systems; (d) to separate the components of blue ink, the activated BP and activate BPT layers are more successful than Si\(60 \mathrm{GF}_{254}\) layers on TLC applications using both kinds of mobile phases; (e) the best analytical separations of pink-yellow and green-yellow ink component couples on all of the chromatographic applications were obtained when using acidic mobile phase butanol:acetic acid:water mixture (12:3:5, v:v:v) as mobile phase on the activated modified BPT layer.

REFERENCES

Ajmal, M., Mohammad, A. & Fatima, N. (1988). Separation of microgram quantities of cadmium (II) from milligram quantities of zinc (II) and of copper (II) from nickel (II) and cobalt (II) with

aqueous sodium formate halogen anion systems. Microchem. J., 37, 314 – 321.

Ajmal, M., Mohammad, A. & Fatima, N. (1989a). Sodium molybdate impregnated silica-gel layers as stationary phase for chromatographicseparation of metal-ions. J. Indian Chem. Soc., 66, 425-426.

Ajmal, M., Mohammad, A., Fatima, N. & Khan, A.H. (1989b). Determination of microquantities of mercury (II) with preliminary thin-layer chromatographic-separation from mercury (I), lead (II), nickel (II), and copper (II) on acid-treated silica-gel layers - recovery of mercury (II) from river waters and industrial wastewater. Microchem. J., 39, 361 – 371.

Anwar, M.H. (1963). Separation of plant pigments by thin layer chromatography. J. Chem. Educ., 40, 29 – 30.

Baum, D.E. & Shanks, R.A. (1975). A novel method for quantitative thin layer chromatography. J. Chem. Educ., 52, 738.

Curtright, R.D., Emry, R. & Markwell, J. (1999). Student understanding of chromatography: a hands-on approach. J. Chem. Educ., 76, 249 – 251.

Duncan. G.R. (1962). The transfer of chromatoplate resolutions to lar ge scale separations on adsorbtion colums. A new apparatus for producing thin layers. J. Chromatogry A, 8, 37 – 43.

Ergül, S. (2004). Qualitative analysis of \(\mathrm{Cu}^{2+}, \mathrm{Co}^{2+}\) and \(\mathrm{Ni}^{2+}\) cations using thin layer chromatography. J. Chromat. Sci., 42, 121 – 124.

Ergül, S. (2006). Investigation of thin-layer chromatography properties of some transition metal complexes based on ditiocarbamates. J. Chromat. Sci., 44, 543 – 547.

Ergül, S. (2008). Linkage between separation of Cu 2+, Co 2+, and Ni 2+ on of \(\mathrm{Cu}^{2+}, \mathrm{Co}^{2+}\), and \(\mathrm{Ni}^{2+}\) on TLC and crystal fi eld theory. J. Chromat. Sci., 46, 907 – 911.

Ergül, S. (2009). Using of baby powder based talc as a thin layer chromatography adsorbent: teaching chemical experiment. Chemistry, 18, 42 – 55.

Ergül, S. & Savaşcı, Ş. (2008). Acid modified diatomaceous earth - a sorbent material for thin layer chromatography. J. Chromat. Sci., 46, 308 – 315.

Ergül, S., Kadan, İ., Savascı, Ş. & Ergül, S. (2005). Diatomaceous earth as a principle stationary phase component on TLC. J. Chromat. Sci., 43 , 394 – 400.

Fayez, M.B.E., Gad, G., Nasr, I. & Radvan, A.S. (1967). Sinai clay, a new adsorbent for thin layer chromatography. J. Chem. UAR, 10: 49 – 54.

Frodyma, M.M. & Frei, R.W. (1969). Reflectance spectroscopic analysis of dyes separated by thin layer chromatography. J. Chem. Educ., 46, \(522-\) 524.

Goller, E.J. (1965). Cation analysis with thin layer chromatography. \(J\). Chem. Educ., 42, 442 – 443.

Gürkan, R. & Savaşcı, Ş. (2005). Investigation of separation and identifi cation possibilities of some metal-DEDTC complexes by sequential TLC-IR systems. J. Chromat. Sci., 43, 324 – 330.

Hashimoto, A., Hitorani, A. & Mukai, K. (1965). Separation of alcohols by thin layer chromatography on activated bleaching earth. \(J\). Chromatography, 14, 343 – 347.

Karakaş, R. & Yüksel, Ü. (1998). Modifi cation of perlite for use as a thinlayer chromatography on activated bleaching earth. J. Chromat. Sci., 36, 499 – 504.

Mohammad, A. (1997). Thin-layer chromatographic methods for the identification, estimation, and separation of toxic metals in environmental samples; J. Planar Chromatography - Modern TLC, 10, 48 – 54.

Mohammad, A. & Agrawal, V. (2000). Applicability of surfactant-modifi ed mobile phases in thin-layer chromatography of transition metal cations: identification and separation of zinc (II), cadmium (II), and mercury (II) in their mixtures. J. Planar Chromatography - Modern TLC, 13, 210 –216.

Mohammad, A. & Agrawal, V. (2002). Use of cationic micellar mobile phases in normal-phase TLC for enhanced selectivity in the separation of transition metal ions: simultaneous separation of mixtures of zinc, nickel, mercury, and cadmium or manganese cations. Acta Chromatographıca, 12, 177 – 188.

Mohammad, A. & Fatima, N. (1987). Cation thin-layer chromatography in mixed organic-solvents containing s-butylamine - separation of Zn (II) from Cd (II) and Cu (II); Chromatographia, 23, 653 – 656.

Mohammad, A. & Jabeen, N. (2003). Soil-thin layer chromatography of heavy metal cations with surfactant-modified mobile phases: mutual separation of zinc (II), cadmium (II), and mercury (II). J. Planar Chromatography - Modern TLC, 16, 137 – 143.

Mohammad, A. & Khan, M.A.M. (1995). Thin-layer chromatographicseparation of zinc from Cd (II), Hg (II) and Ni (II) in environmentalsamples using impregnated silica layers. J. Chr omat. Sci., 33 , 531 – 535.

Mohammad, A., Iraqi, E. & Khan, I. A. (2002). Use of nonionic poly(ethylene glycol) p-isooctyl-phenyl ether (triton x-100) surfactant mobile phases in the thin-layer chromatography of heavy-metal cations. J. Chromat. Sci., 40, 162 – 169.

Mohammad, A., Agrawal, V. & Hena, S. (2004). Adsorption studies of metal cations on a silica static flat bed using anionic micellar mobile-phase systems sontaining carboxylic acids: Separation of co-existing iron (III), copper (II) and nickel (II) cations. Adsorption Science & Technology, 22, 89 – 105.

Popov, A. & Stefanov, K. (1968). Einsatz des aktivierten Bentonits als Adsorbens bei der Dünnschichtchromatographie. Compt. R. Acad. Bulg. Sci., 21, 673 – 675.

Rollins, C. (1963). Thin layer chromatographic separation of leaf pigments: a rapid demonstration. J. Chem. Educ., 40, 32.

Savaşcı, Ş. & Akçay, M. (1996). The determination of some heavy metal cations by TLC/photodensitometry. Turkish J. Chem., 20, 146 – 152.

Sheen, B. (1971). Chine clay – a sorbent for thin-layer chromatography. \(J\). Chromatography A, 60, 363 – 370.

Sthal, E. (1969). Thin-layer chromatography. New York: Springer.

Walsch, B.J.M. (1967). The use of talc as a TLC adsorbent. J. Chem. Educ., 44, 294 – 296.
