Резюме. In this work, we will report a combined experimental and theoretical study on molecular structure, vibrational spectra and energies of Z-(1-pyridin-2-yl-methylene)thiosemicarbazone. The FTIR spectra of Z-(1-pyridin-2-yl-methylene)-thiosemicarbazone molecule have been recorded using Bruker Tensor 27 spectrometer in the range of 400–4000 cm\(^{−1}\). The molecular geometry and vibrational frequencies and energies in the ground state are calculated by using the HF methods with 6-31G(d,p) basis sets. The calculated HOMO and LUMO energies also confirm that charge transfer occurs within the molecule. The geometries and normal modes of vibrations obtained from HF/6-31G(d,p) calculations are in good agreement with the experimentally observed data.

Ключови думи: thiosemicarbazone, HF, IR, HOMO, LUMO

Introduction

Heterocyclic nitrogen containing compounds, such as pyridine and its derivatives, are commonly present in synthetic and natural products (Gilchrist, 1988; Fallas et al., 2009). Pyridine heterocycles are a repeated moiety in many large molecules with interesting photo physical, electrochemical and catalytic applications (Lizarraga et al., 1997; Georgopoulou et al., 1999; Liaw et al., 2000; Trotter & White, 1978; Rajpure & Bhosale, 2000; Licht, 1995). They serve as good anesthetic agent and hence are used in the preparation of drugs for certain brain disease. These pharmaceutically acceptable salts and the pre-drugs are used for the treatment or prevention of diabetic neuropathy (Altenburger et al., 2004).

Heterocyclic thiosemicarbazones have aroused considerable interest in chemistry and biology due to their antibacterial, antimalarial, antineoplastic and antiviral activities and represent an important series of compounds because of potentially beneficial, biological activity (Gallego et al., 1979). Thiosemicarbazones display a broad spectrum of pharmacological properties, including antitumor, antifungal, antibacterial, antiviral and antimalarial activities (Beraldo & Gambino, 2004). Much effort has been devoted to structural variations of the thiosemicarbazones for achieving the ultimate goal of medicinal applications (Hu et al., 2006; French et al., 1974; French & Blanz, Jr., 1966; Sartorelli et al., 1971; Liu et al., 1995; Agrawal & Sartorelli, 1969). However, the detailed HF/6-31G(d,p) comparative studies on the complete FTIR spectra of Z-(1-pyridin-2-yl-methylene)-thiosemicarbazone have not been reported so far.

In this study, molecular geometry, optimized parameters and vibrational frequencies, energies are computed and the performance of the computational methods for ab initio at 6-31G(d,p) basis sets are compared.

The HOMO represents the ability to donate an electron, LUMO as an electron acceptor represents the ability to obtain an electron the HOMO and LUMO energy calculated by HF at 6-31G(d,p) method.

Experimental

General

All chemicals were purchased from Merck chemicals and were used without further purification. Nuclear magnetic resonance spectra were recorded using a Bruker Avance 500 MHz. All the chemical shifts are quoted in ppm using the high-frequency positive convention; 1H NMR spectra were referenced to external TMS. Melting points were determined in an Electrothermal 9200. Infrared spectra (400-4000 cm−1), were recorded using FT-IR Bruker Tensor 27 spectrophotometer at room temperature. The samples were prepared as KBr pellets.

Preparations of Z-(1-pyridin-2-yl-methylene)-thiosemicarbazone

Z-(1-pyridin-2-yl-methylene)-thiosemicarbazone (1) was synthesized starting from of 2-Pyridinecarboxaldehyde (1 mmol) in EtOH (15 mL) was added stoichiometric amount (equimolar) of thiosemicarbazone (1 mmol). The mixture was refluxed for about 4 h. After removal of the ethanol the white solid that appeared was filtered off, and washed three times with dichloromethane and dried in vacuum at 80 °C for 24 h. m.p. 212 °C. IR (KBr) u: 3857, 3743, 3421, 3265, 3134, 1617, 1582, 1489, 1299, 1159, 982, 877. Anal. calcd. (%) for C7H8N4S: C, 46.65; H, 4.47; N, 31.09. Found. (%): C, 46.73; H, 4.48; N, 31.14.

Computational method

All calculations were performed using the Gaussian 98 package of program on a Windows-XP operating PC. The molecular structure of the title compound in the ground state is computed by performing HF with 6-31G(d,p) basis sets. Full optimization for the all molecule were carried out by the HF method using with the 6-31G(d,p) basis set.

Results and discussion

Molecular geometry

The optimized molecular structure of Z-(1-pyridin-2-yl-methylene)-thiosemicarbazone molecule is obtained from Gaussian 03 package of program are shown in the (Fig. 1).

Fig. 1. Numbering system adopted in the study for compound (1) using HF/6-31(d,p)

Computational (theoretical) calculations energy differences for the compound (1) were determined by optimizing the geometry at various computational levels. Comparison of the energies at the HF/6-31G(d,p) levels listed in Table 1 shows the differences in the energies. The optimized structural parameters of compound (1) calculated by ab-initio/ HF levels with the standard 6-31G(d,p) basis set are listed in Table 2.

Vibrational spectroscopy is extensively used in organic chemistry for the identification of functional groups of organic compounds, the study of molecular conformations, reaction kinetics, etc. The observed and calculated data of the vibrational spectrum of compound (1) are given in Table 3. The comparative graph of calculated vibrational frequencies by HF method at 6-31G(d,p) basis sets for the compound (1) are given in Fig. 2.

The suggested reason was that the result obtained by the calculation was harmonic oscillation frequency, while the experimental value contained the anharmonic oscillation frequency. Assignment of compound systems could be proposed on the basis of frequency agreement between the computed harmonics and the observed fundamental modes.

The prominent peaks around 3857, 3743 and 1617 cm−1 in the FT-IR spectra are attributed to νN–H, νNH2and νC=N modes, respectively. The C=C stretching vibration of the aromatic ring appeared around 1582 and 1489 cm−1. The peaks around 1299 and 982 cm−1 are due to νN–N and N–H out of plane bending vibrations, respectively. The in plane bending vibration and out of plane bending vibrations of aromatic C–H group are characterized by bands in the range of 1159 and 877 cm−1, respectively (Fig. 3).

The highest occupied molecular orbitals (HOMOs) and lowest–lying unoccupied molecular orbitals (LUMOs) are named as Frontier molecular orbitals (FMOs). Frontier molecular orbitals (FMOs) i.e. the highest occupied molecular orbital (HOMO) and the lowest unoccupied molecular orbital (LUMO) are shown in (Fig. 4). The HOMO represents the ability to donate an electron, LUMO as an electron acceptor represents the ability to obtain an electron. The HOMO and LUMO energy calculated by the HF level with the 6-31G(d, p) basis set. The HOMO−LUMO energy gap is an important stability index. The HOMO–LUMO energies were also calculated at the HF level with the 6-31G(d, p) basis set and the values are listed in (Fig. 4).

This electronic absorption corresponds to the transition from the ground to the first excited state and is mainly described by one electron excitation from the highest occupied molecular or orbital (LUMO). The HOMO is located over the group, the HOMO→LUMO transition implies an electron density transfer to ring from chlorine and partially from ring.

Conclusion

The structure of Z-(1-pyridin-2-yl-methylene)-thiosemicarbazone geometry was compared with optimized parameters obtained by means of ab initio calculations with the 6-31G(d,P) basis set. The geometries and normal modes of vibrations obtained from HF/6-31G(d,p) calculations are in good agreement with the experimentally observed data. The HOMO and LUMO levels of Z-(1-pyridin-2-yl-methylene)-thiosemicarbazone have been studied with HF/6-31G(d,p) level.

REFERENCES

Agrawal, K.C. & Sartorelli, A.C. (1969). Potential antitumor agents. II. Effects of modifications in the side chain of 1-formylisoquinoline thiosemicarbazone. J. Med. Chem., 12, 771–774.

Altenburger, J.-M., Lassalle, G.Y., Matrougui, M., Galtier, D., Jetha, J.-C., Bocskei, Z., Berry, C.N., Lunven, C., Lorrain, J., Herault, J.-P., Schaeffer, P., O’Connor, S.E. & Herbert, J.-M. (2004). SSR182289A, a selective and potent orally active thrombin inhibitor. Bioorg. & Med. Chem., 12, 1713-1730.

Beraldo, H. & Gambino, D. (2004). The wide pharmacological versatility of semicarbazones, thiosemicarba-zones and their metal complexes. Mini-Rev. Med. Chem., 4, 31–39.

Fallas J.A., Gonzalez, L. & Corral, I. (2009). Density functional theory rationalization of the substituent effects in trifluoromethyl-pyridinol derivatives. J. Tetrahedron Letters, 65, 232-239.

French, F.A. & Blanz Jr, E.J. (1966). The carcinostatic activity of thiosemicarbazones of formyl heteroaromatic compounds. III. Prrimary correlation. J. Med. Chem., 9, 585–589.

French, F.A., Blanz Jr, E.J., Shaddix, S.C. & Brockman, R.W. (1974). α-(N)-formylheteroaromatic thiosemicarbazones: inhibition of tumor-derived ribonucleoside diphosphate reductase and correlation with in vivo antitumor activity. J. Med. Chem., 17, 172–181.

Gallego, M., Garcia-Vargas, M. & Valcarcel, M. (1979). Pyridine-2-carbaldehyde 2-hydroxybenzoylhydrazone as a selective reagent for the extraction and spectrophotometric determination of iron(II). Analyst, 104, 613-619.

Georgopoulou, A.S., Ulvenlund, S., Mingos, D.M.P., Baxter, I. & Williams, D.J. (1999). Synthesis of water soluble DTPA complexes with pendant uracil moieties capable of forming complementary hydrogen bonds. J. Chem. Soc., Dalton Trans., 547-551.

Gilchrist, T.L. (1988). Heterocylic chemistry. New York: John Wiley & Sons.

Hu, W.-X., Zhou, W., Xia, C.-N. & Wen, X. (2006). Synthesis and anticancer activity of thiosemicarbazones. Bioorg. & Med. Chem. Lett., 16, 2213–2218.

Liaw, W.-F., Lee, N.-H., Chen, C.-H., Lee, C.-M., Lee, G.-H. & Peng, S.-M. (2000). Dinuclear and mononuclear iron(II)−thiolate complexes with mixed CO/CN- ligands: synthetic advances for iron sites of [Fe]-only hydrogenases. J. Am. Chem. Soc., 122, 488-494.

Licht, S. (1995). Electrolyte modified photoelectrochemical solar cells. Solar Energy Materials & Solar Cells, 38, 305-319

Liu, M.-C., Lin, T.-S., Penketh, P. & Sartorelli, A.C. (1995). Synthesis and antitumor activity of 4- and 5-substituted derivatives of isoquinoline-1-carboxaldehyde thiosemicarbazone. J. Med. Chem. , 38, 4234–4243.

Lizarraga, M.E., Navarro, R. & Urriolabeitia, E.P. (1997). Synthesis and characterization of dinuclear complexes of Pd(II) containing the (-N-C-S) 2 skeleton. J. Organometallic Chem., 542, 51-60.

Rajpure, K.Y. & Bhosale, C.H. (2000). Sb2S3 semiconductor-septum rechargeable storage cell. Materials Chem. & Phys., 64, 70-74.

Sartorelli, A.C., Agrawal, K.C., Moore, E.C. (1971). Mechanism of inhibition of ribonucleoside diphosphate reductase by α-(N)-heterocyclic aldehyde thiosemicarbazones. Biochem. Pharmacol., 20, 3119–3123.

Trotter, P.J. & White, P.A. (1978). Resonance raman determination of the triiodide structure in bis(tetrathiotetracene)triiodide organic conductor compared with the poly(vinyl alcohol)-iodine complex. Applied Spectroscopy, 32, 323-324.
